Introduction

1 Introduction

1.1 About this Manual

First-time users can find the most essential information for
quick installation and set-up in these chapters:

1.2.1 Technical Overview

1.3 Constraints

3 How to Install
For more detailed information including the full range of
set-up options and diagnosis tools, refer to:
4 How to Configure the System
5 Parameter Mapping Lists
1.1.1 FC 300-related Literature
The following literature is available for the FC 300 series:
•
®
VLT AutomationDrive FC 302 Operating
Instructions
•
®
VLT AutomationDrive FC 302 Design Guide
•
®
VLT AutomationDrive FC 302 Programming
Guide
www.danfoss.com/BusinessAreas/DrivesSolutions/Documen-
tations/VLT+Technical+Documentation.htm
1.2 Technical Overview
The MCA 114 Profibus Converter is an option replacing a
® ®
VLT 5000 with a VLT AutomationDrive FC 302 in a
PROFIBUS network.
With this PROFIBUS converter option the FC 302 reacts as
®
a VLT 5000 on the PROFIBUS network. Changes to PLC
programming or configuration are normally not necessary.
The FC 302 identifies itself as a VLT
PROFIBUS network, and a write command to e.g. Ramp Up
®
Time in VLT 5000 is automatically linked to the
corresponding ramp up time parameter in VLT
tionDrive FC 302.
®
VLT AutomationDrive FC 302 PROFIBUS Converter Operating Instructions
®
5000 on the
®
Automa-
MG34N202 - Rev. 2013-10-15
NOTICE
Some parameters in the VLT
the FC 302 and some FC 302 parameters cannot be
accessed via the PROFIBUS converter option MCA 114.
Refer to 5 Parameter Mapping Lists for more information.
If a write request is attempted to a parameter selection
not supported, the frequency converter discards the
value and issues a positive reply. Only parameters and
functions described in this manual are supported.
NOTICE
The replacement frequency converter must match the
power size, or be bigger than the replaced VLT
Make sure that the brake chopper matches the new
frequency converter.
Make sure that the new frequency converter meets the
local regulations concerning the machinery directive,
prefuses, and other appropriate regulations.
NOTICE
Observe local rules and regulations when replacing
frequency converter in existing installations.
1.3 Constraints

1.3.1 Software Versions

•
®
VLT AutomationDrive FC 302 with firmware
version 5.5X or higher.
•
The MCA 114 Profibus Converter firmware is
®
based on a VLT 5000 software version 3.9x and
PROFIBUS software version 4.5x.
®
5000 are not supported in
®
5000.
