MULTI-INPUT MENU
BIT RATE
HDMI
VIDEO LEVEL
SIGNAL FORMAT
HDMI1, HDMI2, DisplayPort1,
DisplayPort2, COMPUTE MODULE,
OPTION only
RESET

OSD

OSD MENU
LANGUAGE
ENGLISH
DEUTSCH
FRANÇAIS
ITALIANO
ESPAÑOL
SVENSKA
РУССКИЙ
OSD TIME
OSD POSITION
UP
DOWN
RIGHT
LEFT
INFORMATION OSD
COMMUNICATION INFO.
OSD TRANSPARENCY
DisplayPort 1.1a is selected at DisplayPort, [HBR] is set automatically.
DisplayPort1.2 and SST are selected at DisplayPort, set [HBR] or [HBR2].
DisplayPort1.2 and MST are selected at DisplayPort, [HBR2] is set automatically.
Selects [MODE1] or [MODE2].
MODE1: Max resolution is 3840 x 2160 (30 Hz)
MODE2: Max resolution is 3840 x 2160 (60 Hz), HDCP2.2, or HDR
RAW: For computer settings. Show all input signals of 0-255 gray levels.
EXPAND: For audio-visual equipment settings. Expands the input signals from 16-235 gray levels to
0-255 gray levels.
AUTO: Automatically sets input signals by adjusting connected equipment.
NOTE: This function is available only in [HDMI] or [DisplayPort] or [OPTION] and is selected at [INPUT
SIGNAL].
Selects the color space setting for the HDMI/DisplayPort signal.
NOTE: If [SLOT2 CH SETTING] is [2CH], this function is grayed out.
Resets MULTI INPUT options back to factory settings, except for [INPUT DETECT] (priority of input signals
only), [INPUT CHANGE] (INPUT1 and INPUT2), [INPUT SELECT], [PICTURE ASPECT] and [BIT RATE].
Select the language used by the OSD.
Turns off the OSD after a period of inactivity. The preset choices are 10-240 seconds.
Determines the location where the OSD appears on the screen.
Selects whether the Information OSD is displayed or not. The Information OSD will appear when the input
signal or input source changes. The Information OSD will also give a warning when no signal is detected or
the signal is out of range.
An interval between 3 to 10 seconds is selectable for the Information OSD to appear.
The [MONITOR ID] and [IP ADDRESS] will appear when the remote control DISPLAY button is pressed.
Set [ON]/[OFF] for the transparency of the back ground image When OSD menu is displayed.
