rotork Profibus Modbus Module Mk2 Installation Manual page 69

Parameter
Data
No.
'PO' contact S4
86 Function for Indication contact S5
87 Function for Indication contact S6
88 Function for Indication contact S7
89 Function for Indication contact S8
90 Position trip when function set to
'PO' contact S5
91 Position trip when function set to
'PO' contact S6
92 Position trip when function set to
'PO' contact S7
93 Position trip when function set to
'PO' contact S8
94 - 96 For future use
97 ESD direction
98 ESD contact
99 ESD bypasses the actuator
interlocks
100 ESD bypasses the Thermostat trip
101 ESD bypasses Local stop
102 Bits0 to 5 - reserved
Bit6 – Interlocks enable / disable
Bits7 to 15 - reserved
103 Open limit position
104 Interrupter timer start limit
105 Interrupter timer off time
106 Interrupter timer on time
107 Interrupter timer activated when
opening if below xx%
108 Interrupter timer activated when
closing if below xx%
109 Bits0 to 4 - reserved
bit5 – Language
Bits6 to 15 - reserved
110 Reserved
111 ID Main
112 ID Locals
113 ID Resolver
114 ID Power
Read /
Write
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R
R/W
R/W
R/W
R/W
R/W
R
R
R/W
R/W
R/W
R/W
R/W
R
R
R
R
R
R
Publication PUB088-005-00_1017
Value / Range
Bit 0: 0-Normally
Open, 1 – normally
closed.
Bits 1 to 15:
See separate table
'S contact functions'.
0-100%, 0 to 0064 h
0-100%, 0 to 0064 h
0-100%, 0 to 0064 h
0-100%, 0 to 0064 h
00: Close,
01: Open,
10: Stationary
11: Ignore ESD
0: ESD break contact
1: ESD make contact
0: bypass disabled
1: bypass enabled
0: bypass disabled
1: bypass enabled
0: bypass disabled
1: bypass enabled
0: Interlocks Enabled
1:Interlocks Disabled
-
0: Around close limit
1:Around open limit
1-99secs, 0 to 0063h
1-99secs, 0 to 0063h
0-100%, 0 to 0064 h
0-100%, 0 to 0064 h
0: English
1: Alternative
language
-
16bytes ASCII
16bytes ASCII
16bytes ASCII
16bytes ASCII
Parameters
Default Value
0001
0003
000D
002B
0001
0001
0001
0001
0000
0000
0000
0000
0000
0000
0001
001A0000
0000
0002
0003
0028
002D
0000
0000
-
-
-
-
69 of 84
