Appendix
12.3 Emergency Codes
Code Severity
0x3100 Error
0x3101 Error
0x3102 Error
0x3110 Error
0x3111 Error
0x3118 Error
0x3119 Error
0x3180 Warning
0x3181 Warning
0x3190 Warning
0x3191 Warning
0x3200 Error
0x3201 Error
0x3280 Warning
0x4280 Warning
0x5030 Error
0x5031 Error
0xFF01 Error
0xFF02 Error
0xFF90 Warning
0xFF91 Warning
0xFF92 Warning
Table 12.1 Emergency Codes
®
VLT ISD Connection Box Operating Instructions
Description
Input voltage (U ) above absolute maximum.
DC
Input voltage (U ) below absolute minimum.
DC
Input voltage (U ) below intermediate voltage (U
DC
24 V power supply loss.
24 V power supply timeout during initialisation.
5 V CAN power supply loss.
5 V CAN power supply timeout during initialisation.
Switch on, nominal U
Switch on, nominal U
Switch on: 24 V power supply bad.
Switch on: 5 V CAN power supply bad.
Hazardous intermediate circuitry voltage.
Intermediate circuitry voltage (U
Intermediate circuitry voltage (U
Switch on: Heat sink temperature above maximum.
Fuse 1 blown.
Fuse 2 blown.
Power-up timeout.
Power-down timeout.
Switch on: No safety power.
Safety power 1 loss.
Safety power 2 loss.
®
MG75G102 - VLT is a registered Danfoss trademark
) during power-up.
ZK
range: Input voltage above maximum.
DC
range: Input voltage below minimum.
DC
) drop during operation.
ZK
) over voltage during operation.
ZK
