Rabbit 6000 User Manual page 168

Timer A Control Register
Bit(s) Value
7 0
1
6 0
1
5 0
1
4 0
1
3 0
1
2 0
1
1:0 00
01
10
11
Timer A Time Constant x Register
(TAT1R)
(TAT2R)
(TAT3R)
(TAT4R)
(TAT5R)
(TAT6R)
(TAT7R)
(TAT8R)
(TAT9R)
(TAT10R)
(TAT11R)
(TAT12R)
Bit(s) Value
7:0
Rabbit 6000 User's Manual
Timer A7 clocked by the output of TAPR.
Timer A7 clocked by the output of Timer A1.
Timer A6 clocked by the output of TAPR.
Timer A6 clocked by the output of Timer A1.
Timer A5 clocked by the output of TAPR.
Timer A5 clocked by the output of Timer A1.
Timer A4 clocked by the output of TAPR
Timer A4 clocked by the output of Timer A1.
Timer A3 clocked by the output of TAPR.
Timer A3 clocked by the output of Timer A1.
Timer A2 clocked by the output of TAPR.
Timer A2 clocked by the output of Timer A1.
Timer A interrupts are disabled.
Timer A interrupt use Interrupt Priority 1.
Timer A interrupt use Interrupt Priority 2.
Timer A interrupt use Interrupt Priority 3.
(Address = 0x00A3)
(Address = 0x00A5
(Address = 0x00A7))
(Address = 0x00A9)
(Address = 0x00AB)
(Address = 0x00AD)
(Address = 0x00AF)
(Address = 0x00A6)
(Address = 0x00A8)
(Address = 0x00AA)
(Address = 0x00AC)
(Address = 0x00AE)
Time constant for the Timer A counter. This time constant will take effect
the next time that the Timer A counter counts down to zero. The timer
counts modulo n + 1, where n is the programmed time constant.
digi.com
(TACR) (Address = 0x00A4)
Description
Description
168
