Memory Bank x Control Register
(MB0CR)
(MB1CR)
(MB2CR)
(MB3CR)
Bit(s) Value
7:6 00
01
10
11
5 0
1
4 0
1
3:2 00
01
10
11
1:0 00
01
10
11
Rabbit 6000 User's Manual
(Address = 0x0014)
(Address = 0x0015)
(Address = 0x0016)
(Address = 0x0017)
Four (five for writes) wait states for accesses in this bank.
Two (three for writes) wait states for accesses in this bank.
One (two for writes) wait states for accesses in this bank.
Zero (one for writes) wait states for accesses in this bank.
Pass bank select address MSB for accesses in this bank.
Invert bank select address MSB for accesses in this bank.
Pass bank select address LSB for accesses in this bank.
Invert bank select address LSB for accesses in this bank.
/OE0 and /WE0 are active for accesses in this bank.
/OE1 and /WE1 are active for accesses in this bank.
/OE0 only is active for accesses in this bank (i.e., read-only).
Transactions are normal in every other way.
/OE1 only is active for accesses in this bank (i.e., read-only).
Transactions are normal in every other way.
/CS0 is active for accesses in this bank.
/CS1 is active for accesses in this bank.
/CS2 is active for accesses in this bank.
/CS3 (internal memory) is active for accesses in this bank. When
standalone operation is selected (by strapping the SCFG pin high), this bit
combination is forced for MB0CR only.
