Item Symbol
9
10
11
12
13
14
15
4.3

Machine control (Mode RC - on)

Item Symbol
1
2
099-000141-EW501
20.11.2017
Machine description – quick overview
Description 0
Key button, automatic cutout
Wire feed motor supply voltage fuse
press to reset a triggered fuse
G¼" connection thread, shielding gas connection, inlet
Cooling air outlet
Mains connection cable > see 5.1.6 chapter
5-pole connection socket
Cooling unit voltage supply
Intermediate hose package strain relief
Machine feet
Description 0
Electrode diameter push-button > see 5.2.14 chapter
Ignition optimisation (TIG) > see 5.2.16 chapter
Gas test/rinse hose package button
> see 5.2.2.1 chapter
Figure 4-3
Machine control (Mode RC - on)
17
