ioThinx 4510 Series
02: INPUT STATUS
Parameter
diStatus
diMode
diCounterOverflowFlag
03: HOLDING REGISTER
Parameter
diCounterValue
diCounterStatusAll
diCounterOverflowFlagClearAll
04: INPUT REGISTER
Parameter
diStatusAll
diCounterOverflowFlagAll
diModeAll

45MR-2404 (-T), 4 Relays Registers

01: COIL STATUS
Parameter
relayStatus
relayCurrentCountReset
03: HOLDING REGISTER
Parameter
relayStatusAll
04: INPUT REGISTER
Parameter
relayTotalCount
relayCurrentCount

45MR-2600 (-T), 16 DOs Registers

01: COIL STATUS
Parameter
doStatus
doPulseStatus
02: INPUT STATUS
Parameter
doMode
03: HOLDING REGISTER
Parameter
doStatusAll
doPulseCount
doPulseOnWidth
doPulseOffWidth
doPulseStatusAll
Description
DI - DI mode - status (0: OFF, 1: ON)
DI - mode (0: DI, 1: Counter)
DI - Counter mode - overflow flag (0: Normal, 1:
Overflow)
Description
DI - Counter mode - value
DI - Counter mode - status (0: Pause, 1: Run)
DI - Counter mode - clear overflow flag (1: Clear) 1
Description
DI - DI mode - status (0: OFF, 1: ON)
DI - Counter mode - overflow flag (0: Normal, 1:
Overflow)
DI - mode (0: DI, 1: Counter)
Description
Relay - Relay mode - status (0: OFF, 1: ON)
Relay - reset current count (1: Reset)
Description
Relay - Relay mode - status (0: OFF, 1: ON)
Description
Relay - total count
Relay - current count
Description
DO - status (0: OFF, 1: ON)
DO - Pulse mode - status (0: Stop, 1: Start)
Description
DO - mode (0: DO, 1: Pulse)
Description
DO - status (0: OFF, 1: ON)
DO - Pulse mode - count
DO - Pulse mode - ON width (unit: 500 us)
DO - Pulse mode - OFF width (unit: 500 us)
DO - Pulse mode - status (0: Stop, 1: Start)
A-4
Appendix
Length Type
16 BOOL
16 BOOL
4 BOOL
Length Type
8 DWORD
1 WORD
WORD
Length Type
1 WORD
1 WORD
1 WORD
Length Type
4 BOOL
4 BOOL
Length Type
1 WORD
Length Type
8 DWORD
8 DWORD
Length Type
16 BOOL
4 BOOL
Length Type
16 BOOL
Length Type
1 WORD
8 DWORD
4 WORD
4 WORD
1 WORD
