7.2.14 ESD Parameters (Parameter 97 - 101) ............................................................74
7.2.15 Interlock enable (Parameter 102) .....................................................................74
7.2.16 Open Limit position (Parameter 103) ...............................................................74
7.2.17 Interrupter Timer parameters (104 - 108) ........................................................74
7.2.28 Language used (Parameter 109) .....................................................................75
7.2.28 IDs and notes (Parameters 111 - 120) .............................................................75
8 SETTING UP AND MAINTAINING THE PROFIBUS MODULE ....................... 77
8.1 Using a Network Configuration Tool ...................................................................................77
8.1.1
8.1.2
8.2 Setting up the network address in the PFU .......................................................................79
8.3 Setting up an IQ or IQT with the Infra-red Setting Tool .....................................................79
8.3 Setting up a Skil or EH with the Infra-red Setting Tool .....................................................81
8.3 Maintenance and Repair .......................................................................................................81
8.4 Records ..................................................................................................................................82

Glossary of Terms:

Address
Fieldbus
Field Unit
Interoperability
Master/Slave
Profibus DP
Profibus DP-V0 and DP-V1
PNO
RedCom
Node
RS485
Segment

Abbreviations:

Comms Communications
DTM Device Type Manager
EDD Electronic Device Description
FDT Field Device Tool
GSD Generic Station Description
FDT (Field Device Tool) ...................................................................................77
PDM (Process Device Manager) ......................................................................78
The unique address for a node on the fieldbus, range 0-126
The digital, two-way, multi-drop Profibus DP communication link
The Profibus option card fitted to the actuator
The capability for a device from one manufacturer to interact with that
of another manufacturer, on a fieldbus network, without loss of
functionality
The method of communication used by the Profibus DP Module. The
fieldbus requires a Profibus master to control the data exchange on
the highway.
The communication protocol used on the highway.
The cyclic (V0) and acyclic (V1) versions of the protocol supported by
the Rotork module.
Profibus Nutzerorganisation - Profibus User Group, Germany
Dual redundant system as defined in PNO 2.212
A single device on the fieldbus
The electrical properties of the data highway as defined by the IEC
61158 standard, copper conductors, 2-wire twisted pair.
A section of an RS485 fieldbus that is correctly terminated in its
characteristic impedance. Each Segment can include up to 32
devices.
Publication PUB088-005-00_1017
PFU Profibus Field Unit
RAM Random Access Memory
ROM Read Only Memory
RTU Remote Terminal Unit
SW Software
Contents
5 of 84
