7.8

Display/Operation/Service counter

Both displays can be adapted to the respective requirements by
the configuration of the displayed value, the decimal place and
the automatic change (timer).
The time-out of the operation, the function key assignment and
the level inhibit can also be configured.
ConF -> d SP ->
Parameters
Upper display
d SU
Lower display
d SL
Display change
to timer value
d St
Time-out
tout
Restart time
trES
(Power ON
delay)
Decimal place
dECP
34 | nVent.com
Value /
Selection Description
(Analog Display value for the upper display
selector)
Process
value
(analog Display value for the lower display
selector)
Current
set point
value
Time appears in the lower display
(only effective after the timer is started)
0 no function
1 Display of residual timer time
2 Display of timer run time
0... 180... Time period in seconds, after which the
255 device automatically returns to normal
display if no key is pressed.
0...9999 Start delay time in seconds after Power
ON
All functions of the device are only active
after this time has elapsed.
0 no digit after the decimal point
1 one digit after the decimal point
2 two digits after the decimal point
If the value to be displayed cannot be
shown including the programmed decimal
point, the number of digits after the
decimal point are automatically reduced.
If subsequently the measured value
contains less digits, the reading appears
with the decimal point as programmed.
