Parameter Mapping Lists
VLT 5000 series
Parameter 323, 326
Range 01 Relay
04 Relay
[0] No function
[1] Control Ready
[2] Ready signal
[3] Ready - Remote
Control
[4] Enabled, no
warning
[5] Running
[6] Running, no
Warning
[7] Running within
range, no warning
[8] Run at
reference, no
Warning
[9] Alarm
[10] Alarm or
Warning
[11] Torque limit
[12] Out of current
range
[13] Above I low
[14] Under I high
[15] Out of
frequency range
[16] Over f low
[17] Under f high
[18] Out of
feedback range
[19] Over feedback
low
[20] Under feedback
high
[21] Thermal
warning
Table 5.113 Conversion of Parameters 323 to 326
®
VLT AutomationDrive FC 302 PROFIBUS Converter Operating Instructions
FC 302 series
5-40 Function Relay
Relay 1
Relay 2
Par. 5-40 = [0] No operation
Par. 5-40 = [1] Control Ready
Par. 5-40 = [2] Drive ready
Par. 5-40 = [3] Drive rdy/rem
ctrl
Par. 5-40 = [4] Enable / no
warning
Par. 5-40 = [5] VLT running
Par. 5-40 = [6] Running / no
warning
Par. 5-40 = [7] Run in range/no
warn
Par. 5-40 = [8] Run on ref/no
warn
Par. 5-40 = [9] Alarm
Par. 5-40 = [10] Alarm or
Warning
Par. 5-40 = [11] At torque limit
Par. 5-40 = [12] Out of current
range
Par. 5-40 = [13] Below current,
low 1)
Par. 5-40 = [14] Above current,
1)
high
Par. 5-40 = [15] Out of speed
range
Par. 5-40 = [16] Below speed
1)
low
Par.5-40 = [17] Above speed
high 1)
Par. 5-40 = [18] Out of feedb.
Range
Par. 5-40 = [16] Below feedback
1)
low
Par. 5-40 = [17] Above feedback
high 1)
Par. 5-40 = [21] Thermal
warning
MG34N202 - Rev. 2013-10-15
VLT 5000 series
Parameter 323, 326
Range [22] Ready, no
thermal warning
[23] Ready - remote
control - no thermal
warning
[24] Ready – mains
voltage within range
[25] Reversing
[26] Bus OK
[27] Torque limit and
stop
[28] Brake, no brake
warning
[29] Brake ready, no
fault
[30] Brake fault
[31] Relay 123
[32] Mechanical
brake control
[33] Control word bit
11/12
[34] Extended
mechanical brake
control
[35] Safety Interlock
Table 5.114 Conversion of Parameters 323 to 326
VLT 5000 series
Parameter 324 Relay 01, ON delay
Range 0.00 – 600.00 sec
Table 5.115 Conversion of Parameter 324
VLT 5000 series
Parameter 325 Relay 01, OFF delay
Range 0.00 – 600.00 s
Table 5.116 Conversion of Parameter 325
VLT 5000 series
Parameter 327 Pulse reference, max.
freq
Range 100 – 65000 Hz
Table 5.117 Conversion of Parameter 327
FC 302 series
5-40 Function Relay
Par. 5-40 = [12] Ready,no
thermal W
Par. 5-40 = [23] Remote, ready,
no TW
Par. 5-40 = [24] Ready, Voltage
OK
Par. 5-40 = [25] Reverse
Par. 5-40 = [26] Bus OK
Par. 5-40 = [27] Torque limit &
stop
Par. 5-40 = [28] Brake, no
brake warning
Par. 5-40 = [29] Brake ready,
no fault
Par. 5-40 = [30] Brake fault
(IGBT)
Par. 5-40 = [31] Relay 123
Par. 5-40.0 = [32] Mech brake
ctrl
Par. 1-72 = [5] VVC+/Flux
Par. 5-40 = [36] Control word
bit 11
Par. 5-40.1 = [37] Control word
bit 12
Par. 5-40.0 = [32] Mech brake
ctrl
Par. 1-72 = [5] VVC+/Flux
Not supported
FC 302 series
5-41 On Delay, Relay
0.01 – 600.00 sec
FC 302 series
5-42 Off Delay, Relay
0.01 – 600.00 s
FC 302 series
5-51 Term. 29 High
Frequency
0 – 110000 Hz
