Parallel Port D Bit 2 Register
Bit(s) Value
7:3,1:0
2 Write
Parallel Port D Bit 3 Register
Bit(s) Value
7:4,2:0
3 Write
Parallel Port D Bit 4 Register
Bit(s) Value
7:5,3:0
4 Write
Parallel Port D Bit 5 Register
Bit(s) Value
7:6,4:0
5 Write
Rabbit 6000 User's Manual
These bits are ignored.
The port buffer (bit 2) is written with the value of this bit. The port buffer
will be transferred to the port output register on the next rising edge of the
port transfer clock
These bits are ignored.
The port buffer (bit 3) is written with the value of this bit. The port buffer
will be transferred to the port output register on the next rising edge of the
port transfer clock
These bits are ignored.
The port buffer (bit 4) is written with the value of this bit. The port buffer
will be transferred to the port output register on the next rising edge of the
port transfer clock
These bits are ignored.
The port buffer (bit 5) is written with the value of this bit. The port buffer
will be transferred to the port output register on the next rising edge of the
port transfer clock
