Rabbit 6000 User Manual page 433

Key
B
C
D
E
F
G
Rabbit 6000 User's Manual
Table 38-2. Design Considerations
(all dimensions in mm)
Feature
NSMD Defined Land Diameter
Land to Mask Clearance (min.)
Conductor Width (max.)
Conductor Spacing (typ.)
Via Capture Pad (max.)
Via Drill Size (max.)
digi.com
Recommendation
0.406 (0.016)
0.076 (0.003)
0.127 (0.005)
0.127 (0.005)
0.406 (0.016)
0.203 (0.008)
433
