Features

Optimized for Video wall
– Ultra Narrow Bezel
Provides the optimum solution in a tiling environment.
– Tile Matrix and Tile Compensation (TILE COMP), Tile Cut
Shows one image over multiple screens with accuracy while compensating for bezel width.
– Frame comp and V SCAN REVERSE
Compensates for content lag in larger video walls with horizontal moving objects.
– HDMI / DisplayPort daisy chain
Improved daisy chain capabilities allowing for 4K daisy chain for video wall purposes.
– USB power supply
Allows the monitor to supply power to an external device via USB CM1 terminal (5V/2A (Max)).
Seamless and accurate color reproduction
– SpectraView engine
The sophisticated NEC exclusive color processing engine integrated into the display. It combines internal luminance,
white point, ambient lighting, temperature and time monitoring, together with individual characterization and calibration
of each display during production, to provide an unparalleled level of color control, uniformity, accuracy and stability.
The SpectraView engine provides the utmost in versatility; from faster and more advanced color calibration, to the ability
to accurately emulate color spaces such as Adobe
Profiles and internal 3D Look-Up Tables.
– Picture mode include HDR (see
Up to 5 programmable Picture Mode profiles for quick access to Industry standard color spaces or user customized
settings. HDR video is also supported.
– NEC Display Wall Calibrater(NDWC) and MultiProfiler supported.
Multiple color modes can be easily configured and selected using the MultiProfiler software, which can be downloaded
from our website.
– Uniformity (see
page
Provides a more consistent luminance and color across the screen by compensating for variations in luminance and color
that are inherent to LCD panels.
– Stand-alone calibration (see
This function updates the monitor's internal color processor reference data with measurements taken using your color
sensor to fix color presentation.
Please calibrate your monitor in this cases:
– All monitors are set to the same picture mode but each monitor's display color look individual.
– Color degradation due to long-term use.
By using a calibration sensor, OSD picture preset value will match to the value sensor measures.
Multiple signal input
– Option Board Slot.
You can use an Option Board. Please contact your supplier for detailed information.
– Media player (see
page
The Internal Media Player will play audio and video files that are stored on a microSD memory card or USB memory
connected to the side terminal panel on the monitor.
– DisplayPort and HDMI interfaces (see
Designed to be future-ready scalable solutions for high performance digital display connectivity. Both interfaces enable
the highest resolution, fastest refresh rates and deepest color depths.
– Picture-By-Picture/Picture-In-Picture (see
Increases productivity by displaying two different input sources simultaneously, either side by side (Picture-By-Picture) or
a small sub screen on a large main screen (Picture-In-Picture). This function can also be used to display one input source
in two different picture modes for a side by side comparison of different settings.
®
page
53).
107).
page
50).
28).
page
26).
page
54).
RGB and sRGB, to performing printer output emulations using ICC
English−5
