Parameter Mapping Lists
®
5.6 VLT
5000 Parameter Group 5
Parameter
Range
Table 5.183 Conversion of Parameter 500
VLT 5000 series
Parameter 501 Baud rate
Options [0] 300
5 5
[1] 600
[2] 1200
[3] 2400
[4] 4800
[5] 9600
Table 5.184 Conversion of Parameter 501
Parameter
Parameter
Parameter
Parameter
Parameter
Parameter
Parameter
Parameter
type
Options
Table 5.185 Conversion of Parameter 502 - 508
Parameter
Range
Table 5.186 Conversion of Parameter 509
Parameter
Range
Table 5.187 Conversion of Parameter 510
VLT 5000 series
Parameter 512 Telegram Profile
Range [0] Fieldbus profile
[1] FC profile
Table 5.188 Conversion of Parameter 512
Parameter
Table 5.189 Conversion of Parameter 513
34
VLT 5000 series FC 302 series
500 Address 8-31 Address
0 - 126 0 - 126
FC 302 series
8-32 FC Port Baud Rate
Not supported
Not supported
Not supported
[0] 2400
[1] 4800
[2] 9600
VLT 5000 series FC 302 series
502 Coasting 8-50 Coasting Select
503 Quick - Stop 8-51 Quick Stop Select
504 DC brake 8-52 DC Brake Select
505 Start 8-53 Start Select
506 Reversing 8-54 Reversing Select
507 Setup select 8-55 Set-up Select
508 Preset reference 8-56 Preset Reference
select Select
Unsigned 8 (5) Unsigned 8 (5)
[0] Digital input [0] Digital input
[1] Bus [1] Bus
[2] Logic AND [2] Logic AND
[3] Logic OR [3] Logic OR
VLT 5000 series FC 302 series
509 Bus Jog 1 8-90 Bus Jog 1 Speed
0.0 – par. 202 0.0 – par. 4-13
VLT 5000 series FC 302 series
510 Bus Jog 2 8-91 Bus Jog 2 Speed
0.0 – par. 202 0.0 – par. 4-13
FC 302 series
8-10 Control Word Profile
[1] ProfiDrive profile
[0] FC profile
VLT 5000 series FC 302 series
513 Bus time interval Not Converted
®
VLT AutomationDrive FC 302 PROFIBUS Converter Operating Instructions
Parameter
Table 5.190 Conversion of Parameter 514
Parameter
Table 5.191 Conversion of Parameter 515
Parameter
Table 5.192 Conversion of Parameter 516
Parameter
Table 5.193 Conversion of Parameter 517
Parameter
Table 5.194 Conversion of Parameter 518
Parameter
Table 5.195 Conversion of Parameter 519
Parameter
Table 5.196 Conversion of Parameter 520
Parameter 521 Torque
Table 5.197 Conversion of Parameter 521
Parameter
Table 5.198 Conversion of Parameter 522
Parameter
Table 5.199 Conversion of Parameter 523
Parameter
Table 5.200 Conversion of Parameter 524
Parameter
Table 5.201 Conversion of Parameter 525
MG34N202 - Rev. 2013-10-15
VLT 5000 series
514 Bus time interval function
VLT 5000 series FC 302 series
515 Reference % 16-02 Reference %
VLT 5000 series FC 302 series
516 Reference Unit 16-01 Reference [Unit]
VLT 5000 series FC 302 series
517 Feedback 16-52 Feedback[Unit]
VLT 5000 series FC 302 series
518 Frequency 16-13 Frequency
VLT 5000 series
519 Frequency x scaling
VLT 5000 series FC 302 series
520 Current 16-14 Motor current
VLT 5000 series FC 302 series
16-22 Torque [%]
16-21 Torque [%] high resolution
VLT 5000 series FC 302 series
522 Power, kW 16-10 Power [kW]
VLT 5000 series FC 302 series
523 Power, HP 16-11 Power [hp]
VLT 5000 series FC 302 series
524 Motor voltage 16-12 Motor Voltage
VLT 5000 series FC 302 series
525 DC link voltage 16-30 DC Link Voltage
FC 302 series
Not Converted
FC 302 series
Not converted
