Further functions via Setup program
In the Setup program binary functions can be combined with each
other (selection under "Additional functions").
It is also possible to select "Text display" as an additional
function. A maximum of 4 characters can be entered as text
("Text display" button) and displayed with a 7-segment display.
The text appears in the lower display when the binary function is
active.
ConF -> b nF
Parameters
Binary inputs
b n 1
b n2
1
Limit
comparators
LC1
LC2
Timer signal
tF1
Ramp end
signal
rEnd
Tolerance band
signal, ramp
toLS
For activation of binary input 2 the setup program is required (Hardware assistant).
1
Value /
Selection Description
0 no function
1 Start self-optimization
2 Abort self-optimization
3 Change to manual mode
4 Controller off (controller outputs are
switched off)
5 Switch on controller
6 Inhibit manual mode
7 Stop ramp
8 Abort ramp
9 Restart ramp
10 Set point value toggling:
0/Contact open = Set point value 1 active,
1/Contact closed = Set point value 2
11 active)
12 (reserved)
13 (reserved)
14 (reserved)
15 (reserved)
16
(reserved)
17 Key inhibit
Level inhibit:
The parameter and the configuration level
18 are inhibited.
19 Start of self-optimization is inhibited.
20 Display off with key inhibit
21
(reserved)
22 Timer acknowledgement
23 Starting the timer
24 Timer abort
Timer stop
Timer start/abort
