Introduction
Area Title
•
8 Control circuitry
•
•
Table 1.3 Legend to Figure 1.3

1.4 Frame Sizes and Power Ratings

[V] A2 A3
200–240 1.5–3 4–5
[1.1– [3.0–3.7]
2.2]
380–480 1.5–5 7.5–10
[1.1– [5.5–7.5]
4.0]
525–600 N/A 1.5–10
[1.1–7.5]
Table 1.4 Frame Sizes and Power Ratings
MG16E222
Instruction Manual
Functions
Input power, internal
processing, output, and motor
current are monitored to
provide efficient operation
and control
User interface and external
commands are monitored and
performed
Status output and control can
be provided
Frame Size (hp [kW])
A4 A5 B1
1.5–3 1.5–5 7.5–15
[1.1–2.2] [1.1–3.7] [5.5–11]
1.5–5 1.5–10 15–25
[1.1–4.0] [1.1–7.5] [11–18.5]
N/A 1.5–10 15–25
[1.1–7.5] [11–18.5]
Danfoss A/S © Rev. 2014-02-10 All rights reserved.
B2 B3 B4
20 [15] 7.5–15 20–25 25–40
[5.5–11] [15–18.5] [18.5–30]
30–40 15–25 30–50 50–75
[22–30] [11–18.5] [22–37] [37–55]
30–40 15–25 30–50 50–75
[22–30] [11–18.5] [22–37] [37–55]
C1 C2 C3 C4
50–60 30–40 50–60
[37–45] [22–30] [37–45]
100–125 60–75 100–125
[75–90] [45–55] [75–90]
100–125 60–75 100–125
[75–90] [45–55] [75–90]
1 1
