Rabbit 6000 User Manual page 440

Pin Group Pin Name
VRXI+
VRXI-
VRXQ+
VRXQ-
VBG
AD_RSET
ITXI+
ITXI-
ITXQ+
ITXQ-
COMP
DA_RSET
S_VIN
Analog
S_AD_REF+
S_AD_REF-
IN7
IN6
IN5
IN4
IN3
IN2
IN1
IN0
MUXOUT
VIN
REF+
REF-
XTL_48MI
XTL_48MO
USB
D+
D-
Rabbit 6000 User's Manual
Table 38-3. Rabbit 6000 Pin Descriptions
Direction
Input Inphase + Input
Input Inphase - Input
Input Quadrature + Input
Input Quadrature - Input
Input A/D Ext Bandgap
Output A/D resistor
Output Inphase + Output
Output Inphase - Output
Output Quadrature + Output
Output Quadrature - Output
Bidirectional D/A Compensation
Bidirectional D/A resistor
Input RSSI A/D Input
Input RSSI A/D Top Ref
Input RSSI A/D Bottom Ref
Input A/D Inputs
Output Multiplexer Output
Input Actual ADC Input
Input A/D Top Ref
Input A/D Bottom Ref
Input
USB 48MHz Crystal
Bidirectional
Bidirectional USB Data
digi.com
Function BGA 292 Ball BGA 233 Ball
U1 R1
V1 P1
W1 T1
Y1 U1
V3 P2
W3 R2
Y11 U8
Y10 U7
Y13 U10
Y12 U9
V13 P10
U12 P9
Y20 U15
W20 P14
W19 R14
Y14 U11
U13 T11
W14 R11
V14 P11
Y15 U12
U14 T12
W15 R12
Y16 P12
Y17 U13
Y18 U14
V16 T14
V15 T13
H1 A1
J1 B1
M1 D1
L1 E1
