Controller
Controller type
Controller
structures
A/D converter
Sampling cycle
time
Timer
Accuracy
Electrical data
Supply voltage
(switch mode PSU)
Electrical safety
Amperage
Data backup
Electrical
connection
Electromagnetic
compatibility
Interference
emission
Interference
immunity
Case
Case type
Installation depth
Ambient/storage
temperature range
Ambient conditions rel. humidity < 90% annual average, no condensation
42 | nVent.com
2-state, 3-state, modulating controller, continuous
controller
P/PI/PD/PID
16 bit resolution
250 ms
±0.8 % ± 25 ppm/K
AC 110—240 V -15/+10%, 48—63 Hz
AC/DC 20—30 V, 48 — 63 Hz
acc. to EN 61010, part 1
Overvoltage category III, pollution degree 2
max. 15 VA
EEPROM
at the back via screw terminals,
Conductor cross section up to max. 1.3 mm
Installation information on conductor cross
sections
Solid core
Stranded, with
core-end ferrule
EN 61326-1
Class B
Industrial requirements
Plastic case for panel mounting acc. to IEC 61554
90.5 mm
–5...+55 °C / -40...+70 °C
≤ 1.3 mm
2
≤ 1.0 mm²
2
