Parameter Mapping Lists

5.10 VLT

®
Parameter
Table 5.278 Conversion of Parameter 900
Parameter
Table 5.279 Conversion of Parameter 901
5 5
Parameter
Table 5.280 Conversion of Parameter 902
Parameter
Table 5.281 Conversion of Parameter 903
VLT 5000 series
Parameter 904 PPO type select for DP
Table 5.282 Conversion of Parameter 904
Parameter
Table 5.283 Conversion of Parameter 907
Parameter
Table 5.284 Conversion of Parameter 908
Parameter
Table 5.285 Conversion of Parameter 909
Parameter
Table 5.286 Conversion of Parameter 910
VLT 5000 series
Parameter 911 PPO type for FMS read
Table 5.287 Conversion of Parameter 911
Parameter
Table 5.288 Conversion of Parameter 913
40
5000 Parameter Group 9
VLT 5000 series FC 302 series
900 Write PPO type 1 Not converted
VLT 5000 series FC 302 series
901 Write PPO type 2 Not converted
VLT 5000 series FC 302 series
902 Write PPO type 3 Not converted
VLT 5000 series FC 302 series
903 Write PPO type 4 Not converted
FC 302 series
Not converted
VLT 5000 series FC 302 series
907 Read PPO type 1 Not converted
VLT 5000 series FC 302 series
908 Read PPO type 2 Not converted
VLT 5000 series FC 302 series
909 Read PPO type 3 Not converted
VLT 5000 series FC 302 series
910 Read PPO type 4 Not converted
FC 302 series
Not converted
VLT 5000 series FC 302 series
913 Broadcast index Not converted
®
VLT AutomationDrive FC 302 PROFIBUS Converter Operating Instructions
Parameter
Table 5.289 Conversion of Parameter 914
Parameter 915 PCD config write
Options
Comments VLT
Table 5.290 Conversion of Parameter 915
MG34N202 - Rev. 2013-10-15
VLT 5000 series
914 Broadcast off-set
VLT 5000 series FC 302 series
9-15 PCD Write Config-
uration
[0] None [0] None
[204] Minimum Reference [302] Minimum
Reference
[205] Maximum Reference [203] Maximum
Reference
[219] Catch up/slow Down [312] Catch up/slow
Value Down Value
[207] Ramp 1 Ramp up [341] Ramp 1 Ramp up
Time Time
[208] Ramp 1 Ramp Down [342] Ramp 1 Ramp
Time Down Time
[209] Ramp 2 Ramp up [351] Ramp 2 Ramp up
Time Time
[210] Ramp 2 Ramp down [352] Ramp 2 Ramp
Time down Time
[211] Jog Ramp Time [380] Jog Ramp Time
[212] Quick Stop Ramp [381] Quick Stop Ramp
Time Time
[201] Motor Low Limit [Hz] [412] Motor Speed Low
Limit [Hz]
[202] Motor High Limit [Hz] [414] Motor Speed High
Limit [Hz]
[221] Torque Limit Motor [416] Torque Limit
Mode Motor Mode
[222] Torque Limit [417] Torque Limit
Generator Mode Generator Mode
[509] Bus Jog 1 Speed [890] Bus Jog 1 Speed
[510] Bus Jog 2 Speed [891] Bus Jog 2 Speed
®
5000 supports more write signals. If a not-
supported signal is written then the corresponding
signal is set to [0] None.
FC 302 series
Not converted
