Danfoss vlt series Operating Instructions Manual page 22

Parameter Mapping Lists
VLT 5000 series
Parameter 221 Torque limit for
motor mode
Range 0.0 – Max. torque %
Table 5.73 Conversion of Parameter 221
VLT 5000 series
Parameter 222 Torque limit for
generating mode
Range 0.0 – Max. torque %
5 5
Table 5.74 Conversion of Parameter 222
VLT 5000 series
Parameter 223 Warning: Current
Low
Range 0.0 – par. 2-24 Current
High
Table 5.75 Conversion of Parameter 223
VLT 5000 series
Parameter 224 Warning: Current
High
Range Power Unit dependable
Table 5.76 Conversion of Parameter 224
VLT 5000 series
Parameter 225 Warning Low
Frequency
Range 0,0 – par. 226
Table 5.77 Conversion of Parameter 225
VLT 5000 series
Parameter 226 Warning High
Frequency
Range par. 2-25 – par. 202
Table 5.78 Conversion of Parameter 226
VLT 5000 series
Parameter 227 Warning Low
Feedback
Range -100,000.000 – par. 228
Table 5.79 Conversion of Parameter 227
VLT 5000 series
Parameter 228 Warning High
Feedback
Range par. 227 – 100,000.000
Table 5.80 Conversion of Parameter 228
20
®
VLT AutomationDrive FC 302 PROFIBUS Converter Operating Instructions
FC 302 series
4-16 Torque Limit Motor
Mode
0.0 – Max. torque %
FC 302 series
4-17 Torque Limit
Generator Mode
0.0 – Max. torque %
FC 302 series
4-50 Warning Current Low
2-20 Release Brake Current
0.00 – par. 4-51
FC 302 series
4-51 Warning Current
High
Power Unit dependable
FC 302 series
4-52 Warning Speed Low
2-22 Activate Brake Speed
[Hz]
0,0 – Par. 4-53
FC 302 series
4-53 Warning Speed High
Par. 4-52 – par. 4-13
FC 302 series
4-56 Warning Feedback
Low
-999,999.999 – par. 4-57
FC 302 series
4-57 Warning Feedback
High
Par. 4-56 – 999,999.999
MG34N202 - Rev. 2013-10-15
VLT 5000 series
Parameter 229 Frequency bypass,
bandwidth
Range 0 - 100%
Table 5.81 Conversion of Parameter 229
VLT 5000 series
Parameter 230 Frequency Bypass
1
Range 0 – par. 200
Table 5.82 Conversion of Parameter 230
VLT 5000 series
Parameter 2-31 Frequency Bypass
2
Range 0 – par. 200
Table 5.83 Conversion of Parameter 231
VLT 5000 series
Parameter 232 Frequency Bypass
3
Range 0 – par. 200
Table 5.84 Conversion of Parameter 232
VLT 5000 series
Parameter 233 Frequency Bypass
4
Range 0 – par. 200
Table 5.85 Conversion of Parameter 233
VLT 5000 series
Parameter 234 Motor phase
monitor
Range [0] Enable
[1] Disable
Table 5.86 Conversion of Parameter 234
FC 302 series
Stored in EEprom only
FC 302 series
4-61 Bypass Speed From [Hz]
4-63 Bypass Speed To [Hz]
0 – par. 4-14
FC 302 series
4-61 Bypass Speed From [Hz]
4-63 Bypass Speed To [Hz]
0 – par. 4-14
FC 302 series
4-61 Bypass Speed From [Hz]
4-63 Bypass Speed To [Hz]
0 – par. 4-14
FC 302 series
4-61 Bypass Speed From [Hz]
4-63 Bypass Speed To [Hz]
0 – par. 4-14
FC 302 series
4-58 Missing Motor Phase
Function
[2] Trip 1000 ms
[0] Disable
