Parameter Mapping Lists
VLT 5000 series
Parameter 319 Terminal 42,
Output
Parameter 321 Terminal 45,
Output
Options [15] Out of
frequency range
[16] Over f low
[17] Under f high
[18] Out of feedback
range
[19] Over feedback
low
[20] Under feedback
high
[21] Thermal
warning
[22] Ready, no
thermal warning
[23] Ready - remote
control - no thermal
warning
[24] Ready – mains
voltage within range
[25] Reversing
[26] Bus OK
[27] Torque limit and
stop
Table 5.107 Conversion of Parameters 319 to 321
®
VLT AutomationDrive FC 302 PROFIBUS Converter Operating Instructions
FC 302 series
Digital = Par. 5-32 DO X30/7
(MCB 101)
Analogue values= Par. 6-50 AO
42
Pulse = Par. 5-66 DO X30/6
Digital = Par. 5-33 DO X30/7
(MCB 101)
Analogue values= Par. 6-60 AO
X30/8
Pulse = Par. 5-66 DO X30/6
Par. 5-32 = [15] Out of speed
range
Par. 5-32 = [16] Below speed
1)
low
Par. 5-32 = [17] Above speed
high 1)
Par. 5-32 = [18] Out of feedb.
Range
Par. 5-32 = [19] Below
feedback low 1)
Par. 5-32 = [20] Above
1)
feedback high
Par. 5-32 = [21] Thermal
warning
Par. 5-32 = [12] Ready,no
thermal W
Par. 5-32 = [23] Remote, ready,
no TW
Par. 5-32 = [24] Ready, Voltage
OK
Par. 5-32 = [25] Reverse
Par. 5-32 = [26] Bus OK
Par. 5-32 = [27] Torque limit &
stop
MG34N202 - Rev. 2013-10-15
VLT 5000 series
Parameter 319 Terminal 42, Output Digital = Par. 5-32 DO
Parameter 321 Terminal 45, Output Digital = Par. 5-33 DO
Options [28] Brake, no brake
warning
[29] Brake ready, no
fault
[30] Brake fault
[31] Relay 123
[32] Mechanical brake
control
[34] Extended
mechanical brake
control
[35] Safety Interlock
[36] 0 – 100 Hz ⇒ 0 – 20
mA
[37] 0 – 100 Hz ⇒ 4 – 20
mA
[38] 0 – 100 Hz ⇒ 0 –
32000 p
[39] 0 – f max ⇒ 0 – 20
mA
[40] 0 – f max ⇒ 4 – 20
mA
[41] 0 – f max ⇒ 0 –
32000 p
[42] Ref min – Ref max
⇒ 0 – 20 mA
Table 5.108 Conversion of Parameters 319 to 321
FC 302 series
X30/7 (MCB 101)
Analogue values= Par. 6-50
AO 42
Pulse = Par. 5-66 DO X30/6
X30/7 (MCB 101)
Analogue values= Par. 6-60
AO X30/8
Pulse = Par. 5-66 DO X30/6
Par. 5-32 = [28] Brake, no
brake warning
Par. 5-32 = [29] Brake
ready, no fault
Par. 5-32 = [30] Brake fault
(IGBT)
Par. 5-32 = [31] Relay 123
Par. 5-32 = [32] Mech
brake ctrl
Par. 5-32 = [32] Mech
brake ctrl
Not supported
Not supported
Not supported
Not supported
Par. 6-50 = [109] Max Out
freq. 0 – 20 mA
Par. 6-50 = [130] Max Out
freq. 4 – 20 mA
Par. 5-66 = [109] Max Out
freq. 0 – 32000p Par. 568 =
32000
Par. 6-50 = [101] Reference
0 -20 mA
