Parameter Mapping Lists
VLT 5000 series
Parameter 314 Terminal 60,
Analogue Input
current
Options [0] No Operation Par. 3-17 Reference resource 3 set
[1] Reference
5 5
[2] Feedback
signal
[3] Torque limit
[4] Relative
reference
Comments The HW switch S202 for analogue input 54 must be
set to current (ON).
Table 5.101 Conversion of Parameter 314
VLT 5000 series
Parameter 315 Terminal 60, min.
scaling
Range 0.0 – 20.0 mA
Table 5.102 Conversion of Parameter 315
VLT 5000 series
Parameter 316 Terminal 60, max.
scaling
Range 0.0 – 20.0 mA
Table 5.103 Conversion of Parameter 316
VLT 5000 series
Parameter 317 Time Out
Range 0 – 99 sec
Table 5.104 Conversion of Parameter 317
24
®
VLT AutomationDrive FC 302 PROFIBUS Converter Operating Instructions
FC 302 series
3-17 Reference Resource 3
7-00 Speed PID Feedback Source
1-93 Thermistor Resource
4-20 Torque Limit Factor Source
to [0] No function
Par. 3-17 Reference resource 3 set
to [2] Analog input 54 Par. 7-00
Speed PID
Feedback Source set to [7]
Analog input 54
Par. 7-00 Speed PID Feedback
Source set to [7] Analog input 54
Par. 3-17 Reference resource 3 set
to [2] Analog input 54 Par. 4-20
Torque Limit
Factor Source set to [6] Analog in
54
Not supported
FC 302 series
6-22 Terminal 54 Low
Current
0.00 – Par. 6-23
FC 302 series
6-23 Teminal 54 High
Current
Par. 6-22 - 20.00 mA
FC 302 series
6-00 Live Zero Timeout Time
0 – 99 sec
MG34N202 - Rev. 2013-10-15
VLT 5000 series
Parameter 318 Function after time
out
Options [0] Off
[1] Freeze output
frequency
[2] Stop
[3] Jogging
[4] Max Speed, p202
[5] Stop and trip
Table 5.105 Conversion of Parameter 318
VLT 5000 series
Parameter 319 Terminal 42,
Output
Parameter 321 Terminal 45,
Output
Options [0] No function
[1] Control Ready
[2] Ready signal
[3] Ready - Remote
Control
[4] Enabled, no
warning
[5] Running
[6] Running, no
Warning
[7] Running within
range, no Warning
[8] Run at
reference, no
Warning
[9] Alarm
[10] Alarm or
Warning
[11] Torque limit
[12] Out of current
range
[13] Above I low
[14] Under I high
Table 5.106 Conversion of Parameters 319 to 321
FC 302 series
6-01 Live Zero Timeout
Function
[0] Off
[1] Freeze output
frequency
[2] Stop
[3] Jog
[4] Max Speed
[5] Stop and trip
FC 302 series
Digital = Par. 5-32 DO X30/7
(MCB 101)
Analogue values = Par. 6-50 AO
42
Pulse = Par. 5-66 DO X30/6
Digital = Par. 5-33 DO X30/7
(MCB 101)
Analogue values= Par. 6-60 AO
X30/8
Pulse = Par. 5-66 DO X30/6
Par. 5-32 = [0] No operation
Par. 5-32 = [1] Control Ready
Par. 5-32 = [2] Drive ready
Par. 5-32 = [3] Drive rdy/rem
ctrl
Par. 5-32 = [4] Enable / no
warning
Par. 5-32 = [5] VLT ® running
Par. 5-32 = [6] Running /no
warning
Par. 5-32 = [7] Run in range/no
warning
Par. 5-32 = [8] Run on ref/no
warning
Par. 5-32 = [9] Alarm
Par. 5-32 = [10] Alarm or
Warning
Par. 5-32 = [11] At torque limit
Par. 5-32 = [12] Out of current
range
Par. 5-32 = [13] Below current,
1)
low
Par. 5-32 = [14] Above current,
1)
high
