Signal to be
monitored
(Setup)
User level
(Setup)
Controller Selection of the binary signal to be monitored
output 1 Setting in the Setup program (-> Display/
Operation/Service counter -> Service
counter):
- deactivated
- Controller output 1
- Controller output 2
- Binary input 1
- Binary input 2
- Limit comparator 1
- Limit comparator 2
- Timer signal
- Timer runs
- Timer completed
- Timer waiting
- Tolerance band signal
- Ramp end
- Service alarm
- Key actuation
- Manual mode
A maximum of eight parameters from
the various levels can be defined to be
available in the User level of the device.
The parameter name (max. 4 characters
which can be displayed with 7-segment
display) can be user-defined. Without a
user-default entry, the name programmed
in the device will appear.
Setting in the Setup program
(-> Display/Operation/Service counter ->
User level)
