Parameter Mapping Lists
VLT 5000 series
Parameter 409 Trip delay torque 14-25 Trip Delay at Torque
Range 0 – 60 s (60=OFF)
Table 5.137 Conversion of Parameter 409
VLT 5000 series
Parameter 410 Trip delay inverter 14-26 Trip Delay at Inverter
Range 0 – 35 s
5 5
Table 5.138 Conversion of Parameter 410
VLT 5000 series
Parameter 411 Switching frequency 14-01 Switching Frequency
Range Unsigned 16 (6)
1.5 – 14 kHz
Table 5.139 Conversion of Parameter 411
VLT 5000 series
Parameter 412 Output frequency dependent
switching frequency
Table 5.140 Conversion of Parameter 412
VLT 5000 series
Parameter 413 Overmodulation
function
Options [0] Off
[1] On
Table 5.141 Conversion of Parameter 413
Parameter
Table 5.142 Conversion of Parameter 414
VLT 5000 series
Parameter 415 Maximum feedback
Table 5.143 Conversion of Parameter 415
30
FC 302 series
Limit
0 – 60 s (60=OFF)
FC 302 series
Fault
0 – 35 s
FC 302 series
Unsigned 8 (5)
< 2.3 ⇒ 2.0 kHz [2]
2.3 > 2.7 ⇒ 2.5 kHz [3]
2.8 > 3.2 ⇒ 3.0 kHz [4]
3.3 > 3.7 ⇒ 3.5 kHz [5]
3.8 > 4.5 ⇒ 4.0 kHz [6]
4.6 > 5.5 ⇒ 5.0 kHz [7]
5.6 > 6.5 ⇒ 6.0 kHz [8]
6.6 > 7.5 ⇒ 7.0 kHz [9]
7.6 > 9.0 ⇒ 8.0 kHz [10]
9.1 > ⇒ 10.0 kHz [11]
FC 302 series
14-03 Overmodulation
function
[0] Off
[1] On
VLT 5000 series FC 302 series
414 Minimum feedback Not converted
FC 302 series
Not converted
®
VLT AutomationDrive FC 302 PROFIBUS Converter Operating Instructions
Parameter
Options
FC 302 series
Not converted
Table 5.144 Conversion of Parameter 416 part 1
MG34N202 - Rev. 2013-10-15
VLT 5000 series FC 302 series
416 Feedback Unit 3-01 Reference/
feedback Unit
[0] None [0] None
[1] % [1] %
[2] PPM [5] PPM
[3] rpm [2] RPM
[4] bar [71] bar
[5] Cycle/min Not supported
[6] Pulse/s [12] Pulse/s
[7] Unit s/s Not supported
[8] Unit s/min Not supported
[9] Unit s/h Not supported
[10] °C [60] °C
[11] Pa [72] Pa
[12] l/s [20] l/s
[13] m3/s [23] m3/s
[14] l/min [21] l/min
[15] m3/min [24] m3/min
[16] l/h [22] l/h
[17] m3/h [25] m3/h
[18] kg/s [30] kg/s
[19] kg/min [31] kg/min
[20] kg/h [32] kg/h
[21] t/min [33] t/min
[22] t/h [34] t/h
[23] m [45] m
[24] Nm [4] Nm
[25] m/s [40] m/s
