Summary of Contents for NEC MultiSync UN462A
Page 1
User’s Manual Large Format Display MultiSync UN462A MultiSync UN462VA MultiSync UN552S MultiSync UN552VS MODEL: UN462A, UN462VA, UN552S, UN552VS The model name and serial number can be found in the rating label on the rear side of monitor.
Table of Contents Registration Information ..........1 Safety Precautions and Maintenance ......3 Important Information ..........2 Recommended Use ............ 3 Safety Precautions, Maintenance & Cleaning the LCD Panel ..........4 Recommended Use ............ 3 Cleaning the Cabinet ..........4 Features Installation Chapter 1...
Page 3
Basic Operation Chapter 4 Power ON and OFF Modes ........32 OSD (On-Screen-Display) Controls ......37 Operating Range for the Optional Remote Control... 33 Using the Media Player..........39 Using Power Management ........33 File Display Screen ........... 40 Showing the Information OSD ........34 Playing Files .............
Page 4
CONTROL .............. 117 SCHEDULE ............108 OPTION ..............121 MULTI-INPUT ............110 SYSTEM ..............122 OSD ................ 112 COMPUTE MODULE ..........122 Manufacturer’s Recycling and Energy Information Appendix C Disposing of your old NEC product ......124 Energy Saving ............124...
WARNINGN: The Federal Communications Commission does not allow any modifications or changes to the unit EXCEPT those specified by NEC Display Solutions of America, Inc. in this manual. Failure to comply with this government regulation could void your right to operate this equipment.
Please use the power cord provided with this monitor in accordance with the table below. If a power cord is not supplied with this equipment, please contact NEC. For all other cases, please use the power cord with the plug style that matches the power socket where the monitor is located.
ANSI/NFPA 70, the National • In the UK use a BS-approved power cord with a molded Electrical Code (NEC), in particular Section 820.93, plug having a black (5 A) fuse installed for use with this Grounding of Outer Conductive Shield of a Coaxial monitor.
• Adjust the monitor’s brightness, contrast and sharpness controls to enhance readability. • Get regular eye checkups. • Use the preset Size and Position controls with standard input signals. • Use the preset color settings. • Use non-interlaced signals. • Do not view the primary color blue on a dark background.
• – SpectraView engine The sophisticated NEC exclusive color processing engine integrated into the display. It combines internal luminance, white point, ambient lighting, temperature and time monitoring, together with individual characterization and calibration of each display during production, to provide an unparalleled level of color control, uniformity, accuracy and stability.
This device cannot be used or installed without the Tabletop Stand or other mounting accessory for support. For proper installation it is strongly recommended to use a trained, NEC authorized service person. Failure to follow NEC standard mounting procedures could result in damage to the equipment or injury to the user or installer. Product warranty does not cover damage caused by improper installation.
1. Press and slide to open the cover. 2. Align the batteries according to the (+) and (–) indications inside the case. 3. Replace the cover. NEC recommends the following battery use: CAUTIONN: Incorrect usage of batteries can result in leaks or bursting.
Page 12
4. Connect the supplied power cord • The monitor should be installed close to an easily accessible power outlet. CAUTIONN: • Fasten the power cord to the monitor by attaching the screw and clamp. (Recommended Fasten Force: 139 - 189N•cm). •...
Please note the following when mounting on wall or ceiling: CAUTIONN: • When using mounting accessories other than those that are NEC approved, they must comply with the VESA-compatible (FDMlv1) mounting method. • NEC recommends mounting interfaces that comply with UL1678 standard in North America.
Page 14
This may cause the monitor to become distorted or damaged. • Please install monitor in a spot of the wall or ceiling strong enough to support the monitor. • To prevent the monitor from falling off from the wall or ceiling, NEC strongly recommends using a safety wire.
Handles for safety wire Safety wire for landscape position Safety wire for portrait position Mounting location CAUTIONN: • The ceiling or wall must be strong enough to support the monitor and mounting accessories. • DO NOT install in locations where a door or gate can hit the unit. •...
CAUTIONN: • Do not mount this monitor with any tilt. • Do not mount this product face up, face down, or upside down for an extended period of time as it may cause permanent damage to the screen. Ventilation Requirements When mounting in an enclosed space or recessed area, leave adequate room between the monitor and the enclosure to allow heat to disperse, as shown below.
Make sure there is nothing on the table that can damage the monitor. When using mounting accessories other than NEC compliant and approved, they must comply with the VESA Flat Display Mounting Interface Standard (FDMI).
Installing and Removing the Optional Table Top Stand CAUTIONN: • Installing and removing the stand must be done by two or more people. • When installing the monitor stand, handle the unit with care to avoid pinching your fingers. For installation, follow the instructions included with the stand or mounting equipment. Use only those devices recommended by the manufacturer.
Installing an Option Board 1. Turn off the main power switch. 2. Place the monitor face down on a flat even surface that is larger than the monitor screen. Use a sturdy table that can easily support the weight of the monitor. NOTEN: To avoid scratching the LCD panel, always place a soft cloth, such as a blanket that is larger than the monitor’s screen area, on the table before laying the monitor face down.
Installing an Optional Sensor Unit Fixed by screwN: Remove the seal covering screw holes on the bezel. Secure the unit with the attached screw. Fixed by double-sided tapeN: You can set the sensor unit on any side of the monitor. NOTEN: For the UN462A/UN462VAN: •...
Parts Name and Functions Chapter 2 This Chapter Includes: > “Control Panel” on page 18 > “Terminal Panel” on page 19 > “Wireless Remote Control (Optional)” on page 21 English−17...
Control Panel - Button (minus button) Decreases the audio output level when the OSD menu is turned off. Acts to move the highlighted area to the left when navigating through the OSD menu options. Acts as minus button to decrease the adjustment of an OSD menu option after it has been selected with the [INPUT/SET] button.
Terminal Panel Optional sensor unit HDMI From Optional sensor unit AC IN Connector HDMI IN (HDMI1 (DAISY CHAIN IN)/HDMI2 (CEC)) Connects with the supplied power cord. HDMI signals input. Main Power Switch HDMI OUT (HDMI OUT (DAISY CHAIN OUT)) On/Off switch to turn main power ON/OFF. Output signal from HDMI 1, DVI IN, or OPTION.
Page 24
USB Ports Option Speaker Mounting Holes NOTEN: For the USB port information, please see “Connecting a Please contact your supplier for a list of compatible USB Device” on page speaker. USB1 (SENSOR): Downstream port (USB Type-A). Optional Sensor Unit (remote control, room USB2: Upstream port (USB Type-B).
Wireless Remote Control (Optional) ENT Button Makes selections in the Media Player settings. page For use with an Option Board. The function depends on which Option Board installed in the monitor. DISPLAY Button Shows/Hides the information OSD. See page Unlocks the remote control’s buttons if they have been locked in the IR LOCK SETTINGS.
Page 26
GUIDE Button MULTI PICTURE Buttons For use with an Option Board. The function depends on ON/OFF button: Turns Multi Picture Mode on and off. which Option Board is installed in the monitor. MODE button: Switches the mode between PIP (Picture-In- Picture) and PBP (Picture-By-Picture).
Connections Chapter 3 This Chapter Includes: > “Wiring Diagram” on page 24 > “Connections” on page 24 > “External Video Connections” on page 25 > “Internal Video Sources” on page 27 > “Connecting a USB Device” on page 30 Connecting External Equipment NOTEN: •...
Wiring Diagram USB devices such as a USB camera, USB storage device or USB USB cable USB1 (SENSOR) color sensor USB2 AUDIO USB port USB port USB CM1 (2A) Devices that (Type-A) (Type-B) USB CM2 require power supply: Computer (USB)* Ex: Multi Stereo Amplifier Presenter stick...
External Video Connections Video Inputs • Composite Video (RCA) – Analog video signal input with standard definition video quality, no audio signal. • VGA – Analog video signal connection to a computer. Video only, no audio signal. • DVI-D – Digital video signal connection to a computer. Video only, no audio signal. •...
Connecting to a Computer with HDMI • Please use an HDMI cable with the HDMI logo. • It may take a moment for the signal to appear after turning on the computer. • Some display cards or drivers may not display an image correctly. •...
HDMI-CEC (Consumer Electronics Control) HDMI-CEC provides compatible media players, connected via HDMI, the ability to communicate and allow limited control between the device and the monitor. For example, turning on a Blu-ray player can immediately switch input to the Blu-ray player without using the remote control.
Media Player The Internal Media Player will play audio and video files that are stored on a microSD memory card or USB storage device. page 39 for instructions on using the Media Player. Connect Compatible microSD Memory Card Format a microSD memory card in the FAT32 format or FAT16 format. Refer to the computer’s instruction manual or help file on how to format a microSD memory card.
• The optional DS1-IF10CE Compute Module Interface Board and Raspberry Pi Compute Module are available separately. Please contact an authorized NEC dealer for more information. Installation must be performed by a qualified technician. Do not attempt to install a Compute Module Interface Board and Raspberry Pi Compute Module by yourself.
Connecting a USB Device Some of the USB ports on the monitor’s terminal panel have different uses depending on the type of connected USB device. Please follow these guidelines when using these ports with supported devices. USB1 (SENSOR): USB downstream port (Type-A). Connection used by external USB devices (such as cameras, flash memory, keyboards, etc.) and internal devices (an Option Board or Raspberry Pi Compute Module Interface Board and Raspberry Pi Compute Module when installed).
Basic Operation Chapter 4 This Chapter Includes: > “Power ON and OFF Modes” on page 32 > “Operating Range for the Optional Remote Control” on page 33 > “Using Power Management” on page 33 > “Showing the Information OSD” on page 34 >...
Power ON and OFF Modes Press the button on the Control Panel or POWER ON button on the Remote Control to turn on the monitor. The monitor’s power LED indicates the current status of the monitor. Please refer to the following table for information about the LED indicator.
Operating Range for the Optional Remote Control Point the top of the remote control toward the monitor’s remote control sensor during button operation. Use the remote control within a distance of about 7 m (23 ft.) from the remote control sensor, or at a horizontal and vertical angle of within 30°...
Showing the Information OSD The Information OSD provides information such as: Input Source, Picture Size, IP Address, Monitor ID, etc. Press the DISPLAY button on the remote control to bring up the Information OSD. Input name Audio input name Picture aspect Input Signal Information Multi-Picture information Communication Info...
Setting the Aspect Ratio Press the ASPECT button on the remote control to cycle through the options available for the current input signal. For MP (Media Player), VIDEO ➙ ➙ • FULL ZOOM NORMAL For DVI, DisplayPort1, DisplayPort2, VGA (RGB), OPTION* , COMPUTE MODULE* ➙...
Using Point Zoom The [POINT ZOOM] function increases the image size and expands it horizontally and vertically simultaneously. The image can be increased up to 10 times its size. 1. Press the SET/POINT ZOOM button on the remote control. A magnifier icon appears on-screen. 2.
OSD (On-Screen-Display) Controls NOTEN: Some functions may not be available depending on the model or optional equipment. Input source This menu is only available when the optional Main Menu Icons Raspberry Pi Compute MULTI-INPUT OPTION C MODULE PICTURE: PICTURE MODE Module Interface Board Main Menu Item PICTURE MODE...
Page 42
Below is a brief summary of where controls are under each menu item. A table listing all options is located in “OSD Controls List” on page 102. INPUTN: Select the input signal source. PICTUREN: Select one of the default picture modes, manually adjust the color settings, enable or disable SpectraView Engine, and adjust the aspect ratio, image flip, and rotation.
Using the Media Player The Internal Media Player will play image and video files that are stored on a microSD memory card or USB storage device. The Media Player plays videos, still images and background music (BGM). See page 30 for instructions on connecting USB storage device or microSD memory card.
File Display Screen Icon display RETURN Goes back one level higher. PAGE UP Displays the previous set of files in the folder. PAGE DOWN Displays the next set of files in the folder. SETTINGS Shows the settings screen for configuring the Media Player. THUMBNAILS/ Switches between displaying thumbnails or icons for files.
Playing Files Use the + – and SET/POINT ZOOM buttons on the remote control to navigate the Media Player menus. 1. Select either [SD CARD] or [USB] to view the file list. 2. De-select the files you do not want in the slideshow. All files in the directory are selected by default.
Configuring the Slideshow Settings Use the + – and SET/POINT ZOOM buttons on the remote control to navigate the Media Player menus. 1. Navigate to the SETTINGS icon and press SET/POINT ZOOM button. 2. Navigate to [PLAY MODE] and press SET/POINT ZOOM button. 3.
Enabling Auto Play Use the + – and SET/POINT ZOOM buttons on the remote control to navigate the Media Player menus. 1. Navigate to the [SETTINGS] icon and press SET/POINT ZOOM button. 2. Navigate to [AUTO PLAY] and press SET/POINT ZOOM button. 3.
Advanced Operation Chapter 5 This Chapter Includes: > “Creating a Power Schedule” on page 46 > “Advanced Color Adjustment” on page 47 > “Multi-Picture Mode” on page 54 > “Setting Security and Locking the Monitor Controls” on page 58 > “Media Player Settings” on page 62 English−45...
Creating a Power Schedule The schedule function allows the monitor to automatically change between power on and standby modes at different times. To program the scheduleN: 1. Enter the [SCHEDULE] menu. MULTI-INPUT OPTION C MODULE Highlight [SCHEDULE SETTINGS] using the and buttons. SCHEDULE: SETTINGS: SCHEDULE SETTINGS...
Advanced Color Adjustment The SpectraView Engine (SVE) is a custom color processor engine integrated in the monitor. It combines individual characterization and calibration of the monitor during production together with temperature and time monitoring, to provide an unparalleled level of color control, accuracy and stability. Adjustable color uniformity correction is available, utilizing detailed individual factory screen measurements together with the SVE to produce the best possible matching displays.
Page 52
5. Select a preset item at [PRESET]. Choose the [PRESET] that is most suitable for the type of content that is shown or application usage. Each [PICTURE MODE] includes [LUMINANCE], [BLACK] (Black level), [GAMMA], [WHITE (K)](color temperature ), [WHITE (x, y)](White point CIE x, y), [RED] (Red Primary CIE x, y), [GREEN] (Green Primary CIE x, y), and [BLUE] (Blue Primary CIE x, y), settings.
Page 53
DICOM GSDF (Grayscale Standard Display Function) is typically used for medical imaging. Programmable: A programmable gamma curve can be loaded using optional NEC software. Custom: Set a custom value for Peak luminance. CUSTOM VALUE: The gamma value is selected from a range from 0.5 to 4.0 in 0.1 steps.
• The original factory measurements can be recalled at any time. • Access to each monitor’s USB1 (SENSOR) port is necessary to use this feature with the NEC MDSVSENSOR3 color sensor. Be sure to provide adequate access when installing the monitors.
Page 55
This deletes the color measurement data created by the Self Calibration function and returns to the original factory internal reference color measurement data. All Picture Modes will automatically be updated. If you are using NEC display Wall Calibrator, uniformity adjustment data is also deleted.
Page 56
White copy* This function can be used to “copy” the luminance and white point from another monitor when used in a multi-monitor installation. This process is done by measuring the color of a monitor and setting those meaured values into the monitor being adjusted.
Using Other Picture Modes When the SpectraView Engine is off, the white point can be adjusted using familiar red, green and blue level controls. To turn SpectraView Engine off, see page 47 for instructions. There are different picture modes available when the SpectraView Engine is off. These picture modes have also been configured with settings for general use as described in the “Picture Mode Types”...
Multi-Picture Mode Multi-Picture mode lets you see video input from two different sources. The secondary input can be viewed in a inset window on the main video (Picture-In-Picture), or the two inputs can be viewed next to each other (Picture-By-Picture). The instructions in this section guide you through configuring Multi-Picture Mode in the monitor’s OSD menu.
Page 59
PBP (Picture-By-Picture) settingsN: 1. Navigate to [INPUT SELECT] on the OSD. • Select an input source for [PICTURE1] and [PICTURE2]. 2. Navigate to [ACTIVE PICTURE] on the OSD. • Select either [PICTURE1] or [PICTURE2]. The Picture Size, Position, and Aspect functions are configured separately for each input. •...
PIP (Picture-In-Picture) matrix The combination of input connections that can be used for PIP and PBP configuration are limited. If you do not see the input you want to use for the sub picture, refer to the tables below to see if your inputs configuration is supported. DisplayPort = 1.1a/HDMI = MODE1 Sub picture DisplayPort1 DisplayPort2...
Setting Security and Locking the Monitor Controls Under normal operation, the monitor can be controlled by any person using the remote control or the monitor control panel. You can prevent unauthorized use and changes to the monitor settings by enabling the options for Security and Lock Settings. The security and locking functions covered in this section are: •...
Set a password for the monitor This step is only required if you want to change the password. 1. Using the remote control navigate to [CONTROL] then to [CHANGE PASSWORD]. 2. Enter the password in the [CURRENT PASSWORD] field. (The default password is: 0 0 0 0). 3.
Page 64
Locking the IR Remote Buttons The [IR LOCK SETTINGS] prevent the monitor from being controlled using the remote control. Enabling the [IR LOCK SETTINGS] does not lock the buttons the monitor control panel. MULTI-INPUT OPTION C MODULE CONTROL: NETWORK INFORMATION MODE SELECT CUSTOM LOCK CHANGE PASSWORD...
Page 65
Locking the Control Panel Buttons The [KEY LOCK SETTINGS] prevent the monitor from being controlled using the buttons on the monitor Control Panel. Enabling the [KEY LOCK SETTINGS] does not lock the buttons on the remote control. MULTI-INPUT OPTION C MODULE CONTROL: NETWORK INFORMATION MODE SELECT...
Media Player Settings Change to the Media Player by pressing the MEDIA PLAYER button on the optional remote control, or select the MP input in the OSD INPUT menu. Use the + – and SET/POINT ZOOM buttons on the remote control to navigate the Media Player menus. Select the icon in the file list screen or home screen of the Media Player to display the configuration screen of the Media Player.
Preset Contents When the monitor has no current signal input, the monitor automatically changes to the Media Player input and plays any picture or video files in the selected folder. For example, when a device such a Blu-ray player powers off, the monitor changes input from HDMI to MP and plays the files in the folder selected in this screen.
Shared Folder Settings This option allows you to access shared network folders, from within the Media Player, to copy files to the microSD memory card. Up to four folders can be added to the Shared Folder settings. See page After opening the [SHARED FOLDER SETTINGS], select one of the folders then press SET/POINT ZOOM button to show the settings for configuring the network credentials.
Page 69
Using CONTENTS COPY in the Media Player When using the CONTENTS COPY option, the microSD memory card will be erased then the files will be copied from the selected folder. Copying Files to the microSD memory card 1. Either connect a USB storage device to the USB MP port on the monitor, or configure the [SHARED FOLDER SETTINGS] in the Media Player’s [NETWORK &...
Page 70
5. When the computer or mobile device successfully connects to the Media Player, the Media Player’s web controls are displayed in the browser. Select the SD-CARD VIEWER link on the left side of the browser window. 6. Press the Choose File button to open a file browser, then select a file. The file will be added to the root directory of the microSD memory card.
Page 71
SD-CARD VIEWER Web Controls Buttons 1. CHOOSE FILE Choose File opens a file browser to select a file to copy to the microSD memory card. Pressing Open in the file browser shows the upload window displaying the selected file. Pressing OK starts the file upload. NOTEN: Please check the microSD memory card storage capacity before copying files.
Connecting to a different monitor’s SD-CARD VIEWER If there is more than one monitor on the network that has a Media Player, you can search from any monitor’s main web controls to display all supported monitors on the network. 1. Input the monitor’s IP address in the web browser’s address field. Press the DISPLAY button on the remote control to show the monitor’s Information OSD on-screen, which displays the monitor’s IP address.
Multi-Monitor Setup Chapter 6 This Chapter Includes: > “Connecting Multiple Monitors” on page 70 > “Video Out Connection” on page 72 > “Setting the Remote Control ID Function” on page 73 English−69...
Connecting Multiple Monitors Monitors can be connected to each other, both communication and video connections, in multiple display installations. Chaining the video connections together creates a video wall where a single image can be tiled across all displays. When connecting multiple monitors to install a video wall, communication and video cable connections are necessary and their configuration must be carefully considered.
Page 75
3. With [H ADJUSMENT] and [V ADJUSTMENT], you can move the selected square to the exact spot where you display. 4. Select [YES] at [TILE MATRIX ANABLE]. For the right monitor: Repeat the same steps. e.g. Selecting 2 at [POSITION] •...
Setting the Remote Control ID Function The optional remote control can be used to control up to 100 individual MultiSync monitors using what is called the REMOTE CONTROL ID mode. The REMOTE CONTROL ID mode works in conjunction with the Monitor ID, allowing control of up to 100 individual MultiSync monitors.
Page 78
Use the remote control to operate a monitor that has a specific MONITOR ID number assigned to it. 1. Set the [MONITOR ID] number for the monitor (see page 115). The [MONITOR ID] number can range from 1-100. This [MONITOR ID] number allows the remote control to operate this specific monitor without affecting other monitors. 2.
> “Proof of Play” on page 89 Connecting external device There are two options to connect an external device to control the monitor. NEC Display Wall Calibrator or Naviset Administrator allows you to control the monitor settings and get the monitor status, including calibration information. •...
Connecting Interfaces RS-232C Interface PROTOCOL RS-232C BAUD RATE 9600 [bps] DATA LENGTH 8 [bits] PARITY NONE STOP BIT 1 [bit] FLOW CONTROL NONE LAN Interface PROTOCOL PORT NUMBER 7142 COMMUNICATION SPEED AUTO setting (10/100Mbps) Commands Control command The display supports two basic types of command formats: •...
Page 81
This monitor supports control command, which is listed in the “External_Control.pdf” (See page 100), but also supports common ASCII control command, which is used for controlling the NEC monitor or projector from a connected PC. For further information please visit our website. Parameter...
Supporting HDMI CEC Command Please connect a CEC supporting device to HDMI2 port. OSD menu HDMI CEC command name Explanation Setting One Touch Play When a CEC supported HDMI device is turned (Consumer on, the monitor connected to the device by an Electronics HDMI cable also automatically turns on.
Controlling the Monitor via RS-232C This monitor can be controlled by connecting a personal computer with an RS-232C (reverse type) terminal. For example, some of the functions that can be controlled by a personal computer are: • Power ON or standby. •...
PIN ASSIGNMENT RS-232C input/output Pin No Name D-SUB 9P (Monitor side) This monitor uses RXD, TXD and GND lines for RS-232C control. Controlling the Monitor via LAN Connecting to a Network Using a LAN cable allows you to specify the Network Settings and the Alert Mail Settings by using an HTTP server function. To use a LAN connection, you are required to assign an IP address.
Multiple Monitors Connection You can control multiple monitors by using RS-232C, REMOTE or LAN daisy-chain connection. NOTEN: • Up to 100 monitors can be daisy chained together. Please execute AUTO ID/IP to automatically assign unique IDs to each monitor (see page 115) before trying to control a monitor by manually specifying the ID number.
Example 1: When the host name of the monitor has been set to “pd.nec.co.jp”, access is gained to the network setting by specifying http://pd.nec.co.jp/index.html for the address or the entry column of the URL.
Operation Access the following address to show HOME. http://<the Monitor’s IP address>/index.html Click each link on the left column below HOME. REMOTE CONTROL Enable an operation to control the monitor equivalent to the keys on the remote control. OSD Menu Settings in the Monitor Web controls Select one of the links on the left side of the monitor web controls to configure the settings available in the monitor’s OSD.
Network Settings Click on “NETWORK” on the left column below HOME. IP SETTING Select an option for setting the IP ADDRESS. AUTO: Automatically assign an IP address. MANUAL: Manually set an IP address for the monitor connected to the network. NOTE: Consult your network administrator if you have any trouble.
Page 89
Mail Setting Click on “MAIL” on the left column below HOME. When the Mail settings are configured and enabled, the monitor sends email notifications when an error occurs or if the input signal is lost. The monitor must be connected to a LAN for this feature to work. Alert Mail When an error occurs, the monitor will send an error message to the email address(es) listed in the Recipient’s Address fields.
Page 90
SNMP Settings Click on “SNMP” on the left column below HOME. The SNMP protocol is used to get status information and to control a monitor directly via the network. VersionN: SNMP v1 Authenticated plaintext by community name, does not return a confirmation message of the trap. SNMP v2c Authenticated plaintext by community name, returns a confirmation message of the trap.
Page 91
CRESTRON Settings Click on “CRESTRON” on the left column below HOME. CRESTRON ROOMVIEW compatibility The monitor supports CRESTRON ROOMVIEW, allowing multiple devices connected in the network to be managed and controlled from a computer or a controller. For further information, visit http://www.crestron.com ROOMVIEW ROOMVIEW for managing from the computer.
[INTELLI.WIRELESS DATA], and the wireless app must be installed on a compatible mobile device. This function is enabled by default. At this time, the mobile application is only available for Android devices. Please refer to the NEC website for more information. NOTEN: •...
Proof of Play This function allows sending of messages for the current status of the monitor by self-diagnosis. For the Proof of Play function including self-diagnosis, please see the “External_Control.pdf”. See page 100. Check item Message INPUT DVI, DisplayPort1, DisplayPort2, HDMI1, HDMI2, OPTION*, MP, VGA (RGB/YPbPr), VIDEO ...
Page 94
Troubleshooting Chapter 8 This Chapter Includes: > “Screen Image and Video Signal Issues” on page 91 > “Hardware Issues” on page 92 > “Image Persistence” on page 94 English−90...
Page 95
Check the signal cable connector for bent or pushed-in power off for one hour to erase the image. pins. NOTEN: As with all personal display devices, NEC DISPLAY • The monitor automatically goes into standby at the SOLUTIONS recommends displaying moving preset time period after the video signal is lost.
The image is unstable, unfocused or swimming is The image of component signal is greenish apparent • Check to see if the VGA (YPbPr) input connector is selected. • The signal cable should be completely attached to the computer. The image is not properly reproduced •...
Page 97
The USB Hub does not operate The monitor goes into standby automatically • Check to make sure that the USB cable is properly • Please check [OFF TIMER] setting. connected. Refer to your USB device user’s manual. • Set the [CEC] function to [OFF]. The monitor may go into •...
As with all personal display devices, NEC DISPLAY SOLUTIONS recommends displaying moving images and using a moving screen saver at regular intervals whenever the screen is idle, or turn off the monitor’s main power or set it to standby when not in use.
Specifications Chapter 9 This Chapter Includes: > “UN462A” on page 96 > “UN462VA” on page 97 > “UN552S” on page 98 > “UN552VS” on page 99 [Notice] About the MPEG-4 AVC, MPEG-4 Visual license included in this product 1. MPEG AVC THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL USE OF A CONSUMER OR OTHER USES IN WHICH IT DOES NOT RECEIVE REMUNERATION TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN...
Module, which is an optional component available for this model. The required DS1-IF10CE Compute Module Interface Board and Raspberry Pi Compute Module are available separately. Please contact an authorized NEC dealer or visit the NEC Display Solutions website in your region for purchase information and availability. This document can be downloaded from: https://www.nec-display.com/dl/en/manual/raspberrypi/...
Page 105
This customized X-Rite color sensor is required when using the stand-alone Color Calibration functions of this monitor, and can also be used with the NEC Display Wall Calibrator software listed above. Please contact an authorized NEC dealer or see the NEC Display Solutions website in your region for purchase information and availability.
OSD Controls List Appendix B This Chapter Includes > “INPUT” on page 103 > “PICTURE” on page 103 > “AUDIO” on page 108 > “SCHEDULE” on page 108 > “MULTI-INPUT” on page 110 > “OSD” on page 112 > “MULTI-DISPLAY” on page 113 >...
INPUT INPUT MENU Selects the input signals source. HDMI1 HDMI2 DisplayPort1 DisplayPort2 VGA (RGB/YPbPr) VIDEO COMPUTE MODULE* OPTION* : This function is only available when Raspberry Pi Compute Module Interface Board and Raspberry Pi Compute Module are installed. See page 100.
Page 108
Gamma setting for HDR, typically for UHD broadcasting. System gamma can be adjusted. PROGRAMMABLE1, 2, 3 A programmable gamma curve can be loaded using optional NEC software. AUTO HDR SELECT GAMMA correction of HDR signal automatically changes to [HDR-ST2084 (PQ)] or [HDR-Hybrid Log].
Page 109
PICTURE MENU COLOR *2, *3 COLOR Adjusts the color depth of the screen. Press + or - button to adjust. COLOR TEMPERATURE Adjusts the color temperature of the entire screen. A low color temperature will result in a reddish screen. A high color temperature will make the screen bluish.
Page 110
PICTURE MENU ASPECT Select the aspect ratio of the screen image. NOTE: • When selecting an image flip option with the [ASPECT] set to [DYNAMIC], the aspect will automatically change to [FULL]. Aspect will return to [DYNAMIC] after [NONE] is set to the [IMAGE FLIP].
Page 111
PICTURE MENU DEINTERLACE Selects the IP (Interlace to Progressive) conversion function. NOTE: • [IMAGE FLIP] is not available. • When [SUPER] is selected in [INPUT CHANGE] and displayed, this function cannot be changed. Converts interlaced signals to progressive. This is the default setting. Disables IP conversion.
AUDIO AUDIO MENU VOLUME Increase or decrease output volume level. BALANCE Select [STEREO] or [MONO] for the audio output. BALANCE Adjusts the volume balance between the LEFT and RIGHT speakers when [STEREO] is selected. Press the + button to move the stereo sound image to right. Press the - button to move the stereo sound image to left.
Page 113
SCHEDULE MENU INPUT Select which video input to use for the schedule. To keep the active input when the schedule starts, make sure the setting is [--]. If you do select a specific input, set [ON] at [POWER]. PIC. MODE Select the picture mode to use for the schedule.
SCHEDULE MENU OFF TIMER Set the monitor to power off after a preset time period. A time period between 1 to 24 hours may be set. NOTE: [SCHEDULE] is not available if [OFF TIMER] is [ON]. RESET Resets all SCHEDULE options back to factory setting, except for [DATE & TIME] and [DAYLIGHT SAVING]. MULTI-INPUT MULTI-INPUT MENU KEEP MULTI PICTURE...
Page 115
MULTI-INPUT MENU INPUT DETECT Selects the method of input detection the monitor uses when more than one signal source is connected. NOTE: • When SUPER is selected within [INPUT CHANGE], this function cannot be changed. • [INPUT DETECT] is released if [HUMAN SENSOR] is activated while [INPUT DETECT] is active. NONE The Monitor will not search for signals at the other video input ports.
MULTI-INPUT MENU BIT RATE DisplayPort 1.1a is selected at DisplayPort, [HBR] is set automatically. DisplayPort1.2 and SST are selected at DisplayPort, set [HBR] or [HBR2]. DisplayPort1.2 and MST are selected at DisplayPort, [HBR2] is set automatically. HDMI Selects [MODE1] or [MODE2]. MODE1: Max resolution is 3840 x 2160 (30 Hz) MODE2: Max resolution is 3840 x 2160 (60 Hz), HDCP2.2, or HDR VIDEO LEVEL...
The number of monitors that the settings can be copied to may be reduced based on the quality of the LAN cables being used. Please see the “Setting copy.pdf” file on the NEC website. COPY START Select [YES] and press the SET/POINT ZOOM button to start copying.
Page 118
MULTI-DSP MENU TILE MATRIX Allows one image to be expanded and displayed over multiple screens (up to 100) through a distribution amplifier. NOTE: • Low resolution is not suitable for tiling to a large number of monitors. • You can operate without a distribution amplifier at a lower number of screens. When [TILE MATRIX] is active the following functions are not available: [MULTI PICTURE MODE], [TEXT TICKER], [CLOSED CAPTION], [STILL], [POINT ZOOM].
Page 119
MULTI-DSP MENU ID CONTROL Sets the monitor ID number from 1-100 and group ID from A-J. [DETECTED MONITORS] shows the number of all monitors that are included in the daisy chain of connected LAN cables. [MONITOR ID] is used for the conditions: •...
DISPLAY PROTECTION PROTECT MENU POWER SAVE Set [ENABLE] or [DISABLE]. If you set it to [ENABLE], set how long the monitor waits to go into power save mode after signal is lost. For more details please check the Power Indicator (see page 93).
CONTROL CONTROL MENU NETWORK INFORMATION Shows the current network settings. NOTE: When changing any LAN settings, you need to wait several seconds until modified LAN settings are applied. IP SETTING Enabling this option automatically assigns an IP address to the monitor from your DHCP server. Disabling this option allows you to enter a fixed IP address and subnet mask data obtained from your network administrator.
Page 122
CONTROL MENU IR LOCK SETTINGS Prevents the monitor from being controlled by the wireless remote control. When [ACTIVATE] is selected, all settings are activated. NOTE: • [IR LOCK SETTINGS] is a function intended only for the wireless remote control buttons. This function does not lock out access to the buttons on the monitor.
Page 123
CONTROL MENU DDC/CI ENABLE/DISABLE: Turns [ON] or [OFF] the two-way communication and control of the monitor. DisplayPort2, DVI, VGA (RGB) Inputs only PING Confirm successful connection with the network by communicating with a preset IP address. IP ADDRESS Sets an [IP ADDRESS] for sending [PING]. EXECUTE Checks a reply can be sent to the monitor or not from the [IP ADDRESS] by sending [PING].
Page 124
CONTROL MENU HUMAN SENSING [HUMAN SENSING] has three settings. NOTE: [POWER SAVE] is disabled when [AUTO OFF] or [CUSTOM] is selected in [HUMAN SENSING]. [HUMAN SENSING] is released if [INPUT DETECT] is set while [HUMAN SENSING] is active. DISABLE No human sensing. AUTO OFF At the preset time, when no person is detected, [BACKLIGHT] and [VOLUME] automatically go into [OFF].
Page 125
CONTROL MENU This function enables you to control the HDMI CEC compliant device connected via HDMI connector. Please connect a device to the HDMI2 (CEC) port. (CEC is an abbreviation of Consumer Electronics Control). When [ON] is set, the connected HDMI CEC devices are controlled by the wireless remote control (option). Please set items below.
OPTION MENU SLOT2 CH SELECT This function is available only when [SLOT2 CH SETTING] is [1CH]. DisplayPort Shows the DisplayPort signal from a slot 2 type PC option on the full screen. TMDS Shows the [TMDS] signal from a slot 2 type PC option on the full screen. RESET Resets the [AUDIO] setting back to the factory setting within the OPTION menu.
Page 127
> “WEEE Mark (European Directive 2012/19/EU and amendments)” on page 124 NEC DISPLAY SOLUTIONS is strongly committed to environmental protection and sees recycling as one of the company’s top priorities in trying to minimize the burden placed on the environment. We are engaged in developing...
Dedicated recycling sites ensure that environmentally harmful components are properly handled and securely disposed. To ensure the best recycling of our products, NEC DISPLAY SOLUTIONS offers a variety of recycling procedures and gives advice on how to handle the product in an environmentally sensitive way, once it has reached the end of its life.
