FIMB Code LSB Register
(FBCLR)
Bit(s) Value
7:0
FIMB Code MSB Register
(FBCMR)
Bit(s) Value
7:6
5:0
Master System Reset Register
(MSRR)
Bit(s) Value
7:3
0
2
(wr-only)
1
1
0
0
(wr-only)
1
Rabbit 6000 User's Manual
(Address = 0x7800) through (Address = 0x7BFF)
FIMB code bits [7:0].
(Address = 0x7C00) through (Address = 0x7FFF)
These bits are unused.
FIMB code bits [13:8].
(Address = 0x0436)
These bits are reserved and should be written with zeros.
No reset of Flexible Interface Module B. Reads always return zero.
Reset Flexible Interface Module B. This bit holds FIMB in Reset while set.
This bit is reserved and should be written with zero.
no reset of Flexible Interface Module A. Reads always return zero.
Reset Flexible interface Module A. This bit holds FIMA in Reset while set.
digi.com
Description
Description
Description
