Parameter Mapping Lists
VLT 5000 series
Parameter 027 Warning readout line
Options [0] Warning in line 1/2
[1] Warning in line 3/4
Table 5.18 Conversion of Parameter 027
5 5
14
®
VLT AutomationDrive FC 302 PROFIBUS Converter Operating Instructions
FC 302 series
Not converted
5.2 VLT
Parameter 100 Configuration 0-02
Options
Table 5.19 Conversion of Parameter 100
Parameter 101 Torque charac-
Options
Table 5.20 Conversion of Parameter 101
MG34N202 - Rev. 2013-10-15
®
5000 Parameter Group 1
VLT 5000 series FC 302 series
1-01 Motor Control Principle
[0] Speed control, Par. 1-00 = [0] Speed open loop
open loop
Par. 1-01 = [1] VVC
[1] Speed control, Par. 0-02 = [0] RPM
closed loop Par. 1-00 = [1] Speed closed loop
[3] Process Par. 1-00 = [3] Process
control, closed
Par. 1-01 = [1] VVC
loop
[4] Torque control, Par. 1-00 = [4] Torque open loop
open loop
Par.1-01 = [1] VVC
[5] Torque control, Par. 1-00 = [2] Torque close loop
speed feedback Par. 1-01 = [3] Flux with motor fb
Par. 5-71 = [1] Counter clockwise
VLT 5000 series FC 302 series
1-03 Torque Characteristics
teristic 1-04 Overload Mode
14-40 VT Level
[1] High constant Par. 1-03 = [0] Constant torque
torque Par. 1-04 Over load = [0] High
[2] High variable Par. 1-03 = [1] Variable torque
torque low Par. 14-40 VT level = 45%
Par. 1-04 Over load = [0] High
[3] High variable Par. 1-03 = [1] Variable torque
torque medium Par. 14-40 VT level = 66%
Par. 1-04 Over load = [0] High
[4] High variable Par. 1-03 = [1] Variable torque
torque high Par. 14-40 VT level = 85%
Par. 1-04 Over load = [0] High
[5] High special Par. 1-01 = [0] U/f
motor characteristic Par. 1-04 Over load = [0] High
[6] High variable Par. 1-03 = [1] Variable torque
torque with low Par. 14-40 VT level = 45%
starting torque Par. 1-04 Over load = [0] High
plus
plus
plus
