Parameters
Service interval
(Setup)
oCAL
Service type
(Setup)
36 | nVent.com
Value /
Selection Description
Number: Limit value for service counter
(when select. "Number" in increm. of 1000)
0...
0 = Service counter switched off
9999000
The service counter can be used to monitor
Time (h):
a binary signal in respect to number
0...999
(switch-on edge) or time (ON state).
Time (d):
0...999
The service counter is started when
entering a value > 0. When the limit value is
exceeded, a signal is generated which can
be put out to a binary output.
The signal can only be acknowledged by
resetting the limit value to zero (service
counter switched off).
The counter value is saved every hour in
the EEPROM; the counter value saved last
is used to continue counting after a power
failure.
Special features on the device when
selecting "Number" (operation and display
only in the User level):
- V alue range: 0...9999
(1 corresponds to 1000)
- C ounter reading is displayed in Thousand
(1 corresponds to 1000); when the
counter value is below 1000, the display
shows 0.
- S imultaneously press the +
The complete counter value is displayed on
both displays for approx. 3 s.
Example: Counter value 1234567;
upper display = 1234, lower display = 567
Setting in the Setup program
(-> Display/Operation /Service counter ->
Service counter)
Monitoring Selection of the interval type
number
Setting in the Setup program (-> Display/
Operation/Service counter -> Service
counter):
- Monitoring number (quantity)
- Monitoring time (h)
- Monitoring time (d)
keys:
