OSD MENU
OSD ROTATION
LANDSCAPE
PORTRAIT
KEY GUIDE
MEMO
INPUT NAME
CLOSED CAPTION
VIDEO input only
RESET

MULTI-DISPLAY

MULTI-DSP MENU
AUTO TILE MATRIX SETUP
SETTING COPY
COPY START
ALL INPUT
Determines the OSD orientation between landscape and portrait.
Shows the OSD in landscape orientation.
Shows the OSD in portrait orientation.
NOTE: If [PORTRAIT] is set, [CLOSED CAPTION] is not available.
Key guide is shown when the OSD menu is displayed.
NOTE: This function is not available when [OSD FLIP] is [ON].
Displays the memo title and message set via the HTTP server. For more detail, please refer to the
Settings" on page 88.
You can create a name for the [INPUT] currently being used.
Max: 14 characters, including Space, A-Z, 0-9, and some symbols.
Activates closed captioning.
NOTE: This function is released if the following function is activated: [MULTI PICTURE MODE], [TEXT
TICKER], [PORTRAIT] in [OSD ROTATION], [TILE MATRIX], [SCREEN SAVER], [STILL], [POINT ZOOM],
[SUPER] in [INPUT CHANGE].
Resets the following settings within the OSD menu back to factory setting:
[OSD TIME], [OSD POSITION], [INFORMATION OSD], [OSD TRANSPARENCY], [CLOSED CAPTION].
Allows auto setting of [TILE MATRIX] by inputting the number of monitors arranged horizontally and vertically
on the primary monitor. Following settings are set automatically: [MONITOR ID], [TILE MATRIX], [TILE
MATRIX MEM], [Input Signal], [DisplayPort] in [TERMINAL SETTINGS] and setting for video out.

NOTE: • AUTO ID will be automatically executed.

•
When you use this function, it is recommended that monitors be chained by DisplayPort cable.

•
This function is released if [MOTION] in [SCREEN SAVER] is activated.
Example of installation via LAN:
H MONITORS 3
V MONITORS 3
In a daisy chain scenario, select the OSD menu categories that you want to copy over to the other monitors.
NOTE: When you use this function, monitors should be daisy chained by LAN cables. The selection of which
settings to copy will be reset to default when the monitor is powered off. The number of monitors that the
settings can be copied to may be reduced based on the quality of the LAN cables being used. Please see the
"Setting copy.pdf" file on the NEC website.
Select [YES] and press the SET/POINT ZOOM button to start copying.
All input terminals settings are copied when you select this item. Default is [OFF].
Primary monitor
English−113
