Parameter Mapping Lists
VLT 5000 series
Parameter 305 Terminal 29, input
Options [0] No function
[1] Reset
[2] Stop inverse
[3] Only start clockwise,
on
[4] Only start
anticlockwise, on
[5] Jog
5 5
[6] Preset reference, on
[7] Preset reference, lsb
[8] Preset reference, msb
[9] Freeze reference
[10] Freeze output
[11] Speed up
[12] Speed down
[13] Choice of Setup, lsb
[14] Choice of Setup, msb [24] Setup select bit 1
[15] Catch up
[16] Slow down
[17] Ramp 2
[18] Mains failure inverted Not supported
[28] Pulse reference
[29] Data change lock
Table 5.92 Conversion of Parameter 305
VLT 5000 series
Parameter 306 Terminal 32, input
Options [0] No function
[1] Reset
[2] Stop inverse
[3] Only start clockwise,
on
[4] Jog
[5] Preset reference, on
[6] Preset reference, lsb
[7] Freeze reference
[8] Freeze output
[9] Speed up
[10] Choice of Setup, lsb [23] Setup select bit 0
[11] Choice of Setup,
msb / Speed up
[12] Catch up
[13] Ramp 2
[14] Mains failure
inverted
[24] Encoder input 2A
[29] Data change lock
Table 5.93 Conversion of Parameter 306
22
®
VLT AutomationDrive FC 302 PROFIBUS Converter Operating Instructions
FC 302 series
5-13 Terminal 29 Digital
Input
[0] No operation
[1] Reset
[6] Stop inverse
[12] Enable start forward
[13] Enable start reverse
[14] Jog
[15] Preset reference, on
[16] Preset reference bit 0
[17] Preset reference bit 1
[19] Freeze reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Setup select bit 0
[28] Catch up
[29] Slow down
[34] Ramp bit 0
[32] Pulse input
Not supported
FC 302 series
5-14 Terminal 32 Digital
Input
[0] No operation
[1] Reset
[6] Stop inverse
[12] Enable start forward
[14] Jog
[15] Preset reference, on
[16] Preset reference bit 0
[19] Freeze reference
[20] Freeze output
[21] Speed up
Not supported
[28] Catch up
[34] Ramp bit 0
Not supported
[0] No operation
Not supported
MG34N202 - Rev. 2013-10-15
VLT 5000 series
Parameter 307 Terminal 33, input
Options [0] No function
[1] Reset
[2] Stop inverse
[3] Only start
anticlockwise, on
[4] Jog
[5] Preset reference, on
[6] Preset reference, msb [17] Preset reference bit 1
[7] Freeze reference
[8] Freeze output
[9] Speed down
[10] Choice of Setup,
msb
[11] Choice of Setup,
msb / Speed down
[12] Slow down
[13] Ramp 2
[14] Mains failure
inverted
[24] Pulse feedback
[25] Encoder input 2B
[29] Data change lock
Table 5.94 Conversion of Parameter 307
FC 302 series
5-15 Terminal 33 Digital
Input
7-00 Speed PID Feedback
Source
[0] No operation
[1] Reset
[6] Stop inverse
[13] Enable start reverse
[14] Jog
[15] Preset reference, on
[19] Freeze reference
[20] Freeze output
[22] Speed down
[24] Setup select bit 1
Not supported
[29] Slow down
[34] Ramp bit 0
Not supported
[32] Pulse input,
Parameter 700 = [9]
Frequency input 33
[0] No operation
Parameter 700 = [1] 24 V
encoder
Not supported
