3.2

Electrical isolation

2300 V AC
(1)
30 V AC
50 V DC
(2)
(3)
30 V AC
50 V DC
(4)
3.3

Connection diagram

1
2
(1)
5
6
N(L-)
(8) AC/
DC L1(L+)
(1) Output 1 (K1): Relay 230
V AC/3 A
(3) Output 3 (K3): Logic 0/14
V (alternative to binary
input 1, configurable)
(5.1) Binary input 1
(for potential-free contact);
(alternative to output 3,
configurable)
(6) Analog input
(6.1) Standard signals (input
0/2—10V alternative to
binary input 2)
(6.3) RTD temperature probe
(3 wire)
(7) RS485 interface (Option)
(7)
(1) Analog input
(2) Binary inputs/Output K3 (Logics)
(6)
(3) Setup interface
(4) Voltage supply
(5) (5) RS485 interface
(6) Analog output
2300 V AC
(7) Outputs K1, K2 and K4 (relay)
-
13
0/4—20mA
(4)
0/2—10V
+ 14
- 17
(3)
(2)
0/14V
18
+
19
20
0/4—20mA
21
22
23
RxD/TxD
24
(5.1) (5.2)
+
0/2—10V
(6.1) -
-
+ +
-
(6.2) (6.3)
(7)
+
(2) Output 2 (K2): Relay 230 V
AC/3 A
(4) Output 4 (K4) (option): Analog
output or Relay 230 V AC/3 A
(5.2) (5.2) Binary input 2
(for potential-free contact);
(alternative to input
0/2—10V, configurable with
setup program)
(6.2) Thermocouple
(6.4) RTD temperature probe
(2 wire)
(8) Voltage supply 110—240 V AC
(Option: 20—30 V AC/DC)
(6)
(6.4)
