Master Override Control Register
(POCR)
Bit(s) Value
7 0
1
6 0
1
5 0
1
4 0
1
3 0
1
2 0
1
1 0
1
0 0
1
Rabbit 6000 User's Manual
(Address = 0x0438)
Normal operation for Port H.
Override Port H operation (FIM A or FIM B controls the port).
Normal operation for Port G.
Override Port G operation (FIM A or FIM B controls the port).
Normal operation for Port F.
Override Port F operation (FIM A or FIM B controls the port).
Normal operation for Port E.
Override Port E operation (FIM A or FIM B controls the port).
Normal operation for Port D.
Override Port D operation (FIM A or FIM B controls the port).
Normal operation for Port C.
Override Port C operation (FIM A or FIM B controls the port).
Normal operation for Port B.
Override Port B operation (FIM A or FIM B controls the port).
Normal operation for Port A.
Override Port A operation (FIM A or FIM B controls the port).
