22.6 Register Descriptions

Analog Component 0 I LSB Register
Analog Component 0 Q LSB Register
Bit(s) Value
7:6 Read
Write
5:0
Analog Component 0 I MSB Register
Analog Component 0 Q MSB Register
Bit(s) Value
7:0 Read
Write
Rabbit 6000 User's Manual
The current value of the two least-significant bits of the fast A/D
converter are returned. Reading this register locks the value in the
corresponding MSB register to guarantee that the full 10 bits are valid.
Writes to these bits are ignored.
These bits are ignored and will always return zeros when read.
The current value of the eight most-significant bits of the fast A/D
converter are returned.
Writes to this register are ignored.
