Configuration and Use Manual
MMI-20019043, Rev AA
March 2012
®
Micro Motion
Model 2700 Transmitters with
Analog Outputs
Configuration and Use Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Micro Motion 2700 and is the answer not in the manual?

Questions and answers

Related Manuals for Emerson Micro Motion 2700

Summary of Contents for Emerson Micro Motion 2700

  • Page 1 Configuration and Use Manual MMI-20019043, Rev AA March 2012 ® Micro Motion Model 2700 Transmitters with Analog Outputs Configuration and Use Manual...
  • Page 2 Safety messages are provided throughout this manual to protect personnel and equipment. Read each safety message carefully before proceeding to the next step. Micro Motion customer service Location Telephone number Email U.S.A. 800-522-MASS (800-522-6277) (toll free) flow.support@emerson.com Canada and Latin America +1 303-527-5200 (U.S.A.) Asia Japan 3 5769-6803 All other locations +65 6777-8211 (Singapore) Europe U.K.

  • Page 3: Table Of Contents

    Contents Contents Part I Getting Started Chapter 1 Before you begin ......................3 About this manual .........................3 Transmitter model code ........................3 Communications tools and protocols ....................3 Additional documentation and resources ..................4 Chapter 2 Quick start ........................7 Power up the transmitter .......................7 Check flowmeter status .........................7 Make a startup connection to the transmitter ................9 Characterize the flowmeter (if required) ..................10...
  • Page 4 Contents Configure density measurement ....................45 4.5.1 Configure Density Measurement Unit ................46 4.5.2 Configure slug flow parameters ..................47 4.5.3 Configure Density Damping ..................48 4.5.4 Configure Density Cutoff ....................50 Configure temperature measurement ..................50 4.6.1 Configure Temperature Measurement Unit ..............51 4.6.2 Configure Temperature Damping .................51 Configure the petroleum measurement application ..............53...
  • Page 5 Contents 5.6.6 Configure Sensor Liner Material ..................97 5.6.7 Configure Sensor Flange Type ..................98 Chapter 6 Integrate the meter with the control system ..............99 Configure the transmitter channels .....................99 Configure the mA output ......................100 6.2.1 Configure mA Output Process Variable ...............100 6.2.2 Configure Lower Range Value (LRV) and Upper Range Value (URV) ......102 6.2.3...
  • Page 6 Contents 9.4.3 View and acknowledge alerts using ProLink III .............156 9.4.4 View alarms using the Field Communicator ..............156 9.4.5 Alarm data in transmitter memory ................157 Read totalizer and inventory values ...................157 Start and stop totalizers and inventories ..................158 9.6.1 Start and stop totalizers and inventories using the display ..........158 Reset totalizers ..........................160 9.7.1 Reset totalizers using the display ................160...
  • Page 7 Contents 12.3 Flow measurement problems ....................220 12.4 Density measurement problems ....................222 12.5 Temperature measurement problems ..................223 12.6 Milliamp output problems ......................224 12.7 Frequency output problems ......................225 12.8 Use sensor simulation for troubleshooting ................226 12.9 Check power supply wiring ......................227 12.10 Check sensor-to-transmitter wiring ...................227 12.11 Check grounding ........................228 12.12 Perform loop tests ........................228 12.12.1 Perform loop tests using the display ................228...
  • Page 8 Contents B.2.2 Make a service port connection ...................275 B.2.3 Make a HART/Bell 202 connection ................276 B.2.4 Make a HART/RS-485 connection ................281 B.2.5 Make a Modbus/RS-485 connection ................284 Menu maps for ProLink II ......................287 Appendix C Using ProLink III with the transmitter ................297 Basic information about ProLink III .....................297 Connect with ProLink III ......................298 C.2.1...

  • Page 9: Part I Getting Started

    Getting Started Part I Getting Started Chapters covered in this part: • Before you begin • Quick start Configuration and Use Manual...
  • Page 10 Getting Started ® Micro Motion Model 2700 Transmitters with Analog Outputs...

  • Page 11: Before You Begin

    Before you begin Before you begin Topics covered in this chapter: • About this manual • Transmitter model code • Communications tools and protocols • Additional documentation and resources About this manual This manual provides information to help you configure, commission, use, maintain, and troubleshoot the Micro Motion Model 2700 transmitter.

  • Page 12: Additional Documentation And Resources

    Appendix Micro Motion web site (www.micromo- tion.com You may be able to use other communications tools from Emerson Process Management, such as ™ AMS Suite: Intelligent Device Manager, or the Smart Wireless THUM Adapter. Use of AMS or the Smart Wireless THUM Adapter is not discussed in this manual. The AMS interface is similar to the ProLink II interface.
  • Page 13 Before you begin Table 1-2: Additional documentation and resources (continued) Topic Document Transmitter installation Micro Motion Model 1700 and Model 2700 Transmitters: Installation Manual Hazardous area installa- See the approval documentation shipped with the transmitter, or tion download the appropriate documentation from the Micro Motion web site at www.micromotion.com.
  • Page 14 Before you begin ® Micro Motion Model 2700 Transmitters with Analog Outputs...

  • Page 15: Chapter 2 Quick Start

    Quick start Quick start Topics covered in this chapter: • Power up the transmitter • Check flowmeter status • Make a startup connection to the transmitter • Characterize the flowmeter (if required) • Verify mass flow measurement • Verify the zero Power up the transmitter The transmitter must be powered up for all configuration and commissioning tasks, or for process measurement.
  • Page 16 Quick start Wait approximately 10 seconds for the power-up sequence to complete. Immediately after power-up, the transmitter runs through diagnostic routines and checks for error conditions. During the power-up sequence, Alarm A009 is active. This alarm should clear automatically when the power-up sequence is complete. Check the status LED on the transmitter.

  • Page 17: Make A Startup Connection To The Transmitter

    Quick start Make a startup connection to the transmitter For all configuration tools except the display, you must have an active connection to the transmitter to configure the transmitter. Follow this procedure to make your first connection to the transmitter. Identify the connection type to use, and follow the instructions for that connection type in the appropriate appendix.

  • Page 18: Characterize The Flowmeter (If Required)

    Quick start Characterize the flowmeter (if required) Display Not available ProLink II • ProLink > Configuration > Device > Sensor Type • ProLink > Configuration > Flow • ProLink > Configuration > Density • ProLink > Configuration > T Series ProLink III Device Tools >...
  • Page 19 Quick start • Older curved-tube sensors (all sensors except T-Series): see Figure 2-1 • Newer curved-tube sensors (all sensors except T-Series): see Figure 2-2 • Older straight-tube sensors (T-Series): see Figure 2-3 • Newer straight-tube sensors (T-Series): see Figure 2-4 Figure 2-1: Tag on older curved-tube sensors (all sensors except T-Series) Figure 2-2:...
  • Page 20 Quick start Figure 2-3: Tag on older straight-tube sensor (T-Series) Figure 2-4: Tag on newer straight-tube sensor (T-Series) Density calibration parameters (D1, D2, K1, K2, FD, DT, TC) If your sensor tag does not show a D1 or D2 value: •...

  • Page 21: Verify Mass Flow Measurement

    Quick start If your sensor tag does not show a DT or TC value, enter the last 3 digits of the density calibration factor. In the sample tag, this value is shown as 4.44 (see Figure 2-1). Flow calibration parameters (FCF, FT) Two separate values are used to describe flow calibration: a 6-character FCF value and a 4- character FT value.

  • Page 22: Verify The Zero

    Quick start • Review the troubleshooting suggestions for flow measurement issues. See Section 12.3. Verify the zero Verifying the zero helps you determine if the stored zero value is appropriate to your installation, or if a field zero can improve measurement accuracy. The zero verification procedure analyzes the Live Zero value under conditions of zero flow, and compares it to the Zero Stability range for the sensor.

  • Page 23: Verify The Zero Using Prolink Iii

    Quick start If the zero verification procedure fails: a. Confirm that the sensor is completely blocked in, that flow has stopped, and that the sensor is completely full of process fluid. b. Verify that the process fluid is not flashing or condensing, and that it does not contain particles that can settle out.

  • Page 24: Terminology Used With Zero Verification And Zero Calibration

    Quick start If the zero verification procedure fails: a. Confirm that the sensor is completely blocked in, that flow has stopped, and that the sensor is completely full of process fluid. b. Verify that the process fluid is not flashing or condensing, and that it does not contain particles that can settle out.

  • Page 25: Part Ii Configuration And Commissioning

    Configuration and commissioning Part II Configuration and commissioning Chapters covered in this part: • Introduction to configuration and commissioning • Configure process measurement • Configure device options and preferences • Integrate the meter with the control system Completing the configuration •...
  • Page 26 Configuration and commissioning ® Micro Motion Model 2700 Transmitters with Analog Outputs...

  • Page 27: Introduction To Configuration And Commissioning

    Introduction to configuration and commissioning Introduction to configuration and commissioning Topics covered in this chapter: • Configuration flowchart • Default values and ranges • Enable access to the off-line menu of the display • Disable write-protection on the transmitter configuration •...
  • Page 28 Introduction to configuration and commissioning Figure 3-1: Configuration flowchart Configure device options and Test and move to production Configure process measurement preferences Configure mass flow Test or tune transmitter Configure display measurement using sensor simulation parameters Configure volume flow meaurement Configure fault handling Back up transmitter parameters...

  • Page 29: Default Values And Ranges

    Introduction to configuration and commissioning Default values and ranges Section E.1 to view the default values and ranges for the most commonly used parameters. Enable access to the off-line menu of the display Display OFF-LINE MAINT > OFF-LINE CONFG > DISPLAY ProLink II ProLink >...

  • Page 30: Restore The Factory Configuration

    Introduction to configuration and commissioning Write-protecting the transmitter prevents accidental changes to configuration. It does not prevent normal operational use. You can always disable write-protection, perform any required configuration changes, then re-enable write-protection. Restore the factory configuration Display Not available ProLink II ProLink >...

  • Page 31: Configure Process Measurement

    Configure process measurement Configure process measurement Topics covered in this chapter: • Configure mass flow measurement • Configure volume flow measurement for liquid applications • Configure gas standard volume (GSV) flow measurement • Configure Flow Direction • Configure density measurement •...
  • Page 32 Configure process measurement If the measurement unit you want to use is not available, you can define a special measurement unit. Options for Mass Flow Measurement Unit The transmitter provides a standard set of measurement units for Mass Flow Measurement Unit, plus one user-defined special measurement unit.
  • Page 33 Configure process measurement Define a special measurement unit for mass flow Display Not available ProLink II ProLink > Configuration > Special Units ProLink III Device Tools > Configuration > Process Measurement > Flow > Special Units Field Communicator Configure > Manual Setup > Measurements > Special Units > Mass Special Units Overview A special measurement unit is a user-defined unit of measure that allows you to report process data, totalizer data, and inventory data in a unit that is not available in the...

  • Page 34: Configure Flow Damping

    Configure process measurement a. 1 lb/sec = 16 oz/sec b. Mass Flow Conversion Factor = 1/16 = 0.0625 Set Mass Flow Conversion Factor to 0.0625. Set Mass Flow Label to oz/sec. Set Mass Total Label to oz. 4.1.2 Configure Flow Damping Display Not available ProLink II...

  • Page 35: Configure Mass Flow Cutoff

    Configure process measurement • In general, lower damping values are preferable because there is less chance of data loss, and less lag time between the actual measurement and the reported value. • For gas applications, Micro Motion recommends setting Flow Damping to 2.56 or higher. The value you enter is automatically rounded down to the nearest valid value.
  • Page 36 Configure process measurement Procedure Set Mass Flow Cutoff to the value you want to use. The default value for Mass Flow Cutoff is 0.0 g/sec or a sensor-specific value set at the factory. The recommended setting is 0.05% of the sensor's rated maximum flow rate or a value below the highest expected flow rate.

  • Page 37: Configure Volume Flow Measurement For Liquid Applications

    Configure process measurement The frequency output will report the actual flow rate, and the actual flow rate will be used in all internal processing. • If the mass flow rate drops below 10 g/sec, both outputs will report zero flow, and 0 will be used in all internal processing.

  • Page 38: Configure Volume Flow Measurement Unit For Liquid Applications

    Configure process measurement Procedure Set Volume Flow Type to Liquid. 4.2.2 Configure Volume Flow Measurement Unit for liquid applications Display OFF-LINE MAINT > OFF-LINE CONFG > UNITS > VOL ProLink II ProLink > Configuration > Flow > Vol Flow Units ProLink III Device Tools >...
  • Page 39 Configure process measurement Table 4-3: Options for Volume Flow Measurement Unit for liquid applications (continued) Label Unit description Display ProLink II ProLink III Field Communica- CUFT/H ft3/hr ft3/hr Cuft/h Cubic feet per hour CUFT/D ft3/day ft3/day Cuft/d Cubic feet per day M3/S m3/sec m3/sec...
  • Page 40 Configure process measurement Define a special measurement unit for volume flow Display Not available ProLink II ProLink > Configuration > Special Units ProLink III Device Tools > Configuration > Process Measurement > Flow > Special Units Field Communicator Configure > Manual Setup > Measurements > Special Units > Volume Special Units Overview A special measurement unit is a user-defined unit of measure that allows you to report process data, totalizer data, and inventory data in a unit that is not available in the...

  • Page 41: Configure Volume Flow Cutoff

    Configure process measurement a. 1 gal/sec = 8 pints/sec b. Volume Flow Conversion Factor = 1/8 = 0.1250 Set Volume Flow Conversion Factor to 0.1250. Set Volume Flow Label to pints/sec. Set Volume Total Label to pints. 4.2.3 Configure Volume Flow Cutoff Display Not available ProLink II...

  • Page 42: Configure Gas Standard Volume (Gsv) Flow Measurement

    Configure process measurement Result: If the volume flow rate drops below 15 l/sec, volume flow will be reported as 0, and 0 will be used in all internal processing. Example: Cutoff interaction with AO Cutoff higher than Volume Flow Cutoff Configuration: •...

  • Page 43: Configure Volume Flow Type For Gas Applications

    Configure process measurement 4.3.1 Configure Volume Flow Type for gas applications Not available Display ProLink II ProLink > Configuration > Flow > Vol Flow Type ProLink III Device Tools > Configuration > Process Measurement > Flow Field Communicator Configure > Manual Setup > Measurements > GSV > Volume Flow Type > Standard Gas Volume Overview Volume Flow Type controls whether liquid or gas standard volume flow measurement is used.

  • Page 44: Configure Gas Standard Volume Flow Measurement Unit

    Configure process measurement Procedure Set Standard Gas Density to the standard reference density of the gas you are measuring. Note ProLink II and ProLink III provide a guided method that you can use to calculate the standard density of your gas, if you do not know it. 4.3.3 Configure Gas Standard Volume Flow Measurement Unit Display...
  • Page 45 Configure process measurement Table 4-4: Options for Gas Standard Volume Measurement Unit Label Unit description Display ProLink II ProLink III Field Communica- NM3/S Nm3/sec Nm3/sec Nm3/sec Normal cubic meters per sec- NM3/MN Nm3/min Nm3/sec Nm3/min Normal cubic meters per mi- nute NM3/H Nm3/hr...
  • Page 46 Configure process measurement Overview A special measurement unit is a user-defined unit of measure that allows you to report process data, totalizer data, and inventory data in a unit that is not available in the transmitter. A special measurement unit is calculated from an existing measurement unit using a conversion factor.

  • Page 47: Configure Gas Standard Volume Flow Cutoff

    Configure process measurement 4.3.4 Configure Gas Standard Volume Flow Cutoff Not available Display ProLink II ProLink > Configuration > Flow > Std Gas Vol Flow Cutoff ProLink III Device Tools > Configuration > Process Measurement > Flow Field Communicator Configure > Manual Setup > Measurements > GSV > GSV Cutoff Overview Gas Standard Volume Flow Cutoff specifies the lowest gas standard volume flow rate that will reported as measured.

  • Page 48: Configure Flow Direction

    Configure process measurement Example: Cutoff interaction with AO Cutoff higher than Gas Standard Volume Flow Cutoff Configuration: • mA Output Process Variable for the primary mA output: Gas Standard Volume Flow Rate • Frequency Output Process Variable: Gas Standard Volume Flow Rate •...

  • Page 49: Options For Flow Direction

    Configure process measurement 4.4.1 Options for Flow Direction Table 4-5: Options for Flow Direction Flow Direction setting Relationship to Flow Direction ar- row on sensor ProLink II ProLink III Field Communicator Forward Forward Forward Appropriate when the Flow Direction arrow is in the same direction as the majority of flow.
  • Page 50 Configure process measurement Figure 4-1: Effect of Flow Direction on the mA output: Lower Range Value = 0 Flow Direction = Forward Flow Direction = Reverse, Negate Forward Flow Direction = Absolute Value, Bidirectional, Negate Bidirectional Reverse flow Forward flow Reverse flow Forward flow Reverse flow...
  • Page 51 Configure process measurement • Under conditions of reverse flow or zero flow, the mA output is 4 mA. • Under conditions of forward flow, up to a flow rate of 100 g/sec, the mA output varies between 4 mA and 20 mA in proportion to the flow rate. •...
  • Page 52 Configure process measurement Effect of Flow Direction on frequency outputs Flow Direction affects how the transmitter reports flow values via the frequency outputs. The frequency outputs are affected by Flow Direction only if Frequency Output Process Variable is set to a flow variable. Table 4-6: Effect of the Flow Direction parameter and actual flow direction on frequency outputs...

  • Page 53: Configure Density Measurement

    Configure process measurement Table 4-8: Effect of the Flow Direction parameter and actual flow direction on flow values reported via digital communications Flow Direction setting Actual flow direction Forward Zero flow Reverse Forward Positive Negative Reverse Positive Negative Bidirectional Positive Negative Absolute Value Positive...

  • Page 54: Configure Density Measurement Unit

    Configure process measurement 4.5.1 Configure Density Measurement Unit Display OFF-LINE MAINT > OFF-LINE CONFG > UNITS > DENS ProLink II ProLink > Configuration > Density > Density Units ProLink III Device Tools > Configuration > Process Measurement > Density Field Communicator Configure > Manual Setup > Measurements > Density > Density Unit Overview Density Measurement Unit specifies the units of measure that will be displayed for density measurement.

  • Page 55: Configure Slug Flow Parameters

    Configure process measurement 4.5.2 Configure slug flow parameters Not available Display ProLink II • ProLink > Configuration > Density > Slug High Limit • ProLink > Configuration > Density > Slug Low Limit • ProLink > Configuration > Density > Slug Duration ProLink III Device Tools >...

  • Page 56: Configure Density Damping

    Configure process measurement The default value for Slug High Limit is 5.0 g/cm . The range is 0.0 to 10.0 g/cm Set Slug Duration to the number of seconds that the transmitter will wait for a slug flow condition to clear before performing the configured slug flow action. The default value for Slug Duration is 0.0 seconds.
  • Page 57 Configure process measurement Overview Damping is used to smooth out small, rapid fluctuations in process measurement. Damping Value specifies the time period (in seconds) over which the transmitter will spread changes in the reported process variable. At the end of the interval, the reported process variable will reflect 63% of the change in the actual measured value.

  • Page 58: Configure Density Cutoff

    Configure process measurement Interaction between Density Damping and Added Damping In some circumstances, both Density Damping and Added Damping are applied to the reported density value. Density Damping controls the rate of change in the density process variable. Added Damping controls the rate of change reported via the mA output.

  • Page 59: Configure Temperature Measurement Unit

    Configure process measurement 4.6.1 Configure Temperature Measurement Unit Display OFF-LINE MAINT > OFF-LINE CONFG > UNITS > TEMP ProLink II ProLink > Configuration > Temperature > Temp Units ProLink III Device Tools > Configuration > Process Measurement > Temperature Field Communicator Configure > Manual Setup > Measurements > Temperature > Temperature Unit Overview Temperature Measurement Unit specifies the unit that will be used for temperature measurement.
  • Page 60 Configure process measurement Overview Damping is used to smooth out small, rapid fluctuations in process measurement. Damping Value specifies the time period (in seconds) over which the transmitter will spread changes in the reported process variable. At the end of the interval, the reported process variable will reflect 63% of the change in the actual measured value.

  • Page 61: Configure The Petroleum Measurement Application

    Configure process measurement Configure the petroleum measurement application The petroleum measurement application enables Correction for the effect of Temperature on the volume of Liquids (CTL), by calculating and applying a Volume Correction Factor (VCF) to volume measurement. Internal calculations are performed in compliance with American Petroleum Institute (API) standards.

  • Page 62: Configure Petroleum Measurement Using Prolink Iii

    Configure process measurement Option Setup Polling for tempera- a. Ensure that the primary mA output has been wired to support ture HART polling. b. Choose View > Preferences . c. Enable Use External Temperature. d. Choose ProLink > Configuration > Polled Variables. e.
  • Page 63 Configure process measurement Set Temperature Source to the method that the transmitter will use to obtain temperature data. Option Description Poll for external value The transmitter will poll an external temperature device, us- ing HART protocol over the primary mA output. The transmitter will use the temperature data from the sen- sor.

  • Page 64: Configure Petroleum Measurement Using The Field Communicator

    Configure process measurement 4.7.3 Configure petroleum measurement using the Field Communicator Choose Online > Configure > Manual Setup > Measurements > Set Up Petroleum. Specify the API table to use. a. Open the Petroleum Measurement Source menu and select the API table number.

  • Page 65: Api Reference Tables

    Configure process measurement Option Setup A value written by a. Choose Online > Configure > Manual Setup > Measurements > External digital communica- Pressure/Temperature > Temperature. tions b. Set External Temperature to Enabled. c. Perform the necessary host programming and communications setup to write temperature data to the transmitter at appropri- ate intervals.

  • Page 66: Configure The Concentration Measurement Application

    Configure process measurement Table 4-13: API reference tables, associated process fluids, and associated calculation values (continued) Table name Process fluid CTL source data Reference temperature Density unit Generalized products Observed density and 15 °C (configurable) Base density observed temperature Range: 653 to 1075 kg/m Lubricating oils Observed density and...
  • Page 67 Configure process measurement • The concentration measurement application must be enabled on your transmitter. • The concentration matrix you want to use must be available on your transmitter, or it must be available as a file on your computer. • You must know the derived variable that your matrix is designed for.
  • Page 68 Configure process measurement Restriction The high and low limit alarms require the enhanced core processor. Example: If Alarm Limit is set to 5%, Enable Temp High is checked, and the matrix is built for a temperature range of 40 °F to 80 °F, an extrapolation alarm will be posted if process temperature goes above 82 °F Select the label that will be used for the concentration unit.

  • Page 69: Configure Concentration Measurement Using Prolink Iii

    Configure process measurement Option Setup A value written by a. Choose View > Preferences . digital communica- b. Enable Use External Temperature. tions c. Perform the necessary host programming and communications setup to write temperature data to the transmitter at appropri- ate intervals.
  • Page 70 Configure process measurement Choose Device Tools > Configuration > Process Measurement > Concentration Measurement. Set Derived Variable to the derived variable that your matrix is designed for, and click Apply. Important • All concentration matrices on your transmitter must use the same derived variable. If you are using one of the standard matrices from Micro Motion, set Derived Variable to Mass Concentration (Density).
  • Page 71 Configure process measurement Restriction The high and low limit alarms require the enhanced core processor. Example: If Extrapolation Alarm Limit is set to 5%, High Extrapolation Limit (Temperature) is enabled, and the matrix is built for a temperature range of 40 °F to 80 °F, an extrapolation alarm will be posted if process temperature goes above 82 °F Set Temperature Source to the method that the transmitter will use to obtain temperature data.

  • Page 72: Configure Concentration Measurement Using The Field Communicator

    Configure process measurement Set Active Matrix to the matrix to be used for measurement. Concentration process variables are now available on the transmitter. You can view and report them in the same way that you view and report other process variables. 4.8.3 Configure concentration measurement using the Field Communicator...
  • Page 73 Configure process measurement d. Choose Online > Configure > Alert Setup > CM Alerts. e. Enable or disable the high and low limit alarms for temperature and density, as desired. Restriction The high and low limit alarms require the enhanced core processor. Example: If Alarm Limit is set to 5%, the high-temperature extrapolation alert is enabled, and the matrix is built for a temperature range of 40 °F to 80 °F, an extrapolation alarm will be posted if process temperature goes above 82 °F...

  • Page 74: Standard Matrices For The Concentration Measurement Application

    Configure process measurement Option Setup Polling for tempera- a. Ensure that the primary mA output has been wired to support ture HART polling. b. Choose Online > Configure > Manual Setup > Measurements > External Pressure/Temperature > Temperature. c. Enable External Temperature. d.

  • Page 75: Derived Variables And Calculated Process Variables

    Configure process measurement If the standard matrices are not appropriate for your application, you can build a custom matrix or purchase a custom matrix from Micro Motion. Table 4-14: Standard concentration matrices and associated measurement units Temperature Concentration Matrix name Description Density unit unit...
  • Page 76 Configure process measurement Table 4-15: Derived variables and calculated process variables Calculated process variables Density at reference Standard Net vol- Derived Variable Description tempera- volume Specific Concen- Net mass ume flow ture flow rate gravity tration flow rate rate ✓ ✓...

  • Page 77: Configure Pressure Compensation

    Configure process measurement Table 4-15: Derived variables and calculated process variables (continued) Calculated process variables Density at reference Standard Net vol- Derived Variable Description tempera- volume Specific Concen- Net mass ume flow ture flow rate gravity tration flow rate rate ✓...
  • Page 78 Configure process measurement The flow factor is the percent change in the flow rate per PSI. When entering the value, reverse the sign. Example: If the flow factor is 0.000004 % per PSI, enter −0.000004 % per PSI. Enter Density Factor for your sensor. The density factor is the change in fluid density, in g/cm /PSI.

  • Page 79: Configure Pressure Compensation Using Prolink Iii

    Configure process measurement Option Setup A value written by a. Set Pressure Units to the desired unit. digital communica- b. Perform the necessary host programming and communications tions setup to write pressure data to the transmitter at appropriate in- tervals. Note If the Weights &...
  • Page 80 Configure process measurement The density factor is the change in fluid density, in g/cm /PSI. When entering the value, reverse the sign. Example: /PSI, enter −0.000006 g/cm3/PSI. If the density factor is 0.000006 g/cm Set Pressure Source to the method that the transmitter will use to obtain pressure data.

  • Page 81: Configure Pressure Compensation Using The Field Communicator

    Configure process measurement If you want to use digital communications, click Apply, then perform the necessary host programming and communications setup to write temperature data to the transmitter at appropriate intervals. Postrequisites If you are using an external pressure value, verify the setup by checking the External Pressure value displayed in the Inputs area of the main window.

  • Page 82: Options For Pressure Measurement Unit

    Configure process measurement Option Setup A user-configured a. Set Pressure Unit to the desired unit. static pressure val- b. Set Compensation Pressure to the desired value. Polling for pressure a. Ensure that the primary mA output has been wired to support HART polling.
  • Page 83 Configure process measurement Table 4-16: Options for Pressure Measurement Unit Label Unit description Display ProLink II ProLink III Field Communica- FTH2O Ft Water @ 68°F ftH2O Feet water @ 68 °F Ft Water @ 68°F INW4C In Water @ 4°C inH2O @4DegC Inches water @ 4 °C In Water @ 4°C...
  • Page 84 Configure process measurement ® Micro Motion Model 2700 Transmitters with Analog Outputs...

  • Page 85: Configure Device Options And Preferences

    Configure device options and preferences Configure device options and preferences Topics covered in this chapter: • Configure the transmitter display • Enable or disable operator actions from the display • Configure security for the display menus • Configure response time parameters •...

  • Page 86: Configure The Process Variables Shown On The Display

    Configure device options and preferences The languages available depend on your transmitter model and version. 5.1.2 Configure the process variables shown on the display Display Not available ProLink II ProLink > Configuration > Display ProLink III Device Tools > Configuration > Transmitter Display > Display Variables Field Communicator Configure >...

  • Page 87: Configure The Precision Of Variables Shown On The Display

    Configure device options and preferences Display variable Process variable assignment Display Variable 10 None Display Variable 11 None Display Variable 12 None Display Variable 13 None Display Variable 14 None Display Variable 15 None Configure Display Variable 1 to track the primary mA output Display OFF-LINE MAINT >...

  • Page 88: Configure The Refresh Rate Of Data Shown On The Display

    Configure device options and preferences Overview Setting Display Precision determines the precision (number of decimal places) shown on the display. You can set Display Precision independently for each variable. Setting Display Precision does not affect the actual value of the process variable. Procedure Select a process variable.

  • Page 89: Enable Or Disable Automatic Scrolling Through The Display Variables

    Configure device options and preferences 5.1.5 Enable or disable automatic scrolling through the display variables Display OFF-LINE MAINT > OFF-LINE CONFG > DISPLAY > AUTO SCRLL ProLink II ProLink > Configuration > Display > Display Options > Display Auto Scroll ProLink III Device Tools >...

  • Page 90: Enable Or Disable Status Led Blinking

    Configure device options and preferences Procedure Enable or disable Backlight. The default setting is Enabled. 5.1.7 Enable or disable Status LED Blinking Not available Display ProLink II ProLink > Configuration > Display > Display Options > Display Status LED Blinking ProLink III Device Tools >...

  • Page 91: Enable Or Disable Totalizer Start/Stop From The Display

    Configure device options and preferences 5.2.1 Enable or disable Totalizer Start/Stop from the display Display OFF-LINE MAINT > OFF-LINE CONFG > DISPLAY > TOTALS STOP ProLink II ProLink > Configuration > Display > Display Options > Display Start/Stop Totalizers ProLink III Device Tools >...

  • Page 92: Enable Or Disable The Acknowledge All Alarms Display Command

    Configure device options and preferences Restrictions • This parameter does not apply to inventories. You cannot reset inventories from the display. • You cannot use the display to reset all totalizers as a group. You must reset totalizers individually. • If the petroleum measurement application is installed on your computer, the operator must enter the off-line password to perform this function, even if the off-line password is not enabled.

  • Page 93: Configure Security For The Display Menus

    Configure device options and preferences Option Description Enabled (default) Operators can use a single display command to acknowledge all alarms at once. Disabled Operators cannot acknowledge all alarms at once, they must be ac- knowledged individually. Configure security for the display menus Display OFF-LINE MAINT >...

  • Page 94: Configure Response Time Parameters

    Configure device options and preferences To require a password for access to the maintenance section of the off-line menu and the Smart Meter Verification menu, enable or disable Off-Line Password. Option Description Enabled Operator is prompted for the off-line password at entry to the Smart Meter Verification menu (if applicable) or entry to the maintenance section of the off-line menu.

  • Page 95: Configure Update Rate

    Configure device options and preferences 5.4.1 Configure Update Rate Not available Display ProLink II ProLink > Configuration > Device > Update Rate ProLink III Device Tools > Configuration > Process Measurement > Response > Update Rate Field Communicator Configure > Manual Setup > Measurements > Update Rate Overview Update Rate controls the rate at which process data is polled and process variables are calculated.
  • Page 96 Configure device options and preferences Effects of Update Rate = Special Incompatible features and functions Special mode is not compatible with the following features and functions: • Enhanced events. Use basic events instead. • All calibration procedures. • Zero verification. •...

  • Page 97: Configure Calculation Speed (Response Time)

    Configure device options and preferences 5.4.2 Configure Calculation Speed (Response Time) Not available Display ProLink II ProLink > Configuration > Device > Response Time ProLink III Device Tools > Configuration > Process Measurement > Response > Calculation Speed Field Communicator Not available Overview Calculation Speed is used to apply a different algorithm to the calculation of process variables from the raw process data.

  • Page 98: Configure Fault Timeout

    Configure device options and preferences 5.5.1 Configure Fault Timeout Not available Display ProLink II ProLink > Configuration > Analog Output > Last Measured Value Timeout ProLink > Configuration > Frequency/Discrete Output > Frequency > Last Measured Value Timeout ProLink III Device Tools >...
  • Page 99 Configure device options and preferences Overview Use Status Alarm Severity to control the fault actions that the transmitter performs when it detects an alarm condition. Restrictions • For some alarms, Status Alarm Severity is not configurable. • For some alarms, Status Alarm Severity can be set only to two of the three options. Micro Motion recommends using the default settings for Status Alarm Severity unless you have a specific requirement to change them.
  • Page 100 Configure device options and preferences Table 5-2: Status alarms and Status Alarm Severity Alarm code Status message Default severity Notes Configurable? Fault A001 EEPROM Error (Core Pro- cessor) A002 RAM Error (Core Processor) Fault A003 No Sensor Response Fault Fault A004 Temperature Overrange Fault...
  • Page 101 Configure device options and preferences Table 5-2: Status alarms and Status Alarm Severity (continued) Alarm code Status message Default severity Notes Configurable? Fault A031 Low Power Applies only to flowmeters with the enhanced core processor. A032 Meter Verification in Pro- Varies Applies only to transmitters with gress: Outputs to Fault...

  • Page 102: Configure Informational Parameters

    Configure device options and preferences Table 5-2: Status alarms and Status Alarm Severity (continued) Alarm code Status message Default severity Notes Configurable? Informational A114 mA Output 2 Fixed Can be set to either Informational or Ignore, but cannot be set to Fault. Informational A115 No External Input or Polled...

  • Page 103: Configure Descriptor

    Configure device options and preferences Message Date • Sensor parameters Sensor Serial Number Sensor Material Sensor Liner Material Sensor Flange Type 5.6.1 Configure Descriptor Display Not available ProLink II ProLink > Configuration > Device > Descriptor ProLink III Device Tools > Configuration > Informational Parameters > Transmitter Field Communicator Configure >...

  • Page 104: Configure Date

    Configure device options and preferences 5.6.3 Configure Date Not available Display ProLink II ProLink > Configuration > Device > Date ProLink III Device Tools > Configuration > Informational Parameters > Transmitter Field Communicator Configure > Manual Setup > Info Parameters > Transmitter Info > Date Overview Date lets you store a static date (not updated by the transmitter) in transmitter memory.

  • Page 105: Configure Sensor Material

    Configure device options and preferences 5.6.5 Configure Sensor Material Not available Display ProLink II ProLink > Configuration > Sensor > Sensor Matl ProLink III Device Tools > Configuration > Informational Parameters > Sensor Field Communicator Configure > Manual Setup > Info Parameters > Sensor Information > Tube Wetted Material Overview Sensor Material lets you store the type of material used for your sensor’s wetted parts in transmitter memory.

  • Page 106: Configure Sensor Flange Type

    Configure device options and preferences 5.6.7 Configure Sensor Flange Type Not available Display ProLink II ProLink > Configuration > Sensor > Flange ProLink III Device Tools > Configuration > Informational Parameters > Sensor Field Communicator Configure > Manual Setup > Info Parameters > Sensor Information > Sensor Flange Overview Sensor Flange Type lets you store your sensor’s flange type in transmitter memory.

  • Page 107: Integrate The Meter With The Control System

    Integrate the meter with the control system Integrate the meter with the control system Topics covered in this chapter: • Configure the transmitter channels • Configure the mA output • Configure the frequency output • Configure the discrete output • Configure events •...

  • Page 108: Configure The Ma Output

    Integrate the meter with the control system Postrequisites For each channel that you configured, perform or verify the corresponding input or output configuration. When the configuration of a channel is changed, the channel’s behavior will be controlled by the configuration that is stored for the selected input or output type, and the stored configuration may not be appropriate for your process.
  • Page 109 Integrate the meter with the control system • If you plan to configure an output to report a concentration measurement process variable, ensure that the concentration measurement application is configured so that the desired variable is available. • If you are using the HART variables, be aware that changing the configuration of mA Output Process Variable will change the configuration of the HART Primary Variable (PV).

  • Page 110: Configure Lower Range Value (Lrv) And Upper Range Value (Urv)

    Integrate the meter with the control system Table 6-1: Options for mA Output Process Variable (continued) Process variable Label Display ProLink II ProLink III Field Communicator Concentration measurement RDENS CM: Density @ Reference Density at Reference ED Dens at Ref Density at reference Temperature Specific gravity...
  • Page 111 Integrate the meter with the control system Procedure Set LRV and URV as desired. • LRV is the value of mA Output Process Variable represented by an output of 4 mA. The default value for LRV depends on the setting of mA Output Process Variable. Enter LRV in the measurement units that are configured for mA Output Process Variable.

  • Page 112: Configure Ao Cutoff

    Integrate the meter with the control system Table 6-2: Default values for Lower Range Value (LRV) and Upper Range Value (URV) (continued) Process variable Concentration 100% Baume Specific gravity 6.2.3 Configure AO Cutoff Not available Display ProLink II ProLink > Configuration > Analog Output > Primary Output > AO Cutoff ProLink III Device Tools >...

  • Page 113: Configure Added Damping

    Integrate the meter with the control system Example: Cutoff interaction Configuration: • mA Output Process Variable = Mass Flow Rate • Frequency Output Process Variable = Mass Flow Rate • AO Cutoff = 10 g/sec • Mass Flow Cutoff = 15 g/sec Result: If the mass flow rate drops below 15 g/sec, all outputs representing mass flow will report zero flow.
  • Page 114 Integrate the meter with the control system Note Added Damping is not applied if the mA output is fixed (for example, during loop testing) or if the mA output is reporting a fault. Added Damping is applied while sensor simulation is active. Procedure Set Added Damping to the desired value.

  • Page 115: Configure Ma Output Fault Action And Ma Output Fault Level

    Integrate the meter with the control system Result: A change in the mass flow rate will be reflected in the mA output over a time period that is greater than 3 seconds. The exact time period is calculated by the transmitter according to internal algorithms which are not configurable.

  • Page 116: Configure The Frequency Output

    Integrate the meter with the control system Table 6-4: Options for mA Output Fault Action and mA Output Fault Level (continued) mA Output Fault Level Option mA output behavior None Tracks data for the assigned process vari- Not applicable able; no fault action CAUTION! If you set mA Output Fault Action or Frequency Output Fault Action to None, be sure to set Digital Communications Fault Action to None.
  • Page 117 Integrate the meter with the control system Overview Frequency Output Process Variable controls the variable that is reported over the frequency output. Prerequisites If you plan to configure the output to report volume flow, ensure that you have set Volume Flow Type as desired: Liquid or Gas Standard Volume.

  • Page 118: Configure Frequency Output Polarity

    Integrate the meter with the control system Table 6-5: Options for Frequency Output Process Variable (continued) Label Process variable Display ProLink II ProLink III Field Communica- NET M ED: Net Mass Flow Net Mass Flow Rate ED Net Mass flo Net mass flow Rate NET V...

  • Page 119: Configure Frequency Output Scaling Method

    Integrate the meter with the control system 6.3.3 Configure Frequency Output Scaling Method Display OFF-LINE MAINT > OFF-LINE CONFG > IO > CH B > SET FO > FO SCALE ProLink II ProLink > Configuration > Frequency/Discrete Output > Frequency > Scaling Method ProLink III Device Tools >...

  • Page 120: Configure Frequency Output Maximum Pulse Width

    Integrate the meter with the control system N Number of pulses per flow unit, as configured in the receiving device The resulting Frequency Factor must be within the range of the frequency output (0 to 10,000 Hz): • If Frequency Factor is less than1 Hz,reconfigure the receiving device for a higher pulses/unit setting.

  • Page 121: Configure Frequency Output Fault Action And Frequency Output Fault Level

    Integrate the meter with the control system The ON signal may be the high voltage or 0.0 V, depending on Frequency Output Polarity. Table 6-7: Interaction of Frequency Output Maximum Pulse Width and Frequency Output Polarity Polarity Pulse width Active High Active Low Procedure Set Frequency Output Maximum Pulse Width as desired.

  • Page 122: Configure The Discrete Output

    Integrate the meter with the control system Note For some faults only: If Last Measured Value Timeout is set to a non-zero value, the transmitter will not implement the fault action until the timeout has elapsed. Procedure Set Frequency Output Fault Action as desired. The default value is Downscale (0 Hz).

  • Page 123: Configure Discrete Output Source

    Integrate the meter with the control system • Discrete Output Polarity Discrete Output Fault Action • Restriction Before you can configure the discrete output, you must configure a channel to operate as a discrete output. Important Whenever you change a discrete output parameter, verify all other discrete output parameters before returning the flowmeter to service.
  • Page 124 Integrate the meter with the control system Table 6-9: Options for Discrete Output Source (continued) Label Discrete out- Option Condition put voltage Field Commu- Display ProLink II ProLink III nicator Enhanced Event Enhanced Event Event 1–2 EVNT1 Event 1 Event 1 Event 1 Site-specific Event 2...
  • Page 125 Integrate the meter with the control system Configure Flow Switch parameters Display OFF-LINE MAINT > OFF-LINE CONFG > IO > CH B > SET DO > CONFIG FL SW ProLink II • ProLink > Configuration > Flow > Flow Switch Variable •...

  • Page 126: Configure Discrete Output Polarity

    Integrate the meter with the control system 6.4.2 Configure Discrete Output Polarity Display OFF-LINE MAINT > OFF-LINE CONFG > IO > CH B > SET DO > DO POLAR ProLink II ProLink > Configuration > Frequency/Discrete Output > Discrete Output > DO Polarity ProLink III Device Tools >...

  • Page 127: Configure Discrete Output Fault Action

    Integrate the meter with the control system Figure 6-1: Typical discrete output circuit 24 V (Nom) Ω 3.2 K Out+ Out− 6.4.3 Configure Discrete Output Fault Action Display Not available ProLink II ProLink > Configuration > Frequency/Discrete Output > Discrete Output > DO Fault Action ProLink III Device Tools >...

  • Page 128: Configure Events

    Integrate the meter with the control system Procedure Set Discrete Output Fault Action as desired. The default setting is None. Options for Discrete Output Fault Action Table 6-11: Options for Discrete Output Fault Action Discrete output behavior Label Polarity=Active High Polarity=Active Low Upscale •...

  • Page 129: Configure A Basic Event

    Integrate the meter with the control system 6.5.1 Configure a basic event Not available Display ProLink II ProLink > Configuration > Events ProLink III Device Tools > Configuration > Events > Basic Events Field Communicator Not available Overview A basic event is used to provide notification of process changes. A basic event occurs (is ON) if the real-time value of a user-specified process variable moves above (HI) or below (LO) a user-defined setpoint.
  • Page 130 Integrate the meter with the control system Overview An enhanced event is used to provide notification of process changes and, optionally, to perform specific transmitter actions if the event occurs. An enhanced event occurs (is ON) if the real-time value of a user-specified process variable moves above (HI) or below (LO) a user-defined setpoint, or in range (IN) or out of range (OUT) with respect to two user- defined setpoints.
  • Page 131 Integrate the meter with the control system Options for Enhanced Event Action Table 6-12: Options for Enhanced Event Action Action Label Display ProLink II ProLink III Field Communicator Standard NONE None None None None (default) START ZERO Start Sensor Zero Start Sensor Zero Perform auto zero Start sensor zero...

  • Page 132: Configure Digital Communications

    Integrate the meter with the control system Configure digital communications The digital communications parameters control how the transmitter will communicate using digital communications. Your transmitter supports the following types of digital communications: • HART/Bell 202 over the primary mA terminals •...
  • Page 133 Integrate the meter with the control system Ensure Loop Current Mode (mA Output Action) is configured appropriately. Options Description Enabled The primary mA output reports process data as configured. Disabled The primary mA output is fixed at 4 mA and does not report process data.
  • Page 134 Integrate the meter with the control system Label Field Communi- ProLink II ProLink III cator Description Primary Variable Source (Primary The transmitter sends the primary Variable) variable (PV) in the configured measurement units in each burst (e.g., 14.0 g/sec, 13.5 g/sec, 12.0 g/sec).
  • Page 135 Integrate the meter with the control system Options for HART variables Table 6-13: Options for HART variables Process variable Primary Varia- Secondary Third Variable Fourth Varia- ble (PV) Variable (SV) (TV) ble (QV ) Standard ✓ ✓ ✓ ✓ Mass flow rate ✓...
  • Page 136 Integrate the meter with the control system Table 6-13: Options for HART variables (continued) Process variable Primary Varia- Secondary Third Variable Fourth Varia- ble (PV) Variable (SV) (TV) ble (QV ) ✓ ✓ ✓ ✓ ED standard volume flow rate ✓...

  • Page 137: Configure Hart/Rs-485 Communications

    Integrate the meter with the control system 6.6.2 Configure HART/RS-485 communications Display OFF-LINE MAINT > OFF-LINE CONFG > COMM ProLink II ProLink > Configuration > Device > Digital Comm Settings > HART Address ProLink > Configuration > RS-485 ProLink III Device Tools >...

  • Page 138: Configure Modbus/Rs-485 Communications

    Integrate the meter with the control system 6.6.3 Configure Modbus/RS-485 communications Display OFF-LINE MAINT > OFF-LINE CONFG > COMM ProLink II ProLink > Configuration > Device > Digital Comm Settings ProLink III Device Tools > Configuration > Communications > RS-485 Terminals Field Communicator Configure >...

  • Page 139: Configure Digital Communications Fault Action

    Integrate the meter with the control system Set Parity, Stop Bits, and Baud Rate as appropriate for your network. Set Floating-Point Byte Order to match the byte order used by your Modbus host. Code Byte order 1–2 3–4 3–4 1–2 2–1 4–3 4–3 2–1 Table 6-15...
  • Page 140 Integrate the meter with the control system Overview Digital Communications Fault Action specifies the values that will be reported via digital communications if the transmitter encounters an internal fault condition. Procedure Set Digital Communications Fault Action as desired. The default setting is None. Options for Digital Communications Fault Action Table 6-16: Options for Digital Communications Fault Action...
  • Page 141 Integrate the meter with the control system CAUTION! If you set mA Output Fault Action or Frequency Output Fault Action to None, be sure to set Digital Communications Fault Action to None. If you do not, the output will not report actual process data, and this may result in measurement errors or unintended consequences for your process.
  • Page 142 Integrate the meter with the control system ® Micro Motion Model 2700 Transmitters with Analog Outputs...

  • Page 143: Completing The Configuration

    Completing the configuration Completing the configuration Topics covered in this chapter: • Test or tune the system using sensor simulation • Back up transmitter configuration • Enable write-protection on the transmitter configuration Test or tune the system using sensor simulation Use sensor simulation to test the system's response to a variety of process conditions, including boundary conditions, problem conditions, or alarm conditions, or to tune the loop.

  • Page 144: Sensor Simulation

    Completing the configuration Option Required values Sine Period Minimum Maximum For density, set Wave Form as desired and enter the required values. Option Required values Fixed Fixed Value Sawtooth Period Minimum Maximum Sine Period Minimum Maximum For temperature, set Wave Form as desired and enter the required values. Option Required values Fixed...

  • Page 145: Back Up Transmitter Configuration

    Completing the configuration • All mass flow rate, temperature, and density values shown on the display or reported via outputs or digital communications • The mass total and mass inventory values • All volume calculations and data, including reported values, volume totals, and volume inventories •...

  • Page 146: Enable Write-Protection On The Transmitter Configuration

    Completing the configuration Enable write-protection on the transmitter configuration Display OFF-LINE MAINT > CONFIG > LOCK ProLink II ProLink > Configuration > Device > Enable Write Protection ProLink III Device Tools > Configuration > Write-Protection Field Communicator Configure > Manual Setup > Info Parameters > Transmitter Info > Write Protect Overview If the transmitter is write-protected, the configuration is locked and nobody can change it until it is unlocked.

  • Page 147: Set Up The Weights & Measures Application

    Set up the Weights & Measures application Set up the Weights & Measures application Topics covered in this chapter: • Weights & Measures application • Set up the Weights & Measures application using ProLink II • Set up the Weights & Measures application using ProLink III Information in this chapter is applicable only if your transmitter was ordered with the Weights &...

  • Page 148: Set Up The Weights & Measures Application Using Prolink Ii

    Set up the Weights & Measures application Metrological Metrological security protects the transmitter from all changes that would affect measurement. This includes changes to configuration and security some maintenance procedures. Micro Motion implements metrological security via “software security.” Software security is a setting inside the transmitter that programmatically disables the prohibited actions.
  • Page 149 Set up the Weights & Measures application Set Approval to the appropriate regulatory agency for your application. Option Description NTEP Regulatory agency for the U.S.A. and Canada OIML Regulatory agency for all other world areas Set Totalizer Reset Options as desired. Option Description Not Resettable from Display...
  • Page 150 Set up the Weights & Measures application FVZ is a diagnostic variable that monitors the zero value over a period of 3 minutes. It must be read during meter commissioning to comply with MID requirements for Weights & Measures applications in Measuring Instrument Directive (MID) 2004/22/ EC.

  • Page 151: Set Up The Weights & Measures Application Using Prolink Iii

    Set up the Weights & Measures application Set up the Weights & Measures application using ProLink III When your transmitter is set up to comply with OIML or NTEP requirements, and the transmitter is “secured,” selected measurement data from the transmitter is approved for Weights &...
  • Page 152 Set up the Weights & Measures application “Digital communications” refers to any method that uses Modbus or HART communications to interact with the transmitter. This includes ProLink II, ProLink III, the Field Communicator, and any host. If required for your installation, configure your transmitters for two frequency outputs and set them to operate in Quadrature mode.
  • Page 153 Set up the Weights & Measures application Install the physical seal. Important In most installations, the physical seal is a wire seal that must be installed by a certified Weights & Measures inspector. The seal is provided by the inspector. The physical seal is inserted through the locking clamps on the transmitter (if available on your transmitter).
  • Page 154 Set up the Weights & Measures application ® Micro Motion Model 2700 Transmitters with Analog Outputs...

  • Page 155: Part Iii Operations, Maintenance, And Troubleshooting

    Operations, maintenance, and troubleshooting Part III Operations, maintenance, and troubleshooting Chapters covered in this part: • Transmitter operation • Operate the transmitter with the Weights & Measures application • Measurement support • Troubleshooting Configuration and Use Manual...
  • Page 156 Operations, maintenance, and troubleshooting ® Micro Motion Model 2700 Transmitters with Analog Outputs...

  • Page 157: Chapter 9 Transmitter Operation

    Transmitter operation Transmitter operation Topics covered in this chapter: • Record the process variables • View process variables • View transmitter status using the status LED • View and acknowledge status alarms • Read totalizer and inventory values • Start and stop totalizers and inventories •...

  • Page 158: View Process Variables

    Transmitter operation View process variables Display Scroll to the desired process variable. If AutoScroll is enabled, you can wait until the proc- ess variable is displayed. See Section 9.2.1 for more information. ProLink II ProLink > Process Variables ProLink > API process variables (petroleum measurement application) ProLink >...

  • Page 159: View Process Variables Using Prolink Iii

    Transmitter operation Figure 9-1: Transmitter display features A. Status LED B. Display (LCD panel) C. Process variable D. Scroll optical switch E. Optical switch indicator: turns red when either Scroll or Select is activated F. Select optical switch G. Unit of measure for process variable H.

  • Page 160: View Transmitter Status Using The Status Led

    Transmitter operation View transmitter status using the status LED The status LED shows the current alarm condition of the transmitter. The status LED is located on the face of the transmitter. Observe the status LED. • If your transmitter has a display, you can view the status LED with the transmitter housing cover in place.
  • Page 161 Transmitter operation Prerequisites Operator access to the alarm menu must be enabled (default setting). If operator access to the alarm menu is disabled, you must use another method to view or acknowledge status alarms. Procedure Figure 9-2. Configuration and Use Manual...
  • Page 162 Transmitter operation Figure 9-2: Using the display to view and acknowledge the status alarms Scroll and Select simultaneously for 4 seconds SEE ALARM Select Is ACK ALL enabled? ACK ALL Select Scroll EXIT Select Scroll Active/ unacknowledged alarms? Alarm code NO ALARM Scroll Select...

  • Page 163: View And Acknowledge Alarms Using Prolink Ii

    Transmitter operation Postrequisites • To clear the following alarms, you must correct the problem, acknowledge the alarm, then power-cycle the transmitter: A001, A002, A010, A011, A012, A013, A018, A019, A022, A023, A024, A025, A028, A029, A031. • For all other alarms: If the alarm is inactive when it is acknowledged, it will be removed from the list.

  • Page 164: View And Acknowledge Alerts Using Prolink Iii

    Transmitter operation 9.4.3 View and acknowledge alerts using ProLink III You can view a list containing all alerts that are active, or inactive and have been unacknowleged. From this list, you can acknowlege individual alerts or choose to acknowledge all alerts at once. View alerts on the ProLink III main screen under Alerts.

  • Page 165: Alarm Data In Transmitter Memory

    Transmitter operation • To refresh the list of active or unacknowledged alarms, press Service Tools > Alerts > Refresh Alerts. 9.4.5 Alarm data in transmitter memory The transmitter maintains three sets of data for every alarm that is posted. For each alarm occurrence, the following three sets of data are maintained in transmitter memory: •...

  • Page 166: Start And Stop Totalizers And Inventories

    Transmitter operation Overview Totalizers keep track of the total amount of mass or volume measured by the transmitter since the last totalizer reset. Inventories keep track of the total amount of mass or volume measured by the transmitter since the last inventory reset. You can use the inventories to keep a running total of mass or volume across multiple totalizer resets.
  • Page 167 Transmitter operation 1. Scroll until the word TOTAL appears in the lower left corner of the display. Important Because all totalizers are started or stopped together, it does not matter which total you use. 2. Select. 3. Scroll until START appears beneath the current totalizer value. 4.

  • Page 168: Reset Totalizers

    Transmitter operation Reset totalizers Display Section 9.7.1. ProLink II ProLink > Totalizer Control > Reset Mass Total ProLink > Totalizer Control > Reset Volume Total ProLink > Totalizer Control > Reset Gas Volume Total ProLink > Totalizer Control > Reset ProLink III Device Tools >...

  • Page 169: Reset Inventories

    Transmitter operation 3. Scroll until RESET appears beneath the current totalizer value. 4. Select. 5. Select again to confirm. 6. Scroll to EXIT. 7. Select. • To reset the volume totalizer: 1. Scroll until the volume totalizer value appears. 2. Select. 3.
  • Page 170 Transmitter operation Overview When you reset an inventory, the transmitter sets its value to 0. It does not matter whether the inventory is started or stopped. If the inventory is started, it continues to track process measurement. When you reset a single inventory, the values of other inventories are not reset. Totalizer values are not reset.

  • Page 171: Chapter 10 Operate The Transmitter With The Weights & Measures Application

    Operate the transmitter with the Weights & Measures application Operate the transmitter with the Weights & Measures application Topics covered in this chapter: • Operate the transmitter when the Weights & Measures application is installed • Switch between secured and unsecured mode •...

  • Page 172: Approved Methods To Read Or Obtain Process Data

    Operate the transmitter with the Weights & Measures application • You cannot stop totalizers while the tranmitter is secured. • You cannot reset inventories while the transmitter is secured. 10.1.1 Approved methods to read or obtain process data When the Weights & Measures application is installed, process data is approved for custody transfer use only if an approved method is used for reading or obtaining it.

  • Page 173: Effect Of The Weights & Measures Application On Process Measurement And Outputs

    Operate the transmitter with the Weights & Measures application The display is able to show a maximum of eight characters, including the decimal point. For all totalizer values configured as display variables, the position of the decimal point on the display is fixed to the configured precision of the display variable. When the totalizer reaches the largest value that can be displayed in these circumstances: •...

  • Page 174: Effect Of The Weights & Measures Application On Operation And Maintenance Functions

    Operate the transmitter with the Weights & Measures application Table 10-4: Transmitter outputs and process data when Approvals=OIML Function Transmitter status Unsecured Secured Outputs mA output behavior Performs configured fault action Normal Frequency output behavior Performs configured fault action Normal Discrete output behavior Performs configured fault action Normal...
  • Page 175 Operate the transmitter with the Weights & Measures application Table 10-5: Available actions when Approvals=NTEP (continued) Function Transmitter status Unsecured Secured Outputs set to Last Meas- Allowed Not allowed ured Value External pressure and tem- Retrieved by polling Allowed Allowed perature data Written by Modbus or Allowed...

  • Page 176: Switch Between Secured And Unsecured Mode

    Operate the transmitter with the Weights & Measures application Table 10-6: Available actions when Approvals=OIML (continued) Function Transmitter status Unsecured Secured Smart Meter Verification Outputs set to Continue Allowed Allowed Measuring Outputs set to Fault Allowed Allowed Outputs set to Last Meas- Allowed Not allowed ured Value...

  • Page 177: Switch Between Secured And Unsecured Mode Using Prolink Ii

    Operate the transmitter with the Weights & Measures application The controls are not accessible in any other way. 10.2.1 Switch between secured and unsecured mode using ProLink II Prerequisites Before switching to unsecured mode, ensure that you will be able to switch back to secured mode.

  • Page 178: Switch Between Secured And Unsecured Mode Using The Switching Utility

    Operate the transmitter with the Weights & Measures application 1. Make a service port connection to your transmitter. 2. Choose Device Tools > Configuration > Weights & Measures. 3. Set Software Security to Enabled. 10.2.3 Switch between secured and unsecured mode using the switching utility Prerequisites The switching utility must be installed on your PC.

  • Page 179: Replacing The Core Processor In A Weights & Measures Installation

    Operate the transmitter with the Weights & Measures application 10.4 Replacing the core processor in a Weights & Measures installation In a Weights & Measures installation, replacing the core processor requires re-sealing the transmitter. When the transmitter is first secured, the core processor’s unique ID is registered with the transmitter.
  • Page 180 Operate the transmitter with the Weights & Measures application ® Micro Motion Model 2700 Transmitters with Analog Outputs...

  • Page 181: Chapter 11 Measurement Support

    Measurement support Measurement support Topics covered in this chapter: • Options for measurement support • Use Smart Meter Verification • Zero the flowmeter • Validate the meter • Perform a (standard) D1 and D2 density calibration • Perform a D3 and D4 density calibration (T-Series sensors only) •...

  • Page 182: Smart Meter Verification Requirements

    Measurement support 11.2.1 Smart Meter Verification requirements To use Smart Meter Verification, the transmitter must be paired with an enhanced core processor, and the Smart Meter Verification option must be ordered for the transmitter. Table 11-1 for the minimum version of the transmitter, enhanced core processor, and communication tool needed to support Smart Meter Verification.

  • Page 183: Run Smart Meter Verification

    Measurement support Smart Meter Verification has an output mode called Continuous Measurement that allows the transmitter to keep measuring while the test is in progress. If you choose to run the test in Last Measured Value or Fault modes instead, the transmitter outputs will be held constant for the two minute duration of the test.
  • Page 184 Measurement support Option Description Last Value During the test, all outputs will go to their configured fault action. The test will run for approximately 140 seconds. While the test is in progress, dots traverse the display and test progress is shown. Postrequisites View the test results and take any appropriate actions.
  • Page 185 Measurement support Smart Meter Verification flowchart: Running a test using the display Figure 11-2: Running a Smart Meter Verification test using the display RUN VERFY Select OUTPUTS EXIT Scroll Select CONTINUE MEASR FAULT LAST VALUE EXIT Scroll Scroll Scroll Select Select Select ARE YOU SURE/YES?
  • Page 186 Measurement support You may need to wait a few seconds while ProLink II synchronizes its database with the transmitter data. Review the information presented on the screen, and click Next. Enter any desired information on the Test Definition screen, and click Next. All information on this screen is optional.

  • Page 187: View Test Data

    Measurement support Postrequisites View the test results and take any appropriate actions. Run a Smart Meter Verification test using the Field Communicator Navigate to the Smart Meter Verification menu: • Overview > Shortcuts > Meter Verification • Service Tools > Maintenance > Routine Maintenance > Meter Verification Choose Manual Verification.
  • Page 188 Measurement support • Current flowmeter identification data • Current flow and density configuration parameters • Current zero values • Current process values for mass flow rate, volume flow rate, density, temperature, and external pressure • Customer and test descriptions (if entered by the user) If you use ProLink II or ProLink III to run a test, a test result chart and a test report are displayed at the completion of the test.
  • Page 189 Measurement support Smart Meter Verification flowchart: Viewing test results using the display Figure 11-4: Viewing Smart Meter Verification test results using the display RESULTS READ Select RUNCOUNT x Select Scroll Pass Result type Abort Fail xx HOURS xx HOURS xx HOURS Select Select Select...
  • Page 190 Measurement support View test result data using ProLink II Choose Tools > Meter Verification > Run Meter Verification and click View Previous Test Results and Print Report. The chart shows test results for all tests stored in the ProLink II database. (Optional) Click Next to view and print a test report.

  • Page 191: Schedule Automatic Execution Of The Smart Meter Verification Test

    Measurement support Fail The test result is not within the specification uncertainty limit. Micro Motion recommends that you immediately repeat the meter verification test. If during the failed test you had set outputs to Continue Measurement, set outputs to Fault or Last Measured Value instead.
  • Page 192 Measurement support Manage scheduled test execution using the display Navigate to the Smart Meter Verification menu. Figure 11-5: Smart Meter Verification – Top-level menu Scroll and Select simultaneously for 4 seconds Scroll ENTER METER VERFY Select RUN VERFY RESULTS READ SCHEDULE VERFY EXIT Scroll...
  • Page 193 Measurement support Smart Meter Verification flowchart: Scheduling test execution using the display Figure 11-6: Scheduling Smart Meter Verification test execution using the display SCHEDULE VERFY Select Schedule set? SCHED IS OFF TURN OFF SCHED/YES? Scroll Scroll Select Schedule deleted HOURS LEFT Scroll Select xx HOURS...

  • Page 194: Zero The Flowmeter

    Measurement support To disable scheduled execution: • To disable execution of a single scheduled test, set Hours Until Next Run to 0. • To disable recurring execution, set Hours Between Recurring Runs to 0. • To disable all scheduled execution, click Turn Off Schedule. Manage scheduled test execution using ProLink III Choose Device Tools >...

  • Page 195: Zero The Flowmeter Using The Display

    Measurement support • The zero is required by site procedures. • The stored zero value fails the Zero Verification procedure. Prerequisites Before performing a field zero, execute the Zero Verification procedure to see whether or not a field zero can improve measurement accuracy. See Section 2.6.

  • Page 196: Zero The Flowmeter Using Prolink Ii

    Measurement support Navigate to OFFLINE MAINT > ZERO > CAL ZERO and select CAL/YES?. Dots traverse the display while flowmeter zero is in progress. Read the zero result on the display. The display reports CAL PASS if the zero was successful, or CAL FAIL if it was not. Postrequisites Restore normal flow through the sensor by opening the valves.

  • Page 197: Zero The Flowmeter Using Prolink Iii

    Measurement support Click Calibrate Zero. Modify Zero Time, if desired. Zero Time controls the amount of time the transmitter takes to determine its zero- flow reference point. The default Zero Time is 20 seconds. For most applications, the default Zero Time is appropriate. Click Perform Auto Zero.
  • Page 198 Measurement support a. Allow the flowmeter to warm up for at least 20 minutes after applying power. b. Run the process fluid through the sensor until the sensor temperature reaches the normal process operating temperature. c. Stop flow through the sensor by shutting the downstream valve, and then the upstream valve if available.

  • Page 199: Zero The Flowmeter Using The Field Communicator

    Measurement support 11.3.4 Zero the flowmeter using the Field Communicator Zeroing the flowmeter establishes a baseline for process measurement by analyzing the sensor's output when there is no flow through the sensor tubes. Prepare the flowmeter: a. Allow the flowmeter to warm up for at least 20 minutes after applying power. b.

  • Page 200: Validate The Meter

    Measurement support 11.4 Validate the meter Display OFF-LINE MAINT > CONFG > UNITS > MTR F ProLink II ProLink > Configuration > Flow ProLink III Device Tools > Configuration > Process Measurement > Flow Device Tools > Configuration > Process Measurement > Density Field Communicator Configure >...

  • Page 201: Alternate Method For Calculating The Meter Factor For Volume Flow

    Measurement support Procedure Determine the meter factor as follows: a. Use the flowmeter to take a sample measurement. b. Measure the same sample using the reference device. c. Calculate the meter factor using the following formula: ReferenceMeasurement NewMeterFactor ConfiguredMeterFactor FlowmeterMeasurement Ensure that the calculated meter factor is between 0.8 and 1.2, inclusive.

  • Page 202: Perform A (Standard) D1 And D2 Density Calibration

    Measurement support MeterFactor Volume MeterFactor Density Note The following equation is mathematically equivalent to the first equation. You may use whichever version you prefer. Density Flowmeter MeterFactor ConfiguredMeterFactor Volume Density Density ReferenceDevice Ensure that the calculated meter factor is between 0.8 and 1.2, inclusive. If the meter factor is outside these limits, contact Micro Motion customer service.
  • Page 203 Measurement support • If LD Optimization is enabled on your meter, disable it. To do this, choose ProLink > Configuration > Sensor and ensure that the checkbox is not checked. LD Optimization is used only with large sensors in hydrocarbon applications. In some installations, only Micro Motion customer service has access to this parameter.

  • Page 204: Perform A D1 And D2 Density Calibration Using Prolink Iii

    Measurement support Postrequisites If you disabled LD Optimization before the calibration procedure, re-enable it. 11.5.2 Perform a D1 and D2 density calibration using ProLink III Prerequisites • During density calibration, the sensor must be completely filled with the calibration fluid, and flow through the sensor must be at the lowest rate allowed by your application.

  • Page 205: Perform A D1 And D2 Density Calibration Using The Field Communicator

    Measurement support Figure 11-8: D1 and D2 density calibration using ProLink III Close shutoff valve downstream from sensor D1 calibration D2 calibration Fill sensor with D1 fluid Fill sensor with D2 fluid Device Tools > Device Tools > Calibration > Calibration >...
  • Page 206 Measurement support • Before performing the calibration, record your current calibration parameters. If the calibration fails, restore the known values. Restriction For T-Series sensors, the D1 calibration must be performed on air and the D2 calibration must be performed on water. Procedure Figure 11-9.

  • Page 207: Perform A D3 And D4 Density Calibration (T-Series Sensors Only)

    Measurement support 11.6 Perform a D3 and D4 density calibration (T- Series sensors only) For T-Series sensors, the optional D3 and D4 calibration could improve the accuracy of the density measurement if the density of your process fluid is less than 0.8 g/cm or greater than 1.2 g/cm If you perform the D3 and D4 calibration, note the following:...

  • Page 208: Perform A D3 Or D3 And D4 Density Calibration Using Prolink Iii

    Measurement support Figure 11-10: D3 or D3 and D4 density calibration using ProLink II D3 calibration D4 calibration Close shutoff valve Fill sensor with D3 fluid Fill sensor with D4 fluid downstream from sensor ProLink Menu > ProLink Menu > Calibration >...

  • Page 209: Perform A D3 Or D3 And D4 Density Calibration Using The Field Communicator

    Measurement support Minimum difference of 0.1 g/cm between the density of the D4 fluid and the density of the D3 fluid. The density of the D4 fluid must be greater than the density of the D3 fluid. Minimum difference of 0.1 g/cm between the density of the D4 fluid and the density of water.
  • Page 210 Measurement support • For D3 density calibration, the D3 fluid must meet the following requirements: Minimum density of 0.6 g/cm Minimum difference of 0.1 g/cm between the density of the D3 fluid and the density of water. The density of the D3 fluid may be either greater or less than the density of water.

  • Page 211: Perform Temperature Calibration

    Measurement support Figure 11-12: D3 or D3 and D4 density calibration using the Field Communicator D3 calibration D4 calibration Close shutoff valve Fill sensor with D3 fluid Fill sensor with D4 fluid downstream from sensor Service Tools > On-Line Menu > Maintenance >...
  • Page 212 Measurement support Important Consult Micro Motion before performing a temperature calibration. Under normal circumstances, the temperature circuit is stable and should not need an adjustment. Procedure Figure 11-13 Figure 11-14. Figure 11-13: Temperature calibration using ProLink II Temperature Offset calibration Temperature Slope calibration Fill sensor with low- Fill sensor with high-...
  • Page 213 Measurement support Figure 11-14: Temperature calibration using ProLink III Temperature Offset calibration Temperature Slope calibration Fill sensor with low- Fill sensor with high- temperature fluid temperature fluid Wait until sensor achieves Wait until sensor achieves thermal equilibrium thermal equilibrium Device Tools > Device Tools >...
  • Page 214 Measurement support ® Micro Motion Model 2700 Transmitters with Analog Outputs...

  • Page 215: Chapter 12 Troubleshooting

    Troubleshooting Troubleshooting Topics covered in this chapter: • Status LED states • Status alarms • Flow measurement problems • Density measurement problems • Temperature measurement problems • Milliamp output problems • Frequency output problems • Use sensor simulation for troubleshooting •...

  • Page 216: Status Led States

    Troubleshooting 12.1 Status LED states The status LED on the transmitter indicates whether or not alarms are active. If alarms are active, view the alarm list to identify the alarms, then take appropriate action to correct the alarm condition. Your transmitter has a status LED only if it has a display. If the transmitter has a display and LED Blinking is disabled, the status LED does not flash to indicate an unacknowledged alarm.
  • Page 217 Troubleshooting Table 12-2: Status alarms and recommended actions (continued) Alarm code Description Recommended actions A003 No Sensor Response The transmitter is not receiving one or more basic electrical sig- nals from the sensor. This could mean that the wiring between the sensor and the transmitter has been damaged, or that the sensor requires factory service.
  • Page 218 Troubleshooting Table 12-2: Status alarms and recommended actions (continued) Alarm code Description Recommended actions A005 Mass Flow Rate Overrange The sensor is signaling a flow rate that is out of range for the sen- sor. 1. If other alarms are present, resolve those alarm conditions first.
  • Page 219 Troubleshooting Table 12-2: Status alarms and recommended actions (continued) Alarm code Description Recommended actions A008 Density Overrange The sensor is signaling a density reading below 0 g/cm or above 10 g/cm . Common causes for this alarm include partially filled flow tubes, excessive gas entrainment or flashing, tube fouling (foreign material stuck in a tube, uneven coating on the inside of a tube, or a plugged tube), or tube deformation (a permanent...
  • Page 220 Troubleshooting Table 12-2: Status alarms and recommended actions (continued) Alarm code Description Recommended actions A010 Calibration Failure This alarm is typically caused by flow through the sensor during the zero, or by a zero offset result that is out of range. Power to the transmitter must be cycled to clear this alarm.
  • Page 221 Troubleshooting Table 12-2: Status alarms and recommended actions (continued) Alarm code Description Recommended actions A016 Sensor RTD Failure The sensor RTD is signaling a resistance that is out of range for the sensor. 1. Check the wiring between the sensor and the transmitter. a.
  • Page 222 Troubleshooting Table 12-2: Status alarms and recommended actions (continued) Alarm code Description Recommended actions A019 RAM Error (Transmitter) Power to the transmitter must be cycled to clear this alarm. 1. Check that all wiring compartment covers are installed prop- erly. 2.
  • Page 223 Troubleshooting Table 12-2: Status alarms and recommended actions (continued) Alarm code Description Recommended actions A026 Sensor/Transmitter Communi- The transmitter has lost communication with the core processor cations Failure on the sensor. This alarm can be an indication of a problem with the core or the transmitter requiring the replacement of one or both parts.
  • Page 224 Troubleshooting Table 12-2: Status alarms and recommended actions (continued) Alarm code Description Recommended actions A031 Low Power The core processor on the sensor is not receiving sufficient pow- er. Check the wiring between the transmitter and the sensor. Power to the transmitter must be cycled to clear this alarm. 1.
  • Page 225 Troubleshooting Table 12-2: Status alarms and recommended actions (continued) Alarm code Description Recommended actions A100 mA Output 1 Saturated The calculated mA output value is outside of the meter's config- ured range. 1. Check the Upper Range Value and Lower Range Value parame- ters.
  • Page 226 Troubleshooting Table 12-2: Status alarms and recommended actions (continued) Alarm code Description Recommended actions A110 Frequency Output Saturated The calculated frequency output is outside the configured range. 1. Check the Frequency Output Scaling Method parameter. 2. Check your process conditions against the values reported by the flowmeter.
  • Page 227 Troubleshooting Table 12-2: Status alarms and recommended actions (continued) Alarm code Description Recommended actions A117 Density Overrange (Petrole- 1. Check your process conditions against the values reported by the flowmeter. 2. Verify the configuration of the petroleum measurement ta- ble type and density. A118 Discrete Output 1 Fixed The discrete output has been configured to send a constant val-...

  • Page 228: Flow Measurement Problems

    Troubleshooting 12.3 Flow measurement problems Table 12-3: Flow measurement problems and recommended actions Problem Possible causes Recommended actions Flow indication at no • Misaligned piping (especially in new in- • Verify that all of the characterization parame- flow conditions or stallations) ters match the data on the sensor tag.
  • Page 229 Troubleshooting Table 12-3: Flow measurement problems and recommended actions (continued) Problem Possible causes Recommended actions Erratic non-zero flow • Slug flow • Verify that the sensor orientation is appropri- rate when flow is • Damping value too low ate for your application (refer to the sensor steady •...

  • Page 230: Density Measurement Problems

    Troubleshooting 12.4 Density measurement problems Table 12-4: Density measurement problems and recommended actions Problem Possible causes Recommended actions Inaccurate density • Problem with process fluid • Check the wiring between the sensor and reading • Incorrect density calibration factors transmitter. See Section 12.10.

  • Page 231: Temperature Measurement Problems

    Troubleshooting 12.5 Temperature measurement problems Table 12-5: Temperature measurement problems and recommended actions Problem Possible causes Recommended actions Temperature reading • RTD failure • Check junction box for moisture or verdi- significantly different • Wiring problem gris. from process temper- •...

  • Page 232: Milliamp Output Problems

    Troubleshooting 12.6 Milliamp output problems Table 12-6: Milliamp output problems and recommended actions Problem Possible causes Recommended actions No mA output • Wiring problem • Check the power supply and power supply • Circuit failure wiring. See Section 12.9. • Channel not configured for desired output •...

  • Page 233: Frequency Output Problems

    Troubleshooting Table 12-6: Milliamp output problems and recommended actions (continued) Problem Possible causes Recommended actions mA output consis- • Incorrect process variable or units assigned • Verify the output variable assignments. tently out of range to output • Verify the measurement units configured •...

  • Page 234: Use Sensor Simulation For Troubleshooting

    Troubleshooting Table 12-7: Frequency output problems and recommended actions Problem Possible causes Recommended actions No frequency output • Stopped totalizer • Verify that the process conditions are below • Process condition below cutoff the low-flow cutoff. Reconfigure the low-flow • Fault condition if fault action is set to in- cutoff if necessary.

  • Page 235: Check Power Supply Wiring

    Troubleshooting For more information on using sensor simulation using ProLink II, see Section 7.1. 12.9 Check power supply wiring If the power supply wiring is damaged or improperly connected, the transmitter may not receive enough power to operate properly. Prerequisites You will need the installation manual for your transmitter.

  • Page 236: Check Grounding

    Troubleshooting Prerequisites You will need the installation manual for your transmitter. Procedure Before opening the wiring compartments, disconnect the power source. CAUTION! If the transmitter is in a hazardous area, wait five minutes after disconnecting the power. Verify that the transmitter is connected to the sensor according to the information provided in your transmitter installation manual.
  • Page 237 Troubleshooting Follow appropriate procedures to ensure that loop testing will not interfere with existing measurement and control loops. Procedure Test the mA output(s). a. Choose and select a low value, e.g., 4 mA. Dots traverse the display while the output is fixed. b.

  • Page 238: Perform Loop Tests Using Prolink Ii

    Troubleshooting c. At the transmitter, activate Select. d. Scroll to and select SET OFF. e. Verify the signal at the receiving device. f. At the transmitter, activate Select. Postrequisites • If the mA output reading was slightly off at the receiving device, you can correct this discrepancy by trimming the output.

  • Page 239: Perform Loop Tests Using Prolink Iii

    Troubleshooting i. Click UnFix mA. Test the frequency output(s). Note If the Weights & Measures application is enabled on the transmitter, it is not possible to perform a loop test of the frequency output, even when the transmitter is unsecured. a.
  • Page 240 Troubleshooting Procedure Test the mA output(s). a. Choose Device Tools > Diagnostics > Testing > mA Output 1 Test or Device Tools > Diagnostics > Testing > mA Output 2 Test. b. Enter 4 in Fix to:. c. Click Fix mA. d.

  • Page 241: Perform Loop Tests Using The Field Communicator

    Troubleshooting f. Click UnFix. 12.12.4 Perform loop tests using the Field Communicator Loop tests are not required. However, Micro Motion recommends performing a loop test for every input or output available on your transmitter. The inputs and outputs available on your transmitter vary according to your purchase option and your channel configuration.

  • Page 242: Check For Radio Frequency Interference (Rfi)

    Troubleshooting b. Read the frequency signal at the receiving device and compare it to the transmitter output. c. Choose End. Test the discrete output(s). a. Press Service Tools > Simulate > Simulate Outputs > Discrete Output Test. b. Choose Off. c.

  • Page 243: Check The Hart Communication Loop

    Troubleshooting 12.14 Check the HART communication loop If you cannot establish or maintain HART communications, the HART loop may be wired incorrectly. Prerequisites You will need: • A copy of your transmitter installation manual • A Field Communicator • Optional: the HART Application Guide, available at www.hartcomm.org Procedure Verify that the loop wires are connected as shown in the wiring diagrams in the...

  • Page 244: Check Hart Burst Mode

    Troubleshooting Procedure Set HART Address as appropriate for your HART network. The default address is 0. This is the recommended value unless the transmitter is in a multidrop network. Set Loop Current Mode to Enabled. 12.16 Check HART burst mode HART burst mode can cause the transmitter to output unexpected values.

  • Page 245: Check Frequency Output Maximum Pulse Width

    Troubleshooting • For the relevant status alarms, change the setting of Alarm Severity to Ignore. If there are no active fault conditions, continue troubleshooting. 12.20 Check Frequency Output Maximum Pulse Width If Frequency Output Maximum Pulse Width is set incorrectly, the frequency output may report an incorrect value.

  • Page 246: Check The Cutoffs

    Troubleshooting The Flow Direction parameter interacts with actual flow direction to affect flow values, flow totals and inventories, and output behavior. For the simplest operation, actual process flow should match the flow arrow that is on the side of the sensor case. Procedure Verify the actual direction of process flow through the sensor.

  • Page 247: Check The Drive Gain

    Troubleshooting 12.26 Check the drive gain Excessive or erratic drive gain may indicate any of a variety of process conditions, sensor problems, or configuration problems. To know whether your drive gain is excessive or erratic, you must collect drive gain data during the problem condition and compare it to drive gain data from a period of normal operation.

  • Page 248: Collect Drive Gain Data

    Troubleshooting Table 12-9: Possible causes and recommended actions for erratic drive gain (continued) Possible cause Recommended actions Polarity of pick-off reversed or polarity of drive reversed Contact Micro Motion. Slug flow Check for slug flow. See Section 12.25. Foreign material caught in flow tubes •...

  • Page 249: Collect Pickoff Voltage Data

    Troubleshooting Table 12-10: Possible causes and recommended actions for low pickoff voltage (continued) Possible cause Recommended actions No tube vibration in sensor • Check for plugging. • Ensure sensor is free to vibrate (no mechanical binding). • Verify wiring. • Test coils at sensor.

  • Page 250: Check The Sensor Coils

    Troubleshooting 12.28.1 Check the sensor coils Checking the sensor coils can identify electrical shorts. Restriction This procedure applies only to 9-wire remote-mount transmitters and remote transmitters with remote core processors.. Procedure Disconnect power to the transmitter. CAUTION! If the transmitter is in a hazardous area, wait 5 minutes before continuing. Remove the end-cap from the core processor housing.

  • Page 251: Check The Core Processor Led

    Troubleshooting a. Leave the terminal blocks disconnected. b. Remove the lid of the junction box. c. Testing one terminal at a time, place a DMM lead on the terminal and the other lead on the sensor case. With the DMM set to its highest range, there should be infinite resistance on each lead.
  • Page 252 Troubleshooting a. Remove the core processor lid. The core processor is intrinsically safe and can be opened in all environments. b. Check the state of the core processor LED. If you have an integral installation: a. Loosen the four cap screws that fasten the transmitter to the base. Figure 12-1: Integral installation components Transmitter...
  • Page 253 Troubleshooting Figure 12-2: 9-wire remote installation components Transmitter Core processor 4 x cap screws (4 mm) End-cap b. Inside the core processor housing, loosen the three screws that hold the core processor mounting plate in place. Do not remove the screws. c.

  • Page 254: Core Processor Led States

    Troubleshooting 3. Tighten the screws, torquing to 6 to 8 in-lbs (0.7 to 0.9 N-m). 4. Replace the end-cap. Important When reassembling the meter components, be sure to grease all O-rings. 12.29.1 Core processor LED states Table 12-13: Standard core processor LED states LED state Description Recommended actions...

  • Page 255: Perform A Core Processor Resistance Test

    Troubleshooting Table 12-14: Enhanced core processor LED states (continued) LED state Description Recommended action Solid red High-severity alarm Check alarm status. Flashing red (80% on, 20% off) Tubes not full • If alarm A105 (slug flow) is active, refer to the recommended actions for that alarm.
  • Page 256 Troubleshooting Figure 12-3: Integral installation components Transmitter Transition ring Core processor 4 x cap screws (4 mm) Base b. Rotate the transmitter counter-clockwise so that the cap screws are in the unlocked position. c. Gently lift the transmitter straight up, disengaging it from the cap screws. If you have a 9-wire remote installation: a.
  • Page 257 Troubleshooting At the core processor, disconnect the 4-wire cable between the core processor and the transmitter. Measure the resistance between core processor terminal pairs 3–4, 2–3, and 2–4. Terminal pair Function Expected resistance 3–4 RS-485/A and RS-485/B 40 kΩ to 50 kΩ 2–3 VDC–...
  • Page 258 Troubleshooting ® Micro Motion Model 2700 Transmitters with Analog Outputs...

  • Page 259: Appendix A Using The Transmitter Display

    Using the transmitter display Appendix A Using the transmitter display Topics covered in this appendix: • Components of the transmitter interface • Use the optical switches • Access and use the display menu system • Display codes for process variables •...

  • Page 260: Use The Optical Switches

    Using the transmitter display Figure A-1: Transmitter interface Status LED Display (LCD panel) Process variable Scroll optical switch Optical switch indicator Select optical switch Unit of measure for process variable Current value of process variable Use the optical switches Use the optical switches on the transmitter interface to control the transmitter display. The transmitter has two optical switches: Scroll and Select.

  • Page 261: Access And Use The Display Menu System

    Using the transmitter display Table A-1: Optical switch indicator and optical switch states Optical switch indicator State of optical switches Solid red One optical switch is activated. Flashing red Both optical switches are activated. Access and use the display menu system The display menu system is used to perform various configuration, administrative, and maintenance tasks.

  • Page 262: Enter A Floating-Point Value Using The Display

    Using the transmitter display If you do not know the correct value for Off-Line Password, wait 30 seconds. The password screen will time out automatically and you will be returned to the previous screen. If Scroll flashes on the display, activate the Scroll optical switch, then the Select optical switch, and then the Scroll optical switch again.
  • Page 263 Using the transmitter display Procedure • To change the value: 1. Activate Select until the digit you want to change is active (flashing). Select moves the cursor one position to the left. From the leftmost position, Select moves the cursor to the rightmost digit. 2.
  • Page 264 Using the transmitter display • To exit the menu without saving the displayed value to transmitter memory, activate Scroll and Select simultaneously and hold until the display changes. If the displayed value is the same as the value in transmitter memory, you will be returned to the previous screen.

  • Page 265: Display Codes For Process Variables

    Using the transmitter display b. Activate Scroll until the desired character is displayed. c. Activate Select to move the cursor one digit to the left. d. Activate Scroll until the desired character is displayed. e. Activate Select to move the cursor one digit to the left. f.
  • Page 266 Using the transmitter display Table A-2: Display codes for process variables (continued) Code Definition Comment or reference Field verification zero Weights & Measures application only GSV F Gas standard volume flow GSV I Gas standard volume inventory GSV T Gas standard volume total LPO_A Left pickoff amplitude LVOLI...

  • Page 267: Codes And Abbreviations Used In Display Menus

    Using the transmitter display Codes and abbreviations used in display menus Table A-3: Codes and abbreviations used in display menus Code or abbrevi- ation Definition Comment or reference ACK ALARM Acknowledge alarm ACK ALL Acknowledge all alarms Action ADDR Address AO 1 SRC Fixed to the process variable assigned to the primary out- Analog output 1 (primary mA output)
  • Page 268 Using the transmitter display Table A-3: Codes and abbreviations used in display menus (continued) Code or abbrevi- ation Definition Comment or reference ENABLE ALARM Enable alarm menu Access to alarm menu from display ENABLE AUTO Enable Auto Scroll Enable or disable the Auto Scroll func- tion ENABLE OFFLN Enable off-line...
  • Page 269 Using the transmitter display Table A-3: Codes and abbreviations used in display menus (continued) Code or abbrevi- ation Definition Comment or reference MASS Mass flow MBUS Modbus MFLOW Mass flow MSMT Measurement OFFLN Off-line OFF-LINE MAINT Off-line maintenance P/UNT Pulses/unit POLAR Polarity PRESS...

  • Page 270: Menu Maps For The Transmitter Display

    Using the transmitter display Menu maps for the transmitter display Figure A-2: Offline menu – top level Scroll and Select simultaneously for 4 seconds SEE ALARM OFF-LINE MAINT EXIT Scroll Scroll Select CONFG Scroll Scroll Scroll ZERO SENSOR VERFY* EXIT Scroll Scroll *This option is displayed only if the transmitter is connected to an enhanced core processor and the...
  • Page 271 Using the transmitter display Figure A-3: Offline menu – version information Scroll and Select simultaneously for 4 seconds Scroll OFF-LINE MAINT Select Scroll Select Version info Scroll CEQ/ETO info* Scroll ED/API info* Scroll CUSTODY XFER* Scroll SENSOR VERFY* Scroll EXIT *The option is displayed only if the corresponding CEQ/ ETO or application is installed on the transmitter.
  • Page 272 Using the transmitter display Figure A-4: Offline menu – configuration: units and I/O Scroll and Select simultaneously for 4 seconds Scroll OFF-LINE MAINT Select Scroll CONFG Select UNITS Scroll Select Select CH A Scroll CH B MASS Select Select Scroll AO 1 SRC Scroll VOL/GSV...
  • Page 273 Using the transmitter display Figure A-5: Offline menu – configuration: meter factor, display, and digital communications Scroll and Select simultaneously for 4 seconds Scroll OFF-LINE MAINT Select Scroll CONFG Select UNITS Scroll MTR F Scroll DISPLAY Scroll COMM Scroll LOCK Select Select Select...
  • Page 274 Using the transmitter display Figure A-6: Offline menu – alarms Scroll and Select simultaneously for 4 seconds SEE ALARM Select ACK ALL* Select Scroll EXIT Select Scroll Active/ unacknowledged alarms? Alarm code NO ALARM Scroll Select Scroll EXIT Select Scroll *This screen is displayed only if the ACK ALL function s enabled and there are unacknowledged alarms.
  • Page 275 Using the transmitter display Figure A-7: Offline menu – meter verification: top level Scroll and Select simultaneously for 4 seconds Scroll ENTER METER VERFY Select RUN VERFY RESULTS READ SCHEDULE VERFY EXIT Scroll Scroll Scroll Select Select Select Scroll Select Figure A-8: Offline menu –...
  • Page 276 Using the transmitter display Figure A-9: Offline menu – meter verification test RUN VERFY Select OUTPUTS EXIT Scroll Select CONTINUE MEASR FAULT LAST VALUE EXIT Scroll Scroll Scroll Select Select Select ARE YOU SURE/YES? Select ....x% SENSOR ABORT/YES? Select Scroll...
  • Page 277 Using the transmitter display Figure A-10: Offline menu – meter verification results RESULTS READ Select RUNCOUNT x Select Scroll Pass Result type Abort Fail xx HOURS xx HOURS xx HOURS Select Select Select PASS CAUTION Abort Type Select Select Select xx L STF% xx L STF% Select...
  • Page 278 Using the transmitter display Figure A-11: Offline menu – totalizers and inventories Process variable display Scroll Mass total Volume total Scroll Scroll Select E1--SP EXIT Scroll Scroll E2--SP STOP/START RESET Scroll Scroll Select Select STOP/START YES? RESET YES? Select Scroll Select Scroll The Event Setpoint screens can be used to define or change the setpoint for Event 1 or Event 2 in the basic event model.
  • Page 279 Using the transmitter display Figure A-12: Offline menu – Simulation (loop testing) Scroll and Select simultaneously for 4 seconds Scroll OFF-LINE MAINT Select Scroll Select AO SIM FO SIM DO SIM Scroll Scroll Select Select Select SET ON SET x MA* SET y KHZ**** Select** Select**...
  • Page 280 Using the transmitter display Figure A-13: Offline menu – Zero Scroll and Select simultaneously for 4 seconds Scroll OFF-LINE MAINT Select Scroll ZERO Select CAL ZERO RESTORE ZERO EXIT Scroll Scroll Select Select ZERO/YES? Current zero display Scroll Scroll Select ………………….

  • Page 281: Appendix B Using Prolink Ii With The Transmitter

    Using ProLink II with the transmitter Appendix B Using ProLink II with the transmitter Topics covered in this appendix: • Basic information about ProLink II • Connect with ProLink II • Menu maps for ProLink II Basic information about ProLink II ProLink II is a software tool available from Micro Motion.

  • Page 282: Connect With Prolink Ii

    Using ProLink II with the transmitter ProLink II messages As you use ProLink II with a Micro Motion transmitter, you will see a number of messages and notes. This manual does not document all of these messages and notes. Important The user is responsible for responding to messages and notes and complying with all safety messages.

  • Page 283: Make A Service Port Connection

    Using ProLink II with the transmitter B.2.2 Make a service port connection CAUTION! If the transmitter is in a hazardous area, do not use a service port connection. Service port connections require opening the wiring compartment, and opening the wiring compartment while the transmitter is powered up could cause an explosion.

  • Page 284: Make A Hart/Bell 202 Connection

    Using ProLink II with the transmitter Figure B-1: Connection to service port A. PC B. Signal converter C. Service port terminal 7 (RS-485/A) D. Service port terminal 8 (RS-485/B) E. Transmitter, with wiring compartment and power supply compartment opened Note This figure shows a serial port connection.
  • Page 285 Using ProLink II with the transmitter CAUTION! If the transmitter is in a hazardous area, do not connect directly to the transmitter terminals. Connecting directly to the transmitter terminals requires opening the wiring compartment, and opening the wiring compartment while the transmitter is powered up could cause an explosion.
  • Page 286 Using ProLink II with the transmitter Figure B-2: Connection to transmitter terminals A. PC B. Signal converter Ω resistance C. 250–600 D. Transmitter, with wiring compartment and power supply compartment opened Note This figure shows a serial port connection. USB connections are also supported. To connect from a point in the local HART loop: a.
  • Page 287 Using ProLink II with the transmitter Figure B-3: Connection over local loop A. PC B. Signal converter C. Any combination of resistors R1, R2, and R3 as necessary to meet HART communication resistance requirements D. DCS or PLC E. Transmitter, with wiring compartment and power supply compartment opened Note This figure shows a serial port connection.
  • Page 288 Using ProLink II with the transmitter Figure B-4: Connection over multidrop network A. Signal converter Ω resistance B. 250–600 C. Devices on the network D. Master device Start ProLink II. Choose Connection > Connect to Device. Set Protocol to HART Bell 202. HART/Bell 202 connections use standard connection parameters.

  • Page 289: Make A Hart/Rs-485 Connection

    Using ProLink II with the transmitter Option Description Primary Use this setting if no other host is on the network. The Field Communicator is not a host. Click Connect. Need help? If an error message appears: • Verify the HART address of the transmitter. •...
  • Page 290 Using ProLink II with the transmitter HART connections are not polarity-sensitive. It does not matter which lead you attach to which terminal. Figure B-5: Connection to transmitter terminals A. PC B. Signal converter C. Transmitter, with wiring compartment and power supply compartment opened Note This figure shows a serial port connection.
  • Page 291 Using ProLink II with the transmitter Figure B-6: Connection over network A. PC B. Signal converter Ω , 1/2-watt resistors at both ends of the segment, if necessary C. 120- D. DCS or PLC E. Transmitter, with wiring compartment and power supply compartment opened Note This figure shows a serial port connection.

  • Page 292: Make A Modbus/Rs-485 Connection

    Using ProLink II with the transmitter Option Description Secondary Use this setting if another HART host such as a DCS is on the network. Primary Use this setting if no other host is on the network. The Field Communicator is not a host.
  • Page 293 Using ProLink II with the transmitter Usually, but not always, the black lead is RS-485/A and the red lead is RS-485/B. Figure B-7: Connection to transmitter terminals A. PC B. Signal converter C. Transmitter, with wiring compartment and power supply compartment opened Note This figure shows a serial port connection.
  • Page 294 Using ProLink II with the transmitter Figure B-8: Connection over network A. PC B. Signal converter Ω , 1/2-watt resistors at both ends of the segment, if necessary C. 120- D. DCS or PLC E. Transmitter, with wiring compartment and power supply compartment opened Note This figure shows a serial port connection.

  • Page 295: Menu Maps For Prolink Ii

    Using ProLink II with the transmitter Need help? If an error message appears: • Verify the Modbus address of the transmitter. • Ensure that you have specified the correct COM port. • Check the physical connection between the PC and the transmitter. •...
  • Page 296 Using ProLink II with the transmitter Figure B-10: Main menu (continued) ProLink Tools Plug-ins Gas Unit Configurator Data Logging* Meter Verification Entrained Gas Analyzer Enable/Disable Commissioning Wizard Custody Transfer Proving Wizard Marine Bunker Transfer Options Configuration Output Levels Process Variables Status Alarm Log Diagnostic Information...
  • Page 297 Using ProLink II with the transmitter Figure B-11: Configuration menu ProLink > Configuration Additional configuration options Flow T Series Density • Flow Direction • Dens Units • FTG • Flow Damp • FFQ • Dens Damping • Flow Cal • DTG •...
  • Page 298 Using ProLink II with the transmitter Figure B-12: Configuration menu (continued) ProLink > Configuration Additional configuration options Analog Output Frequency/Discrete Output Primary Output • Frequency • PV is • Tertiary Variable • LRV • Freq Factor • URV • Rate Factor •...
  • Page 299 Using ProLink II with the transmitter Figure B-13: Configuration menu (continued) ProLink > Configuration Additional configuration options Device Discrete Input • Model • Start Sensor Zero • Manufacturer • Reset Mass Total • Hardware Rev • Reset Volume Total • Distributor •...
  • Page 300 Using ProLink II with the transmitter Figure B-14: Configuration menu (continued) ProLink > Configuration Additional configuration options RS-485 Events Discrete Events • Protocol Event 1/2 • Event Name • Parity • Variable • Event Type • Baud Rate • Type •...
  • Page 301 Using ProLink II with the transmitter Figure B-15: Configuration menu (continued) ProLink > Configuration Additional configuration options Variable mapping Display • PV is • mA1 • SV is • Var1...Var15 • TV is • Display Precision • QV is • Var •...
  • Page 302 Using ProLink II with the transmitter Figure B-16: Configuration menu (continued) ProLink > Configuration Additional configuration options CM Setup Transmitter Options • Active Curve • Volume Flow • Derived Variable • Meter Fingerprinting • Reset All Curve Info • Cryogenic Moduls •...
  • Page 303 Using ProLink II with the transmitter Figure B-17: Configuration menu (continued) ProLink > Configuration Additional configuration options API Setup Sensor • Generalized Crude or JP4 • Sensor s/n • Generalized Products • Sensor Model • User Defined TEC • Sensor Matl •...
  • Page 304 Using ProLink II with the transmitter Figure B-18: Configuration menu (continued) ProLink > Configuration Sensor Simulation Channel • Enable/disable • Channel A • Mass flow • Channel B • Wave form • Type Assignment • Fixed value • Power Type •...

  • Page 305: Appendix C Using Prolink Iii With The Transmitter

    Using ProLink III with the transmitter Appendix C Using ProLink III with the transmitter Topics covered in this appendix: • Basic information about ProLink III • Connect with ProLink III • Menu maps for ProLink III Basic information about ProLink III ProLink III is a configuration and service tool available from Micro Motion.

  • Page 306: Connect With Prolink Iii

    Using ProLink III with the transmitter ProLink III messages As you use ProLink III with a Micro Motion transmitter, you will see a number of messages and notes. This manual does not document all of these messages and notes. Important The user is responsible for responding to messages and notes and complying with all safety messages.

  • Page 307: Make A Service Port Connection

    Using ProLink III with the transmitter C.2.2 Make a service port connection CAUTION! If the transmitter is in a hazardous area, do not use a service port connection. Service port connections require opening the wiring compartment, and opening the wiring compartment while the transmitter is powered up could cause an explosion.

  • Page 308: Make A Hart/Bell 202 Connection

    Using ProLink III with the transmitter Figure C-1: Connection to service port A. PC B. Signal converter C. Service port terminal 7 (RS-485/A) D. Service port terminal 8 (RS-485/B) E. Transmitter, with wiring compartment and power supply compartment opened Note This figure shows a serial port connection.
  • Page 309 Using ProLink III with the transmitter CAUTION! If the transmitter is in a hazardous area, do not connect directly to the transmitter terminals. Connecting directly to the transmitter terminals requires opening the wiring compartment, and opening the wiring compartment while the transmitter is powered up could cause an explosion.
  • Page 310 Using ProLink III with the transmitter Figure C-2: Connection to transmitter terminals A. PC B. Signal converter Ω resistance C. 250–600 D. Transmitter, with wiring compartment and power supply compartment opened Note This figure shows a serial port connection. USB connections are also supported. To connect from a point in the local HART loop: a.
  • Page 311 Using ProLink III with the transmitter Figure C-3: Connection over local loop A. PC B. Signal converter C. Any combination of resistors R1, R2, and R3 as necessary to meet HART communication resistance requirements D. DCS or PLC E. Transmitter, with wiring compartment and power supply compartment opened Note This figure shows a serial port connection.
  • Page 312 Using ProLink III with the transmitter Figure C-4: Connection over multidrop network A. Signal converter Ω resistance B. 250–600 C. Devices on the network D. Master device Start ProLink III. Choose Connect to Physical Device. Set Protocol to HART Bell 202. HART/Bell 202 connections use standard connection parameters.

  • Page 313: Make A Hart/Rs-485 Connection

    Using ProLink III with the transmitter Option Description Primary Use this setting if no other host is on the network. The Field Communicator is not a host. Click Connect. Need help? If an error message appears: • Verify the HART address of the transmitter. •...
  • Page 314 Using ProLink III with the transmitter HART connections are not polarity-sensitive. It does not matter which lead you attach to which terminal. Figure C-5: Connection to transmitter terminals A. PC B. Signal converter C. Transmitter, with wiring compartment and power supply compartment opened Note This figure shows a serial port connection.
  • Page 315 Using ProLink III with the transmitter Figure C-6: Connection over network A. PC B. Adapter, if necessary C. Signal converter Ω , 1/2-watt resistors at both ends of the segment, if necessary D. 120- E. DCS or PLC F. Transmitter, with wiring compartment and power supply compartment opened Note This figure shows a serial port connection.

  • Page 316: Make A Modbus/Rs-485 Connection

    Using ProLink III with the transmitter Set Master as appropriate. Option Description Secondary Use this setting if another HART host such as a DCS is on the network. Primary Use this setting if no other host is on the network. The Field Communicator is not a host.
  • Page 317 Using ProLink III with the transmitter b. Connect the leads from the signal converter to terminals 5 (RS-485/A) and 6 (RS-485/B). Usually, but not always, the black lead is RS-485/A and the red lead is RS-485/B. Figure C-7: Connection to transmitter terminals A.
  • Page 318 Using ProLink III with the transmitter Figure C-8: Connection over network A. PC B. Signal converter Ω , 1/2-watt resistors at both ends of the segment, if necessary C. 120- D. DCS or PLC E. Transmitter, with wiring compartment and power supply compartment opened Note This figure shows a serial port connection.

  • Page 319: Menu Maps For Prolink Iii

    Using ProLink III with the transmitter Need help? If an error message appears: • Verify the Modbus address of the transmitter. • Ensure that you have specified the correct COM port. • Check the physical connection between the PC and the transmitter. •...
  • Page 320 Using ProLink III with the transmitter Figure C-10: Device Tools: Configuration (with Weights & Measures) Figure C-11: Configuration: Process Measurement (with Concentration Measurement) ® Micro Motion Model 2700 Transmitters with Analog Outputs...
  • Page 321 Using ProLink III with the transmitter Figure C-12: Configuration: Process Measurement (with Petroleum Measurement) Figure C-13: Configuration: I/O Configuration and Use Manual...
  • Page 322 Using ProLink III with the transmitter Figure C-14: Configuration: Transmitter Display Figure C-15: Configuration: Events ® Micro Motion Model 2700 Transmitters with Analog Outputs...
  • Page 323 Using ProLink III with the transmitter Figure C-16: Configuration: Communications Figure C-17: Configuration: Informational Parameters Configuration and Use Manual...
  • Page 324 Using ProLink III with the transmitter Figure C-18: Device Tools: Calibration Figure C-19: Calibration: Density Calibration ® Micro Motion Model 2700 Transmitters with Analog Outputs...
  • Page 325 Using ProLink III with the transmitter Figure C-20: Calibration: Temperature Calibration Figure C-21: Device Tools: Configuration Transfer Configuration and Use Manual...
  • Page 326 Using ProLink III with the transmitter Figure C-22: Diagnostics: Testing Figure C-23: Diagnostics: Meter Verification ® Micro Motion Model 2700 Transmitters with Analog Outputs...
  • Page 327 Using ProLink III with the transmitter Figure C-24: Device Tools: Trending Configuration and Use Manual...
  • Page 328 Using ProLink III with the transmitter ® Micro Motion Model 2700 Transmitters with Analog Outputs...

  • Page 329: Appendix D Using The Field Communicator With The Transmitter

    Using the Field Communicator with the transmitter Appendix D Using the Field Communicator with the transmitter Topics covered in this appendix: • Basic information about the Field Communicator • Connect with the Field Communicator • Menu maps for the Field Communicator Basic information about the Field Communicator The Field Communicator is a handheld configuration and management tool that can be...

  • Page 330: Connect With The Field Communicator

    Using the Field Communicator with the transmitter If Micro Motion is not listed, or you do not see the required device description, use the Field Communicator Easy Upgrade Utility to install the device description, or contact Micro Motion. Field Communicator menus and messages Many of the menus in this manual start with the On-Line menu.
  • Page 331 Using the Field Communicator with the transmitter Figure D-1: Field Communicator connection to transmitter terminals A. Field Communicator Ω resistance B. 250–600 C. Transmitter, with wiring compartment and power supply compartment opened To connect to a point in the local HART loop, attach the leads from the Field Communicator to any point in the loop and add resistance as necessary.

  • Page 332: Menu Maps For The Field Communicator

    Using the Field Communicator with the transmitter Figure D-3: Field Communicator connection to multidrop network A. Field Communicator Ω resistance B. 250–600 C. Devices on the network D. Master device Turn on the Field Communicator and wait until the main menu is displayed. If you are connecting across a multidrop network: a.
  • Page 333 Using the Field Communicator with the transmitter Figure D-4: On-Line menu On-Line Menu Overview 1 Check Status 2 Primary Purpose Variables 3 Shortcuts Configure 1 Manual Setup 2 Alert Setup Service Tools 1 Alerts 2 Variables 3 Trends 4 Maintenance 5 Simulate Configuration and Use Manual...
  • Page 334 Using the Field Communicator with the transmitter Figure D-5: Overview menu On-Line Menu > 1 Overview Shortcuts 1 Device Information 2 Totalizer Control Check Status 3 Zero Calibration 1 Refresh Alerts 4 Variables 2 Dev Status: 5 Trends 3 Comm Status: 6 Meter Verification * Device Information 1 Identification...
  • Page 335 Using the Field Communicator with the transmitter Figure D-6: Configure menu On-Line Menu > 1 Configure Manual Setup 1 Characterize 2 Measurements 3 Display 4 Inputs/Outputs 5 Info Parameters Alert Setup 1 I/O Fault Actions 2 Alert Severity 3 Discrete Events 4 CM Alerts Configuration and Use Manual...
  • Page 336 Using the Field Communicator with the transmitter Figure D-7: Manual Setup menu On-Line Menu > 2 Configure > 1 Manual Setup Characterize Inputs/Outputs 1 Sensor Type 1 Channels 2 Sensor Tag Parameters 2 mA Output 3 Frequency Output 4 Discrete Output 5 Communications Measurements 6 Variable Mapping...
  • Page 337 Using the Field Communicator with the transmitter Figure D-8: Manual Setup menu: Characterize On-Line Menu > 2 Configure > 1 Manual Setup > 1 Characterize Sensor Type 1 Curved Tube 2 Straight Tube Curved Tube Sensor Type Straight Tube Sensor Tag Parameters Sensor Tag Parameters 1 FlowCal 1 Flow Parameters...
  • Page 338 Using the Field Communicator with the transmitter Figure D-9: Manual Setup menu: Measurements On-Line Menu > 2 Configure > 1 Manual Setup > 2 Measurements Additional options Flow Temperature 1 Flow Direction 1 Temperature Unit 2 Flow Damping 2 Temp Damping 3 Mass Flow Unit 4 Mass Flow Cutoff 5 Volume Flow Unit *...
  • Page 339 Using the Field Communicator with the transmitter Figure D-10: Manual Setup menu: Measurements (continued) On-Line Menu > 2 Configure > 1 Manual Setup > 2 Measurements Petroleum Measurement * External Pressure/Temperature 1 2540 CTL Table type 1 Pressure 2 TEC 2 Temperature 3 Ref Temperature 3 External Polling...
  • Page 340 Using the Field Communicator with the transmitter Figure D-11: Manual Setup menu: Display On-Line Menu > 2 Configure > 1 Manual Setup > 3 Display Language Backlight English 1 Control German 2 Intensity (0-63) French Spanish Display Variables 1 Display Variables (1-5) 2 Display Variables (6-10) Display Variable Menu Features 3 Display Variables (11-15)
  • Page 341 Using the Field Communicator with the transmitter Figure D-12: Manual Setup menu: I/O On-Line Menu > 2 Configure > 1 Manual Setup > 4 Inputs/Outputs Additional options Channels Frequency Output 1 Channel A 1 FO Settings 2 Channel B 2 FO Fault Parameters 3 Channel C 3 FO Scaling Channel B...
  • Page 342 Using the Field Communicator with the transmitter Figure D-13: Manual Setup menu: I/O (continued) On-Line Menu > 2 Configure > 1 Manual Setup > 4 Inputs/Outputs Discrete Output Map Variables 1 DO Assignment 1 Primary Variable 2 DO Polarity 2 Secondary Variable 3 DO Fault Action 3 Third Variable 4 Flow Switch Source...
  • Page 343 Using the Field Communicator with the transmitter Figure D-14: Alert Setup menu On-Line Menu > 2 Configure > 2 Alert Setup Discrete Events 1 Discrete Event 1 2 Discrete Event 2 I/O Fault Action 3 Discrete Event 3 1 MAO Fault Action 4 Discrete Event 4 2 MAO Fault Level 5 Discrete Event 5...
  • Page 344 Using the Field Communicator with the transmitter Figure D-15: Service Tools menu On-Line Menu > 3 Service Tools Alerts Maintenance 1 Refresh Alerts 1 Routine Maintenance Alert Name 2 Zero Calibration 3 Density Calibration Additional Information 4 Temperature Calibration 5 Diagnostic Variables 6 Modbus Data Variables 1 Variable Summary...
  • Page 345 Using the Field Communicator with the transmitter Figure D-16: Service Tools menu: Variables On-Line Menu > 3 Service Tools > 2 Variables Variable Summary Totalizer Control Mass Flow Rate 1 All Totalizers Volume Flow Rate * 2 Mass Density 3 Volume * 4 CM Volume at Reference Temperature 5 CM Net Mass *** 6 CM Net Volume ***...
  • Page 346 Using the Field Communicator with the transmitter Figure D-17: Service Tools menu: Variables (continued) On-Line Menu > 3 Service Tools > 2 Variables Variables (PM) * Outputs 1 Density at Reference 1 mA Output (MA0) Temperature 2 Frequency Output 2 Average Observed Density 3 Volume Flow at Reference Temperature mA Output...
  • Page 347 Using the Field Communicator with the transmitter Figure D-18: Service Tools menu: Maintenance On-Line Menu > 3 Service Tools > 4 Maintenance Routine Maintenance Temperature Calibration 1 Trim mA Output 1 Temperature 2 Meter Verification * 2 Temp Cal Factor Diagnostic Variables Meter Verification ** 1 Sensor Model...
  • Page 348 Using the Field Communicator with the transmitter Figure D-19: Service Tools menu: Simulate On-Line Menu > 3 Service Tools > 5 Simulate Simulate Outputs 1 mA Output Loop Test 2 Frequency Output Test/ Discrete Output Test * Simulate Sensor 1 Simulate Primary Purpose Variables 2 Mass Flow Rate 3 Density 4 Temperature...

  • Page 349: Appendix E Default Values And Ranges

    Default values and ranges Appendix E Default values and ranges Default values and ranges The default values and ranges represent the typical factory transmitter configuration. Depending on how the transmitter was ordered, certain values may have been configured at the factory and are not represented in the default values and ranges. Table E-1: Transmitter default values and ranges Type...
  • Page 350 Default values and ranges Table E-1: Transmitter default values and ranges (continued) Type Parameter Default Range Comments Density units g/cm Density cutoff 0.2 g/cm 0.0 – 0.5 g/cm 0 g/cm 1 g/cm 1000 µsec 1000 – 50,000 µsec 50,000 µsec 1000 –...
  • Page 351 Default values and ranges Table E-1: Transmitter default values and ranges (continued) Type Parameter Default Range Comments Base volume time Volume flow conversion factor Variable map- Primary variable Mass flow ping Secondary variable Density Tertiary variable Mass flow Quaternary variable Volume flow mA output 1 Primary variable...
  • Page 352 Default values and ranges Table E-1: Transmitter default values and ranges (continued) Type Parameter Default Range Comments Fault action Downscale AO fault level – downscale 2.0 mA 1.0 – 3.6 mA AO fault level – upscale 22 mA 21.0 – 24.0 mA Last measured value timeout 0.00 sec −200.000 g/s...
  • Page 353 Default values and ranges Table E-1: Transmitter default values and ranges (continued) Type Parameter Default Range Comments Polarity Active low Display Backlight on/off Backlight intensity 0 – 63 Refresh rate 200 millisec- 100 – 10,000 onds milliseconds Variable 1 Mass flow rate Variable 2 Mass total Variable 3...
  • Page 354 Default values and ranges ® Micro Motion Model 2700 Transmitters with Analog Outputs...

  • Page 355: Appendix F Transmitter Components And Installation Wiring

    Transmitter components and installation wiring Appendix F Transmitter components and installation wiring Topics covered in this appendix: • Installation types • Power supply terminals and ground • Input/output (I/O) wiring terminals Installation types Model 1700 and Model 2700 transmitters can be installed five different ways, only one of which applies to your specific installation.
  • Page 356 Transmitter components and installation wiring Figure F-2: High-temperature flexible conduit installation High-temperature flexible conduit installations use the same installation instructions as 4-wire remote installations, except that the distance between the sensor and the electronics is limited by the length of the flexible conduit. •...
  • Page 357 Transmitter components and installation wiring Figure F-4: 4-wire remote installation – stainless steel housing Transmitter Core processor 4-wire cable Sensor • 9-wire remote – The transmitter and core processor are combined in a single unit that is installed remotely from the sensor. You need to mount the transmitter/core processor assembly separately from the sensor, connect a 9-wire cable between the transmitter/core processor, and connect power and I/O wiring to the transmitter.
  • Page 358 Transmitter components and installation wiring Figure F-5: 9-wire remote installation type Transmitter Junction box 9-wire cable Sensor • Remote core processor with remote sensor – A remote core process with remote sensor installation separates all three components – transmitter, core processor, and sensor –...

  • Page 359: Power Supply Terminals And Ground

    Transmitter components and installation wiring Figure F-6: Remote core processor with remote sensor installation type Transmitter 4-wire cable Core processor Junction box 9-wire cable Sensor Power supply terminals and ground Figure F-7: Power supply wiring terminals Warning flap Equipment ground Power supply wiring terminals (9 and 10) Configuration and Use Manual...

  • Page 360: Input/Output (I/O) Wiring Terminals

    Transmitter components and installation wiring Input/output (I/O) wiring terminals Figure F-8: I/O wiring terminals mA/HART Frequency output or discrete output RS-485 ® Micro Motion Model 2700 Transmitters with Analog Outputs...

  • Page 361: Appendix G Ne 53 History

    NE 53 history Appendix G NE 53 history NE 53 history Operating in- Date Version Type Change struction 08/2000 Expansion Added writing of the device tag using Modbus 3600204 A Adjustment Improved communication handling with the HART Tri-Loop product Feature Indication of outputs option board type appears on display at power-up 05/2001...
  • Page 362 NE 53 history Operating in- Date Version Type Change struction The display start/stop totalizers function can be enabled or disabled Petroleum measurement application improve- ments Live zero available as display variable Increased options for fault output settings New cryogenic application temperature algo- rithms Adjustment Improved frequency output stability and unit...
  • Page 363 NE 53 history Operating in- Date Version Type Change struction 09/2006 Expansion Discrete output assignable as a flow switch 20001715 B Discrete output fault indication configurability Discrete input support for multiple action as- signments Added support for querying the display LED sta- tus via Modbus Additional HART and Modbus commands Process comparator expanded to five configura-...
  • Page 364 NE 53 history Operating in- Date Version Type Change struction Adjustment The following combinations are not allowed: • mA Output Fault Action = None and Digital Communications Fault Action = NAN • Frequency Output Fault Action = None and Digital Communications Fault Action = NAN Display variables set to a volume process varia- ble automatically switch between liquid and GSV, according to current setting of Volume...

  • Page 365: Index

    Index Index using ProLink III using the Field Communicator Added Damping temperature Additional Communications Response Delay calibration parameters, See characterizing address calibration pressure, See pressure compensation HART address 124, 129 channel configuration Modbus address characterizing air calibration, See calibration, density density parameters alarm menu, See display flow calibration parameters...
  • Page 366 Index restore factory configuration density measurement using ProLink II configuring using ProLink III cutoff temperature measurement configuring volume flow measurement effect on volume measurement Weights & Measures, See Weights & Measures damping application effect on volume measurement write-protection interaction with added damping 21, 138 connection measurement units...
  • Page 367 Index polarity Enhanced Event Action configuring configuring options options source event models configuring exponential notation, See display, exponential notation options display accessing menu system Fault Action components affected by Fault Timeout configuring display behavior digital communications Auto Scroll discrete outputs backlight frequency outputs display language...
  • Page 368 Index using the display using the Field Communicator I/O terminals maximum pulse width informational parameters polarity installation types configuring 4-wire remote options 9-wire remote process variable high-temperature flexible conduit configuring integral options remote core processor with remote transmitter scaling method inventories configuring resetting...
  • Page 369 Index process variable meter verification, See Smart Meter Verification configuring metrological security, See Weights & Measures options application scaling Modbus troubleshooting Additional Communications Response Delay 224, 236 mass flow measurement address configuring configuring Modbus/RS-485 digital cutoff communications configuring Floating-Point Byte Order effect on volume measurement model code interaction with AO cutoff...
  • Page 370 Index using ProLink III protocols using the Field Communicator proving, See meter validation polling address, See HART address pulse width power power up power supply terminals quaternary variable (QV) power supply wiring troubleshooting pressure compensation configuring radio frequency interference (RFI) using ProLink II troubleshooting using the Field Communicator...
  • Page 371 Index slave address, See Modbus address system testing slug flow, See density measurement, slug flow using ProLink II Smart Meter Verification using the Field Communicator automatic execution and scheduling Thermal Expansion Coefficient (TEC) using ProLink II totalizers using ProLink III displaying values and Weights &...
  • Page 372 Index unsecured, See Weights & Measures application regulatory agencies Update Period replacing the core processor Update Rate sealing 140, 143 configuring secured vs. unsecured effect on process measurement security types incompatible functions setting up Upper Range Value (URV) using ProLink II using ProLink III Status Alarm A027:Security Breach 139, 170...
  • Page 374 © Micro Motion Japan 2012 Micro Motion, Inc. All rights reserved. Emerson Process Management The Emerson logo is a trademark and service mark of Emerson 1-2-5, Higashi Shinagawa Electric Co. Micro Motion, ELITE, ProLink, MVD and MVD Direct Shinagawa-ku Connect marks are marks of one of the Emerson Process Tokyo 140-0002 Japan Management family of companies.

Table of Contents

Save PDF
