Parameter Mapping Lists
VLT 5000 series
Parameter 916 PCD config read
Options [0] None
[538] Alarm word
[540] Warning word
[541] Ext. status word
[600] Operating hours
[601] Running hours
[602] kWh Counter
[539] Control word
[516] Reference [Unit]
[515] Reference %
[534] Status word
[522] Power [kW]
[523] Power [HP]
[524] Motor voltage
[518] Motor frequency
[520] Motor current
[557] Motor RPM
[526] Motor thermal
[521] Torque
[525] DC link voltage
[536] Brake energy/s
[535] Brake energy/2 min [1633] Brake energy/2 min
[537] Heat sink temp.
[527] Inverter Thermal
[533] External reference
[532] Pulse reference
[517] Feedback [Unit]
[528] Digital input
[529] Analog input 53
[530] Analog input 54
[531] Analog input 60
Table 5.291 Conversion of Parameter 916
VLT 5000 series
Parameter 917 Spontaneous messages
Table 5.292 Conversion of Parameter 917
VLT 5000 series
Parameter 918 Station address
Range 0 - 125
Table 5.293 Conversion of Parameter 918
®
VLT AutomationDrive FC 302 PROFIBUS Converter Operating Instructions
FC 302 series
9-16 PCD Read Configu-
ration
[0] None
[1472] VLT Alarm Word
[1473] VLT Warning Word
[1474] VLT Ext. status
Word
[1500] Operating hours
[1501] Running hours
[1502] kWh Counter
[1600] Control word
[1601] Reference [Unit]
[1602] Reference %
[1603] Status word
[1610] Power [kW]
[1611] Power [HP]
[1612] Motor voltage
[1613] Motor frequency
[1614] Motor current
[1617] Motor speed
[1618] Motor thermal
[1622] Torque %
[1630] DC link voltage
[1632] Brake energy/s
[1634] Heat sink temp.
[1635] Inverter Thermal
[1650] External reference
[1651] Pulse reference
[1652] Feedback [Unit]
[1660] Digital input
[1662] Analog input 53
[1664] Analog input 54
[1664] Analog input 54
FC 302 series
Not converted
FC 302 series
9-18 Node Address
0 - 125
MG34N202 - Rev. 2013-10-15
VLT 5000 series
Parameter 927 Parameter edit
Options [0] Disable
[1] Enable
Table 5.294 Conversion of Parameter 927
VLT 5000 series
Parameter 928 Control authority
Options [0] Disable
[1] Enable
Table 5.295 Conversion of Parameter 928
VLT 5000 series
Parameter 953 Warning parameter 9-53 Profibus Warning Word
Table 5.296 Conversion of Parameter 953
VLT 5000 series
Parameter 964 Identification
Table 5.297 Conversion of Parameter 964
VLT 5000 series
Parameter 965 Profile Number
Table 5.298 Conversion of Parameter 965
VLT 5000 series
Parameter 967 Control word (FMS)
Table 5.299 Conversion of Parameter 967
VLT 5000 series
Parameter 968 Status word (FMS)
Table 5.300 Conversion of Parameter 968
VLT 5000 series
Parameter 970 Parameter set-up selection 9-70 Edit Set-up
Options [0] Factory setting
[1] Parameter setup 1
[2] Parameter setup 2
[3] Parameter setup 3
[4] Parameter setup 4
[5] Active setup
Table 5.301 Conversion of Parameter 970
FC 302 series
9-27 Parameter Edit
[0] Disable
[1] Enable
FC 302 series
9-28 Process Control
[0] Disable
[1] Enable cyclic master
FC 302 series
FC 302 series
9-64 Device Identification
FC 302 series
9-65 Profile Number
FC 302 series
Not converted
FC 302 series
Not converted
FC 302 series
[0] Factory setting
[1] Parameter setup 1
[2] Parameter setup 2
[3] Parameter setup 3
[4] Parameter setup 4
[9] Active setup
