8 Specifications
Surroundings:
Enclosure type A
Enclosure type B1/B2
Enclosure type B3/B4
Enclosure type C1/C2
Enclosure type C3/C4
Enclosure type D1/D2/E1
Enclosure type D3/D4/E2
Enclosure kit available ≤ enclosure type D
Vibration test
Relative humidity
Aggressive environment (IEC 60068-2-43) H
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature (at 60 AVM switching mode)
- with derating
- with full output power of typical EFF2 motors (up to 90% output current)
- at full continuous FC output current
1) For more information on derating, see the Design Guide, section on Special Conditions.
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Temperature during storage/transport
Maximum altitude above sea level without derating
8
Maximum altitude above sea level with derating
Derating for high altitude, see section on special conditions.
EMC standards, Emission
EMC standards, Immunity
See section on special conditions!
Control card performance:
Scan interval
Control card, USB serial communication:
USB standard
USB plug
Connection to a PC is done via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
The USB connection is not galvanically isolated from protection ground. Use only an isolated laptop/PC as the connection to the USB
connector on the adjustable frequency drive or an isolated USB cable/drive.
Protection and Features:
• Electronic thermal motor protection against overload.
• Temperature monitoring of the heatsink ensures that the adjustable frequency drive trips if the temperature reaches 203°F ± 41°F [95°C ±
5°C]. An overload temperature cannot be reset until the temperature of the heatsink is below 158°F ± 41°F [70°C ± 5°C] (Guideline - these
temperatures may vary for different power sizes, enclosures, etc.). The adjustable frequency drive has an auto derating function to avoid its
heatsink reaching 203°F [95°C].
• The adjustable frequency drive is protected against short-circuits on motor terminals U, V, W.
• If a line phase is missing, the adjustable frequency drive trips or issues a warning (depending on the load).
8-18
S test
2
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
MG.11.A9.22 - VLT ®
VLT ® HVAC Drive Instruction Manual
IP 20/Chassis, IP 21kit/Type 1, IP55/Type12, IP 66/Type12
IP 21/Type 1, IP55/Type12, IP 66/12
IP 21/Type 1, IP55/Type 12, IP66/12
IP21/NEMA 1/IP 4
5%–95%(IEC 721-3-3; Class 3K3 (non-condensing) during operation
-13°–+°149/°158°F [-25°–+65°/70°C]
EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
is a registered Danfoss trademark
IP20/Chassis
IP20/Chassis
IP21/Type 1, IP54/Type12
IP00/Chassis
on top of enclosure
X
1.0 g
class Kd
max. 55° C 1)
max. 50 ° C 1)
max. 45 ° C
1)
32°F [0°C]
14°F [-10°C]
3280 ft [1000 m]
9842 ft [3000 m]
EN 61800-3, EN 61000-6-1/2,
: 5 ms
1.1 (Full speed)
USB type B "device" plug
