ioThinx 4510 Series

Horizontal Installation

Before installing the device, ensure there is enough space around the device so that it can dissipate heat. In
order to ensure the device works properly, we suggest reserving the space shown in the figure below.
CAUTION
DO NOT install the device vertically, as the fan-less heat dissipation design will not perform as intended.

Powering on the Unit

After turning on the power supply, it will take 5 to 10 seconds for the operating system to boot up. The green
Ready LED will illuminate continuously until the operating system is ready.
3-9
Hardware Installation
