Introduction
Area Title
8 Control circuitry
Table 1.3 Legend to Illustration 1.3

1.5 Frame Sizes and Power Ratings

References to frames sizes used in this manual are defined in Table 1.4.
[V] A2 A3
200-240 1.1-2.2 3.0-3.7
380-480 1.1-4.0 5.5-7.5
525-600 n/a 1.1-7.5
525-690 n/a 1.1-7.5
Table 1.4 Frames Sizes and Power Ratings
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.ctiautomation.net - Email: info@ctiautomation.net
®
VLT HVAC Drive Operating Instructions
Functions
•
Input power, internal
processing, output, and motor
current are monitored to
provide efficient operation
and control
•
User interface and external
commands are monitored and
performed
•
Status output and control can
be provided
A4 A5 B1
1.1-2.2 1.1-3.7 5.5-11
1.1-4.0 1.1-7.5 11-18.5
n/a 1.1-7.5 11-18.5
n/a n/a n/a
®
MG11AI02 - VLT is a registered Danfoss trademark
Frame Size [kW]
B2 B3 B4
15 5.5-11 15-18.5 18.5-30
22-30 11-18.5 22-37 37-55
22-30 11-18.5 22-37 37-55
11-30 n/a 11-37 n/a
C1 C2 C3 C4
37-45 22-30 37-45
75-90 45-55 75-90
75-90 45-55 75-90
37-90 45-55 n/a
