Rabbit 6000 User Manual page 281

DMA y Source Addr[23:16] Register
(D0SA2R)
(D1SA2R)
(D2SA2R)
(D3SA2R)
(D4SA2R)
(D5SA2R)
(D6SA2R)
(D7SA2R)
(D8SA2R)
(D9SA2R)
(D10SA2R)
(D11SA2R)
(D12SA2R)
(D13SA2R)
(D14SA2R)
(D15SA2R)
Bit(s) Value
7:0
DMA y Destination Addr[7:0] Register
(D0DA0R)
(D1DA0R)
(D2DA0R)
(D3DA0R)
(D4DA0R)
(D5DA0R)
(D6DA0R)
(D7DA0R)
(D8DA0R)
(D9DA0R)
(D10DA0R)
(D11DA0R)
(D12DA0R)
(D13DA0R)
(D14DA0R)
(D15DA0R)
Bit(s) Value
7:0
Rabbit 6000 User's Manual
(Address = 0x0186)
(Address = 0x0196)
(Address = 0x01A6)
(Address = 0x01B6)
(Address = 0x01C6)
(Address = 0x01D6)
(Address = 0x01E6)
(Address = 0x01F6)
(Address = 0x0986)
(Address = 0x0996)
(Address = 0x09A6)
(Address = 0x09B6)
(Address = 0x09C6)
(Address = 0x09D6)
(Address = 0x09E6)
(Address = 0x09F6)
Bits 23:16 of the source address are stored in this register.
(Address = 0x0188)
(Address = 0x0198)
(Address = 0x01A8)
(Address = 0x01B8)
(Address = 0x01C8)
(Address = 0x01D8)
(Address = 0x01E8)
(Address = 0x01F8)
(Address = 0x0988)
(Address = 0x0998)
(Address = 0x09A8)
(Address = 0x09B8)
(Address = 0x09C8)
(Address = 0x09D8)
(Address = 0x09E8)
(Address = 0x09F8)
Bits 7:0 of the destination address are stored in this register.
digi.com
Description
Description
281
