Type Designation; Scope Of Delivery; Accessories - nvent raychem tcontrol-cont-03 Operating And Installation Manual

1.2

Type designation

Type key
702071/9-1131-23-00
(nVent Part No.:
1244-0006829)
702071/9-1131-23-00
(nVent Part No.:
1244-0006829)
702071/9-1131-23-53
(nVent Part No.:
1244-0006982)
702071/9-1134-23-53
(nVent Part No.:
1244-0006981)
1.3

Scope of delivery

• Controller (including seal and fastening elements)
• Operating and Installation manual INSTALL-148 in DIN A4 format
1.4

Accessories

Computer aided setup and configuration utility
(TCONTROL-CONT-03/CONFIG)
Content:
• Mini CD with software, license + manuals
• PC interface with USB/TTL converter, cable and connector
Hardware requirements (PC):
• 512 MB RAM
• 250 MB free space on hard disk
• CD ROM drive
• Free USB interface
• Operating system:
Microsoft
(32-bit and 64-bit version)
Type description
TCONTROL-CONT-03
nominal dimension 48 mm x 48 mm
• 1 analog input
• 3 relays
TCONTROL-CONT-03/MA
nominal dimension 48 mm x 48 mm
• 1 analog input
• 2 relays
• 1 analog output (user configurable
0/4...20 mA or 0/2...10 V)
TCONTROL-CONT-03/COM
nominal dimension 48 mm x 48 mm
• 1 analog input
• 3 relays
• Interface RS485
TCONTROL-CONT-03/COMA
nominal dimension 48 mm x 48 mm
• 1 analog input
• 2 relays
• 1 analog output| (user configurable
0/4...20 mA or 0/2...10 V)
• Interface RS485
Windows 2000 / XP / Vista / 7
