6 How to program the adjustable frequency
drive
[8] Analog input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[100] Bus feedback 1
[101] Bus feedback 2
[102] Bus feedback 3
[104]
[105]
NOTE!
If a feedback is not used, its source must be set to
feedbacks will be used by the PID controller.
6
20-01 Feedback 1 Conversion
Option:
[0] * Linear
[1] Square root
[2] Pressure to temperature
20-03 Feedback 2 Source
Option:
[0] * No function
[1] Analog input 53
[2] Analog input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog input X30/11
[8] Analog input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[100] Bus feedback 1
[101] Bus feedback 2
[102] Bus feedback 3
6-44
No Function
[0]. par.20-20
Function:
This parameter allows a conversion function to be applied to Feedback 1.
Linear
[0] has no effect on the feedback.
Square root [1] is commonly used when a pressure sensor is used to provide flow feedback
flow pressure
( ( ∝ ) ).
Pressure to temperature
[2] is used in compressor applications to provide temperature feedback
using a pressure sensor. The temperature of the refrigerant is calculated using the following for-
mula:
A 2
Temperature =
( ( + 1 ) − 1 )
ln Pe A
stants. The refrigerant must be selected in par. 20-30
par. 20-23 Setpoint 3 allow the values of A1, A2 and A3 to be entered for a refrigerant that is not
listed in par. 20-30 Refrigerant .
Function:
See par.20-00 Feedback 1 Source for details.
MG.11.A9.22 - VLT ® is a registered Danfoss trademark
VLT ® HVAC Drive Instruction Manual
Feedback Function
determines how the three possible
− A 3 , where A1, A2 and A3 are refrigerant-specific con-
Refrigerant . par.20-21 Setpoint 1 through
