Parameter Mapping Lists
VLT 5000 series
Parameter 319 Terminal 42,
Output
Parameter 321 Terminal 45,
Output
Options [43] Ref min – Ref max
5 5
⇒ 4 – 20 mA
[44] Ref min – Ref max
⇒ 0 - 32000 p
[45] FB min – FB max
⇒ 0 – 20 mA
[46] FB min – FB max
⇒ 4 – 20 mA
[47] FB min – FB max
⇒ 0 - 32000 p
[48] 0 – I max ⇒ 0 – 20
mA
[49] 0 – I max ⇒ 4 – 20
mA
[50] 0 – I max ⇒ 0 –
32000 p
[51] 0 – T lim ⇒ 0 – 20
mA
[52] 0 – T lim ⇒ 4 – 20
mA
[53] 0 – T lim ⇒ 0 –
32000 p
[54] 0 – T nom ⇒ 0 –
20 mA
[55] 0 – T nom ⇒ 4 –
20 mA
[56] 0 – T nom ⇒ 0 –
32000 p
[57] 0 – P nom ⇒ 0 –
20 mA
[58] 0 – P nom ⇒ 4 –
20 mA
[59] 0 – P nom ⇒ 0 –
32000 p
Table 5.109 Conversion of Parameters 319 to 321
26
®
VLT AutomationDrive FC 302 PROFIBUS Converter Operating Instructions
FC 302 series
Digital = Par. 5-32 DO X30/7
(MCB 101)
Analogue values= Par. 6-50
AO 42
Pulse = Par. 5-66 DO X30/6
Digital = Par. 5-33 DO X30/7
(MCB 101)
Analogue values= Par. 6-60
AO X30/8
Pulse = Par. 5-66 DO X30/6
Par. 6-50 = [131] Reference
4 -20 mA
Par. 5-66 = [101] Reference
0 – 32000p Par. 5-68 =
32000
Par. 6-50 = [102] Feedback 0
-20 mA
Par. 6-50 = [132] Feedback 4
-20 mA
Par. 5-66 = [102] Feedback 0
– 32000p Par. 5-68 = 32000
Par. 6-50 = [103] Motor
current 0 -20 mA
Par. 6-50 = [133] Motor
current 4 -20 mA
Par. 5-66 = [103] Motor
current 0 - 32000p Par. 5-68
= 32000
Par. 6-50 = [104] Torque
related to limit 0 - 20 mA
Par. 6-50 = [134] Torque
related to limit 4 - 20 mA
Par. 5-66 = [104] Torque
related to limit 0 – 32000p
Par. 5-68 = 32000
Par. 6-50 = [105] Torque
related to norm 0 - 20 mA
Par. 6-50 = [135] Torque
related to norm 4 - 20 mA
Par. 5-66 = [105] Torque
related to norm 0 – 32000p
Par. 5-68 = 32000
Par. 6-50 = [106] Power
related to norm 0 - 20 mA
Par. 6-50 = [136] Power
related to norm 4 - 20 mA
Par. 5-66 = [106] Power
related to norm 0 – 32000p
Par. 5-68 = 32000
MG34N202 - Rev. 2013-10-15
VLT 5000 series
Parameter 319 Terminal 42,
Output
Parameter 321 Terminal 45,
Output
Options [60] 0 – SyncRPM ⇒ 0
– 20 mA
[61] 0 – SyncRPM ⇒ 4
– 20 mA
[62] 0 – SyncRPM ⇒ 0
– 32000 p
[63] RPM at F max ⇒ 0
– 20 mA
[64] RPM at F max ⇒ 4
– 20 mA
[65] RPM at F max ⇒ 0
– 32000 p
Table 5.110 Conversion of Parameters 319 to 321
VLT 5000 series
Parameter 320 Terminal 42 Output,
pulse scaling
Range 1 – 32000 Hz
Table 5.111 Conversion of Parameter 320
VLT 5000 series
Parameter 322 Terminal 45 Output,
pulse scaling
Range 1 – 32000 Hz
Table 5.112 Conversion of Parameter 322
FC 302 series
Digital = Par. 5-32 DO X30/7
(MCB 101)
Analogue values= Par. 6-50
AO 42
Pulse = Par. 5-66 DO X30/6
Digital = Par. 5-33 DO X30/7
(MCB 101)
Analogue values= Par. 6-60
AO X30/8
Pulse = Par. 5-66 DO X30/6
Not supported
Not supported
Not supported
Par. 6-50 = [107] Speed
related to norm 0 - 20 mA
Par. 6-50 = [137] Speed
related to norm 4 - 20 mA
Par. 5-66 = [107] Speed
related to norm 0 – 32000p
Par. 5-68 = 32000
FC 302 series
5-68 Pulse Output Max
Freq #X30/6
0 – 32000 Hz
FC 302 series
5-68 Pulse Output Max
Freq #X30/6
0– 32000 Hz
