MULTI-INPUT MENU
INPUT DETECT
*6
NONE
FIRST DETECT *3, *5
LAST DETECT
*3, *5
CUSTOM DETECT
*3
INPUT CHANGE
TERMINAL SETTINGS
DVI MODE
VGA MODE
SYNC TYPE
DisplayPort
* : When you select OPTION for multi picture input, this function depends on which Option Board installed in the monitor.
3
* 5 : Except for MP
* : Depending on the device, it may not be detected correctly.
6
Selects the method of input detection the monitor uses when more than one signal source is connected.


NOTE: • When SUPER is selected within [INPUT CHANGE], this function cannot be changed.

•
[INPUT DETECT] is released if [HUMAN SENSOR] is activated while [INPUT DETECT] is active.
The Monitor will not search for signals at the other video input ports.
When the current video input signal is not present, the monitor searches for a video signal from another video
input port. If a video signal is present in the other input, the monitor switches from the current video source to
this active video source automatically. The monitor will not look for any other video signals while the current
video source is present.
When the monitor is reproducing a signal from the current video source and a new second video source is
supplied to the monitor, the monitor will automatically switch to the new video source. When the current video
input signal is not present anymore, the monitor searches for a video signal from any other video input. If a
video signal is present in the other input, the monitor switches from the current video source to this active
video source automatically.
Sets the priority of input signals.
When [CUSTOM DETECT] is selected, the monitor searches on preset inputs only.
e.g. In the priorities, a signal input set to [PRIORITY 1] has the highest priority.


NOTE: • Priority of an option input signal is only available in [PRIORITY3], except for a slot 2 type PC
option.

• If you set DisplayPort1 to Priority [1] or [2] or [3], you cannot set [OPTION] (slot 2 type PC option
(DP)) to any priority settings.

•
If you set [OPTION] (slot 2 type PC option (DP)) to Priority [1] or [2] or [3], you cannot set
DisplayPort1 to any priority settings.
Sets input change speed. If [QUICK] is set, speed of changing input is faster but this setting may cause image
distorted while switching signals.
Selecting SUPER enables high-speed switching between two preset signals.


NOTE: • Depending on the Option Board you use, [SUPER] may not available.

•
When [SUPER] is active, [MULTI PICTURE MODE], [TEXT TICKER], [STILL], [POINT ZOOM] are
not available.

•
When you set [QUICK] then change input signal to DisplayPort, displaying image is distorted.

•
When a cable is connected to the HDMI OUT port, speed of changing input may not be faster.

•
When a cable is connected to the HDMI OUT port, if [QUICK] or [SUPER] is set, this setting
causes image distorted while switching signals.
Selects the kind of DVI-D equipment, which is connected to the DVI input.
Select [DVI-HD] when a DVD player or computer equipment is connected which requires HDCP authentication.
Select [DVI-PC] when computer equipment is connected which does not requires HDCP authentication.
Selects [RGB] or [YPbPr] for VGA input.
Selects a type of sync signal of VGA (RGB).
AUTO: Automatically identifies received sync signal type.
H/V SYNC: If the input signal is H/V SYNC then displayed image is unstable with [AUTO] setting, please set
[H/V SYNC].
SOG: If the input signal is SOG then displayed image is unstable with [AUTO] setting, please set [SOG].
NOTE: If [VGA MODE] is set to [YPbPr], you cannot set [SYNC TYPE].
Selects the DisplayPort mode [1.1a] or [1.2].
DisplayPort 1.1a is selected, [SST] is set automatically.
DisplayPort 1.2 is selected, set [SST] or [MST*].
* DisplayPort 1.2 should be selected when using Multi-Stream Transport. Multi-Stream Transport requires a
corresponding display card. Contact your supplier for limitations of this function.
NOTE: MST is not available with DisplayPort2 signal input.
English−111
