Installing an Optional Sensor Unit

Fixed by screwN: Remove the seal covering screw holes on the bezel. Secure the unit with the attached screw.
Fixed by double-sided tapeN: You can set the sensor unit on any side of the monitor.

NOTEN: For the UN462A/UN462VAN:

• When installing the sensor unit on the upper side of the monitor, please use the provided double-sided tape. If the
sensor unit is installed using a screw, it could damage the monitor.

• When installing the sensor on the upper and left sides of the monitor, follow instructions below to avoid damage to
the monitor.


• Fixed by screw: Set the sensor unit close to the back side.


• Fixed by double-sided tape: Set the sensor unit 8 mm away from the front edge.

F or the UN552S/UN552VSN:

• Please use double-sided tape only.
8 mm
Seal
Double-sided tape
Screw Position
