Commissioning

5.4 Basic Programming

5.4.1 Commissioning with SmartStart

The SmartStart wizard enables fast configuration of basic
motor and application parameters.
•
At first power-up or after initialization of the
adjustable frequency drive, SmartStart starts by
itself.
•
Follow on-screen instructions to complete commis-
5 5
sioning of the adjustable frequency drive.
SmartStart can always be reactivated by selecting
Quick Menu Q4 - SmartStart.
•
For commissioning without use of the SmartStart
wizard, refer to 5.4.2 Commissioning via [Main Menu]
or the Programming Guide.
NOTICE!
Motor data are required for the SmartStart set-up. The
required data are normally available on the motor
nameplate.

5.4.2 Commissioning via [Main Menu]

Recommended parameter settings are intended for start-up
and checkout purposes. Application settings may vary.
Enter data with power ON, but before operating the
adjustable frequency drive.
1. Press [Main Menu] on the LCP.
2. Use the navigation keys to scroll to parameter
group 0-** Operation/Display and press [OK].
Figure 5.2 Main Menu
28
®
VLT HVAC Drive Instruction Manual
1107 RPM 3.84 A
Main Menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
MG11AJ22 - Rev. 2013-09-13
3. Use navigation keys to scroll to parameter group
0-0* Basic Settings and press [OK].
Figure 5.3 Operation/Display
4. Use navigation keys to scroll to 0-03 Regional
Settings and press [OK].
Figure 5.4 Basic Settings
5. Use navigation keys to select [0] International or [1]
North America as appropriate and press [OK]. (This
changes the default settings for a number of basic
parameters).
6. Press [Main Menu] on the LCP.
7. Use the navigation keys to scroll to 0-01 Language.
8. Select language and press [OK].
9. If a jumper wire is in place between control
1 (1)
terminals 12 and 27, leave 5-12 Terminal 27 Digital
Input at factory default. Otherwise, No Operation
should be selected in 5-12 Terminal 27 Digital Input.
For adjustable frequency drives with an optional
bypass, no jumper wire is required between control
terminals 12 and 27.
10. 3-02 Minimum Reference
11. 3-03 Maximum Reference
0.0% 0.00A
Operation / Display
0-0 * Basic Settings
0-1 * Set-up Operations
0-2 * LCP Display
0-3 * LCP Custom Readout
0.0% 0.00A
Basic Settings
0-03 Regional Settings
[0] International
1(1)
0-
**
1(1)
0-0
*
