Analog selector
Some parameters in the Configuration level allow users to select from a
series of analog values. The list below shows all available options.
Value Description
0 Deactivated
1 Analog input
2 Process value
3 Current set point value
4 Ramp limit value
5 Ramp set point value
6 (Reserved)
7 (Reserved)
8 Set point value 1
9 Set point value 2
10 Controller output value (-100%...+100%)
11 Controller output 1 (0...+100%; e. g. "Heating")
12 Controller output 2 (0...-100%; e. g. "Cooling")
13 Timer run time (time unit of the timer)
14 Residual timer run time (time unit of the timer)
15 (Reserved)
16 (Reserved)
17 (Reserved)
