rotork Remote Control Series Manual

RCEL
SA PCU
CAUTION
ELECTRICAL SHOCK HAZARD.To avoid serious personal injury,
property damage, turn off ALL power to the actuator before remov-
ing the cover.
Before installation or use, verify the nameplate information infor-
mation to insure the correct model number, torque, voltage and
enclosure type.
Be sure to completly review the actuator manual prior to operation.
Final limit switch adjustment MUST be done after mounting the ac-
tuator to the valve. Incorrect adjustment may cause actuator failure.
Over torque switches are factory set, tampering with the over
torque switch settings may damage the actuator and void the war-
ranty.
The actuator must be properly grounded. Use the grounding lugs
provided on the inside and outside of the actuator body.
To minimize the possible damage caused by condensation, be sure
to energize the heater.
The warranty will be void under the following conditions:
1. Failure or damage caused by misuse or abuse.
2. Failure or damage caused by unauthorized modifications or repairs done to the actuator.
3. Failure caused by the unauthorized modification / change or the wiring.
4. Failure caused by a reverse phase mis-wire when using three phase power.
5. Failure caused by water leakage due to the improper sealing of the actuator conduit entries or by failure
to install the cover properly.
6. Failure caused by improperly set limit switches.
7. Failure caused by fire, flood damage or other natural disasters.
8. Failure occuring more than one year after shipment date.
Warranty Information
www.rotork.com www.remotecontrol.se
Manual
Specifications
Input Power
Command Signal
Dead Band
Output Signal
Load Resistance
Wiring Terminals
Visual Indicators
Calibration Method
Output Contact
User Adjustable
Parameters
Resolution
Ambient Temperatur
Ambient Humidity
Dielectric Strenght
Insulation Resistance 500V DC 30MΩ MIN.
- 1 -
Top Quality Valve Actuators
Made in Sweden
90~230V AC ±10%, 50/60Hz
DC 24V / AC 24V
Input Power must match motor Ratings
4~20mA DC (Default), 0~5VDC,
0~10VDC, 1~5VDC, 2~10VDC
1 ~ 7,5% (1 scale 0,5%)
4~20mA DC
750Ω
YW 396 2P(3EA), 3P, 5P connector
4 LEDS,
Power (Blue), Fault (Yellow),
Open (Red), Close (Green)
ASCN (Autoscan) Button
Relay Contact 250V AC 16A MAX.
(Inductive Load)
Delay Time: 0.5 Sec (Step)
Dead Band: 0.2mA(Step)
Fail operation (during loss of command
signal) Select input signal. A FULL Set
or Clear
Min 1/1,000
-10 ºC ~ +60 ºC
90% RH MAX. (Non-Condensing)
1,500V AC 1 MIN.
(Input to Output to Power to Ground)
