7.9

Interface

The device can be integrated into a data network (Modbus) via an
optional RS485 interface.
ConF -> i ntF ->
Parameters
Baud rate
bdrt
Data format
dFt
Device
address
Adr
Min. response
time
(Setup)
TIP!
W hen the communication takes place via the setup interface, the
RS485 interface is inactive.
TIP!
F or further information a separate interface description Modbus
is available (as a PDF file).
38 | nVent.com
Value /
Selection Description
0 9600 bps
1 19200 bps
2 38400 bps
0 8 data bits, 1 stop bit, no parity
1 8 data bits, 1 stop bit, odd parity
2 8 data bits, 1 stop bit, even parity
3 8 data bits, 2 stop bits, no parity
0...1... Address in data network
255
0 ... Time period in milli-seconds that elapses
500 ms between the request of a device in the data
network and the response of the controller.
Setting in the Setup program
(-> Interface)
