nvent raychem tcontrol-cont-03 Operating And Installation Manual page 7

Configuration level (ConF) cont...
Parameter
Limit comparator 1 (LC1):
Function (FnCt)
Alarm value (AL)
Response by Out of
Range (ACrA)
Limit comparator 2 (LC2):
Function (FnCt)
Alarm value (AL)
Response by Out of
Range (ACrA)
Binary outputs (OutL):
Binary output 1
(Out1)
Binary output 2
(Out2)
Binary output 3
(Out3)
Binary output 4
(Out4)
Analog output (OutA):
Type of signal
(SiGn)
Display/Operation/Service counter (diSP):
Decimal place
(dECP)
Service interval
(oCAL)
Level inhibit
Factory setting for type
TCONTROL- CONT-03
lk8
2.0
1 (= ON)
lk7
120.0
1 (= ON)
1 (= Controller output 1) 5 (= Limit comparator 1)
5 (= Limit comparator 1) 6 (= Limit comparator 2)
0 (= no function)
6 (= Limit comparator 2)
1 (= one digit after
decimal point)
30000
Parameter and
Configuration level
TCONTROL- CONT-03/MA
lk8
2.0
1 (= ON)
lk7
120.0
1 (= ON)
0 (= no function)
3 (= 4...20 mA)
1 (= one digit after
decimal point)
0 (= switched off)
Parameter and
Configuration level
